Marine Navigation & Instruments - Compasses

Ritchie GM-5-C 5" GlobeMaster Binnacle Mount Compass Cover - WhiteProtective cover for Globemaster binnacle models.For: SP-5B, SP-5C, D-515, and D-515-EPApprox. Shipping Weight: 1lb (454g)

Read more less

SCX21 Satellite CompassUtilizing four separate GNSS Antennas for the ultimate in responsiveness, the SCX21 sets a new standard for reliable and accurate heading for all of your marine electronics. The four antennas ensure reliable heading performance, even under the most challenging of conditions. The unprecedented quad antenna design of the SCX21 makes it capable of calculating extremely accurate heading, pitch, roll, and heave information, even when line of sight is limited to only a single satellite. They greatly enhance the performance of onboard equipment such as Radar, Fish Finders, Sonar, and Autopilots.Features: Outputs accurate Time, Position, Heading, COG/SOG, ROT (10 degrees/second), Roll/Pitch/Heave 3-Axis Speed, Air Temperature and Air Pressure data Unprecedented heading accuracy for Radars, Sonars, and Navigation 1.0 degree heading accuracy, 0.02 knot speed accuracy Extremely compact with easy & flexible installation for reduced susceptibility to multi-path interference This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

SC33 Compact Dome Satellite Compass, NMEA2000 (0.4° Heading Accuracy) with 6M CableSleek, Fast & AccurateThe SC33 Satellite Compass provides highly accurate attitude information for navigation equipment such as Radar, Plotter, Autopilot, Fish Finder and Sonar. With its compact GNSS antenna and built-in processor, it can be used for a wide variety of applications on any type of vessel. This all-in-one system delivers incredibly accurate heading and roll & pitch information as well as heaving information, GPS position, SOG (Speed Over Ground), COG (Course Over Ground) and ROT (Rate Of Turn) data.Employing a two-antenna system with a 3-axis gyro and acceleration sensors, the SC33 enables high-speed response capability. Advanced digital signal processing techniques compute accurate heading based on sensor data. NMEA2000 interface is standard for simple installation, while the optional interface unit IF-NMEASC is available for conventional NMEA0183, AD10 and contact closure.The GNSS antenna and advanced parallel signal processing allows the SC33 to achieve more precise Pitch, Roll and Heading measurement than conventional models, providing enhanced performance for all of your connected equipment. Its Micro-C pigtail NMEA2000 cable provides flexibility to run cables in challenging areas.Revolutionary 2-Antenna & Rate Sensor SystemIn order to calculate roll & pitch data, a satellite compass requires two vectors. The SC33 employs a dual GNSS antenna system that calculates a single vector while a 3-axis rate gyro and acceleration sensors add the 2nd vector. This configuration enables the SC33 to calculate highly accurate roll and pitch data without using a third sensor.Features: Highly Accurate Two Antenna Satellite Compass & Rate Sensor System More resistant to multi-path, shock & vibration, compared to previous models Improved time to first fix (TTFF) = 60 seconds (typical) NMEA2000 Certified Interface/NMEA0183 Interface with IF-NMEASC (Optional) Accuracy: ±0.4° RMS (Heading/Roll/Pitch) Position Accuracy: 5.0M (GPS); 3.0M (GPS + SBAS) Integrated Rate Sensors provide Pitch, Roll and Heave Compensation 6 Meter Micro-C Male/Female NMEA2000 Drop Cable (Standard Supply) Pigtail cable w/NMEA2000 connector for convenient connection to drop cable Tri-axis speed & direction via PGN 130578 & "Heartbeat" PGN output SC33 menu access with NavPilot 300 & TZtouch2 (with impending software update) This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

SCX20 Satellite CompassUtilizing four separate GNSS Antennas for the ultimate in responsiveness, the SCX20 sets a new standard for reliable and accurate heading for all of your marine electronics. The four antennas ensure reliable heading performance, even under the most challenging of conditions. The unprecedented quad antenna design of the SCX20 makes it capable of calculating extremely accurate heading, pitch, roll, and heave information, even when line of sight is limited to only a single satellite. They greatly enhance the performance of onboard equipment such as Radar, Fish Finders, Sonar, and Autopilots.Features: Outputs accurate Time, Position, Heading, COG/SOG, ROT (10 degrees/second), Roll/Pitch/Heave 3-Axis Speed, Air Temperature and Air Pressure data Unprecedented heading accuracy for Radars, Sonars, and Navigation 1.0 degree heading accuracy, 0.02 knot speed accuracy Extremely compact with easy and flexible installation for reduced susceptibility to multi-path interference This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

