Marine Navigation & Instruments - GPS - Fishfinder Combos

Axiom 2 Pro 16 RVM Chartplotter/Fishfinder - Lighthouse North America Chart - No Transducer Axiom 2 Pro combines chartplotter, sonar, radar, autopilot, and video into a powerful all-in-one navigation system. With Axiom 2 Pro, you can navigate smarter and expand your system, thanks to the super intuitive LightHouse operating system. Plan your next trip and get underway confidently with Axiom 2 Pro’s HybridTouch™ — a simple touchscreen and keypad experience. Axiom 2 Pro RVM chartplotters feature built-in wide-spectrum CHIRP with RealVision MAX technology. RealVision MAX ups your fish-finding game with DownVision, SideVision, and 3D sonar upgraded with increased range, better resolution, and sharper fish targets.Features: Includes preloaded LightHouse Charts North America chart card Includes 1 Free year of LightHouse Charts Premium Subscription Get underway faster with a fast 6-core processor HydroTough™ nano-coating repels water for reliable touchscreen control and superior sunlight visibility Confident HybridTouch™ control plus an interchangeable autopilot keypad or user-programable soft keys Find more fish with built-in RealVision MAX CHIRP and dual channel 1kW CHIRP sonar Smart backlighting and an ambient light sensor automatically adjust display brightness for day and evening Create your own Axiom 2 Pro system with multiple networked Axiom displays Stay entertained with streaming Apps and Axiom 2 Pro’s HDMI and audio output for remote displays and marine entertainment system What's in the Box? Display unit User Configurable Keypad Suncover Gasket Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3)) DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft) RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft) Mounting fixings x 4 Documentation Power/Video/Audio cable 1.5 m (4.92 ft) Specifications: Cartography Brand: Navionics/C-Map Screen Size: 16" Touchscreen: Yes Transducer Included: No Box Dimensions: 1"H x 4"W x 5"L WT: 20.45 lbs

Read more less

Axiom 2 Pro 16 RVM Chartplotter/Fishfinder  - No Transducer Axiom 2 Pro combines chartplotter, sonar, radar, autopilot, and video into a powerful all-in-one navigation system. With Axiom 2 Pro, you can navigate smarter and expand your system, thanks to the super intuitive LightHouse operating system. Plan your next trip and get underway confidently with Axiom 2 Pro’s HybridTouch™ — a simple touchscreen and keypad experience. Axiom 2 Pro RVM chartplotters feature built-in wide-spectrum CHIRP with RealVision MAX technology. RealVision MAX ups your fish-finding game with DownVision, SideVision, and 3D sonar upgraded with increased range, better resolution, and sharper fish targets.Features Get underway faster with a fast 6-core processor HydroTough™ nano-coating repels water for reliable touchscreen control and superior sunlight visibility Confident HybridTouch™ control plus an interchangeable autopilot keypad or user-programable soft keys Find more fish with built-in RealVision MAX CHIRP and dual channel 1kW CHIRP sonar Smart backlighting and an ambient light sensor automatically adjust display brightness for day and evening Create your own Axiom 2 Pro system with multiple networked Axiom displays Stay entertained with streaming Apps and Axiom 2 Pro’s HDMI and audio output for remote displays and marine entertainment system What's in the Box? Display unit User Configurable Keypad Suncover Gasket Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3)) DeviceNet to SeaTalkng adaptor cable 1m (3.28 ft) RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft) Mounting fixings x4 Documentation Power/Video/Audio cable 1.5 m (4.92 ft) Specifications: Cartography Brand: Navionics/C-Map Screen Size: 16" Touchscreen: Yes Transducer Included: No Box Dimensions: 10"H x 14"W x 22"L WT: 20.4 lbs UPC: 723193843567