X-23WW RitchieSport Compass - Dash Mount - White/BlackFeatures: 2″ (51 mm) Direct Reading Dial Easily Installed, Fits Standard 2 1/16″ (5.50 cm) Instrument Hole The View Adjusts up to 30 degrees Scientifically Matched Sapphire Jewel & Hardened Steel Pivot Dial Movement Exclusive Built-in Green NiteVu Lighting High-Temperature Composite Construction for Extended Operating Range DirectiveForce Magnets Exclusive 5-Year Ritchie Warranty Specifications:Approx. Shipping Weight: 5oz (142g)Notes: X-23 Compasses do not have Built-in Compensators. Comes standard with 12V lighting Some custom-built OEM models may have different lighting Specifications: Backlight: Yes Lubber Lines: Yes Mounting Style: Dash Read: Front Box Dimensions: 3"H x 4"W x 5"L WT: 0.55 lbs UPC: 010342121240

Read more less

Helmsman Combidial CompassFeatures: 3 3/4″ (95 mm) Open Face Dial or CombiDial Adjustable and Removable with Bracket and Thumbscrews Exclusive Built-in Green NiteVu Night Illumination Built-in Compensators to Easily Adjust for Deviation Scientifically Matched Sapphire Jewel and Hardened Steel Pivot Dial Movement Powerful DirectiveForce Magnets for Fast Heading Lock-on Movable Sun Shield 45 Degree Lubber lines High Temperature Composite Construction for Extended Operating Range 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 2lbs (907g)Notes:Comes standard with 12V lighting. 24 & 32V lighting options are available. Some custom built OEM models may have different lighting. Specifications: Read: Both Mounting Style: Bracket Lubber Lines: Yes Backlight: Yes Box Dimensions: 7"H x 8"W x 8"L WT: 2.45 lbs UPC: 010342138613 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

MSC 10 Marine Satellite CompassKNOW EXACTLY WHERE YOU'RE HEADEDGet reliable, accurate heading information with the easy-to-install GPS-based MSC 10 marine satellite compass.Features: Accuracy comes easy when you’ve got a multi-band GNSS receiver on board. Faster updates. More detailed tracking. Rough waters got you worried? MSC 10 delivers pitch, roll, and heave info, too. If other onboard systems need a heading sensor, we’ve got you covered. MULTI-BAND GNSS AND MULTI-CONSTELLATIONThe multi-band GNSS (L1 and L5 GPS) and multi-constellation (GPS, Galileo1, GLONASS, and BeiDou1) receiver deliver precise positioning2.BOAT HEAVE AND MOREGet reliable, accurate boat heave, pitch, and roll information — even in rough waters.BUILT-IN ATTITUDE HEADING REFERENCE SYSTEM (AHRS)With a fully integrated attitude and heading reference system for better GPS heading at all speeds, including pitching in rough seas, taking sharp turns, or standing still.ACCURATE HEADING DATAMultiple receivers deliver heading accuracy within 2 degrees. Because it uses satellite signals, you don’t have to worry about magnetic interference.PRIMARY SENSOR ACROSS MULTIPLE SYSTEMSYou can use MSC 10 as the primary sensor for autopilots and other onboard systems that need accurate heading information.NMEA 2000® NETWORK COMPATIBLEGet heading, pitch, roll, and heave information delivered straight to your compatible Garmin chartplotter via the NMEA 2000 network.EASY TO INSTALLThis compact device is simple to install and easily integrates into your Garmin marine ecosystem.10 HZ UPDATE RATEGet better, more detailed tracking information, thanks to the 10 Hz position update rate.BACKUP HEADING SENSORIn the extremely rare case that you lose a satellite signal, MSC 10 will seamlessly transition from GPS-based to magnetometer-based heading3.What's In The Box? MSC-10 Marine Satellite Compass Pole mount Mounting hardware NMEA 2000® backbone/drop cable (6 meters) NMEA 2000 T-connector Documentation 1 Supported when available2 < 1 meter CEP, < 3 meters 95%3 Magnetometer calibration required for backup magnetic heading support

Read more less

Explorer CompassFeatures: 2 3/4″(70 mm) Direct Reading Dial Easily Installed, Fits 3″ Instrument Hole. Bezels Styled to Match Popular Gauge Packages 12v Night Illumination Viewing is adjustable to 30 degrees Choice of Traditional Black or Designer White Colors Scientifically Matched Sapphire Jewel & Hardened Steel Pivot Dial Movement Built-in Compensators to Easily Adjust for Deviation Hi-Temperature Construction 100% Repairable Exclusive 5-Year Warranty Approx. Shipping Weight: 1lb (454g)Notes:All compasses come standard with 12v lighting. 24v lighting option is available. Some custom built OEM models may have different lighting. Specifications: Read: Front Mounting Style: Dash Backlight: Yes Lubber Lines: Yes Box Dimensions: 5"H x 6"W x 6"L WT: 0.8 lbs UPC: 010342160614 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Explorer CompassFeatures: 2 3/4″ (70 mm) Easy to Read Direct Reading Dial Adjustable and Removable with Bracket and Thumbscrews Internal Green Night Illumination Built-in Compensators to Easily Adjust for Deviation Scientifically Matched Sapphire Jewel & Hardened Steel Pivot Dial Movement Powerful DirectiveForce Magnets for Fast Heading Lock-on Movable Sun Shield High Temperature Composite Construction for Extended Operating Range 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 1lb (454g)Notes:All compasses come standard with 12v lighting. 24v lighting option is available. Some custom built OEM models may have different lighting.  Specifications: Read: Front Lubber Lines: Yes Backlight: Yes Mounting Style: Bracket Box Dimensions: 5"H x 6"W x 6"L WT: 0.9 lbs UPC: 010342160515 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Navigator CompassFeatures: 4 1/2″ (115 mm) PowerDamp Open Face Dial with Large Numerals Ideal for both Power and Sailboats Fits all Popular Sailboat Steering Pedestals Easily Installed Stainless Housing selections: Brushed stainless, powder-coated black, or powder-coated white 12v Green LED lighting Standard Built-in Compensators to Easily Adjust for Deviation Movable Sun Shield 45 Degree Lubber Lines High Temperature Construction for Extended Operating Range Weather Shield available. Model No. WS-P 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 3lbs 10oz (1.65 kg)Notes:12v lighting standard - 24 & 32v lighting options are available. Specifications: Mounting Style: Binnacle Lubber Lines: Yes Read: Rear Backlight: Yes Box Dimensions: 7"H x 8"W x 8"L WT: 3.6 lbs UPC: 010342150219 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Ritchie NC-20 Navigator Bulkhead Mount Compass Cover - WhiteBack cover for Navigator Bulkhead mount.For: BN-202Approx. Shipping Weight: 1lb (454g)

Read more less

SteadyCast™ Heading SensorKnow where you're actually casting. SteadyCast heading sensor is a simple, easy-to-install solution that provides fast calibration and premium heading accuracy. It aligns your boat bow to its actual orientation so you know where you are casting according to your chartplotter screen.Features: Ensures bow orientation on your chartplotter matches your heading Heading accuracy of plus or minus 3 degrees Easy NMEA 2000® plug-and-play interface Simple 2-step calibration process 9-axis MEMS technology allows installation in any orientation located away from magnetic interference Accurate Heading Even at Low SpeedIts heading output rate at 10 Hz and accuracy of plus or minus 3 degrees ensures your chart orientation and boat heading line match up with reality, even at trolling speeds or when dead in the water.Effective in Rough WatersYou can also be confident your heading information will remain accurate, even in rough water.Easy Installation, Fast CalibrationSteadyCast heading sensor installs easily with NMEA 2000® plug-and-play interface and a simple 2-step precision calibration process for compatible Garmin chartplotters. Basic calibration for displays other than Garmin is also supported. Its 9-axis MEMS technology allows installation in any orientation located away from magnetic interference, and it's built to withstand bilge environments.In The Box: SteadyCast heading sensor with integrated NMEA 2000® drop cable (6 ft) NMEA 2000® T-connector Documentation WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Output Frequency (mHz): 10Hz Box Dimensions: 4"H x 6"W x 7"L WT: 0.6 lbs UPC: 753759173838