Read more less

HELIX 10 CHIRP MEGA MSI+ GPS G4NThe HELIX 10 CHIRP MSI+ GPS G4N features a 10.1" display, MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar, and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 10 includes standard features such as AutoChart Live, Wi-Fi, and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota and Cannon.FeaturesKeypad ControlMaster HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft-key controls that allow users to reliably operate the fish finder in any conditions.MEGA Side Imaging+See the world below like never before with a crystal-clear side imaging view out to 200 feet on either side of the boat. Users will unlock more fish and structures with 20% more detail and 60% more range capability than MEGA Side Imaging sonar.MEGA Down Imaging+Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below the boat. Users will unlock more fish and structures with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar.Dual Spectrum CHIRP SonarBefore users cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by Humminbird's proprietary Low-Q CHIRP transducer, the Dual Spectrum offers two ways to search: wide mode for maximum coverage and narrow mode for focusing on the slightest detail.Internal GPS and Humminbird BasemapHumminbird's enhanced basemap provides users with a clear view of underwater terrain and surrounding points of interest, so users can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.Premium Chart CompatibleHumminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as compatible Navionics® charts.AutoChart LiveCreate real-time maps of the fishing spots with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as users drive the boat. It comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually unlimited AutoChart Live mapping capacity.One-Boat Network CompatibleMany Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Users can take advantage of the time on the water by using the exclusive boat control and fish-catching features of the One-Boat Network.Ethernet NetworkingHigh-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.BluetoothTake control right from the screen of a Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and the display of smartphone notifications on the Humminbird.NMEA 2000 Networking Built-inConnect an accessory NMEA 2000 network to a control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.Includes:Includes control head, screen cover, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.Specifications: Series: HELIX Display Size – Diagonal: 10.1 in Display Pixel Matrix: 1024H x 600V Sonar-Standard: Dual Spectrum CHIRP / MEGA Down Imaging+ / MEGA Side Imaging+ Sonar-Coverage: 20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP Live Sonar Coverage: 20 degrees x 120 degrees CHIRP - Frequencies Supported: Full Mode (150-220 kHz) / Narrow Mode (180-240 kHz) / Wide Mode (140-200 kHz) Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz Depth-Sonar: 1,200 ft (standard transducer) / 3,500 ft (optional 50 kHz) CHIRP - Imaging-Frequencies Supported / 455 kHz DI+ (435-535 kHz) / 455 kHz SI+ (405-505 kHz) / 800 kHz DI+ (800-860 kHz) / 800 kHz SI+ (780-840 kHz) / MEGA DI+ (1100-1200 kHz) / MEGA SI+ (1050-1175 kHz) Depth-Down Imaging: 125 ft (800 kHz) / 200 ft (MEGA) / 400 ft (455 kHz) Range-Side Imaging (Side-To-Side): 800 ft (455 kHz) / 250 ft (800 kHz) / 400 ft (MEGA) Memory Card Slot: Dual SD Compatible With: AIS / AutoPilot / Minn Kota US2 Sonar / Minn Kota Built-In MEGA DI / Minn Kota Built-In MEGA SI / MEGA Live / One-Boat Network / Minn Kota i-Pilot Link / Minn Kota Talon/Raptor / NMEA 2000 Power Draw: 2.7 Amps Power Input: 10.8-20 VDC Power Output Peak-to-Peak: 8000 Watts Power Output RMS: 1000 Watts Screen Snap Shot: Included Sonar Recording: Included Mount-Standard: Gimbal Mount-Standard Size: 13.44 in W x 7.5 in H x 4.2 in D Mount-Optional: In-Dash Mounting Kit Mount-Optional Size: 13.44 in W x 7.12 in H x 1.32 in D Transducer Mount Location: Transom GPS Chartplotting: Included GPS Receiver: Internal GPS Trackplotting: Included Waypoints, Routes, Tracks/Points: 2,750, 45, 50/20,000 360 Imaging Compatibility: Yes LakeMaster Compatibility: Yes Coast Master Compatibility: Yes Navionics Gold/HotMaps Compatibility: Yes Navionics Platinum + Compatibility: Yes Platinum Compatibility: Yes Minn Kota i-Pilot Link Compatibility: Yes Minn Kota Talon Shallow Water Anchor Compatibility: Yes Radar Compatibility: Yes 5-Port Ethernet Switch Compatibility: Yes AIS Compatibility: Optional Autopilot Compatibility: Yes Heading Sensor GPS Compatibility: Yes NMEA2000: Included Target Separation: 2.5 in Interference Rejection: 6 Modes Noise Rejection: 10 Steps Upgradable Software: Yes View Preset Keys: Yes X-Press Menu System: Yes Custom Digital Readout: Yes Custom View Selections: Yes Display Colors Grayscale: 16-Bit Display Type: Color TFT Speed: Included Temperature: Built In Temperature Alarm: Yes Temperature Graph: Yes Transducer Included: XM 9 HW MSI T HDMI Compatible: No MEGA Live Compatibility: Yes Humminbird Basemap: Included Warranty: Two-Year Warranty Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: XM-9-HW-MSI-T Screen Size: 10" Touchscreen: No Transducer Included: Yes Box Dimensions: 11"H x 13"W x 19"L WT: 13.45 lbs UPC: 082324058226

Read more less

HELIX 7 CHIRP MEGA DI GPS G4NThe HELIX 7 CHIRP MEGA DI GPS G4N fish finder features MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish. All HELIX 7 G4N models support Ethernet networking, Bluetooth(R), NMEA 2000(R), Wi-Fi, and are compatible with the One-Boat Network(TM), which means you'll have total control of your fishing machine at your fingertips. Features: Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions. MEGA Down Imaging: Get unprecedented underwater clarity with coverage down to 125 feet below your boat. You'll unlock new details with up to 3X more detail than standard Down Imaging sonar. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts. AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity. One-Boat Network Compatible: These Humminbird models seamlessly integrate and communicate with other Humminbird and Minn Kota products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network. Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors. Additional features include wireless software updates from the Humminbird FishSmart App and a display of smartphone notifications on your Humminbird. NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking. Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware. 1-Year Limited Warranty Specifications: Display Size - Diagonal: 7" Display Pixel Matrix: 1024H x 600V Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz) Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz Depth-Sonar: 1,200 ft (standard transducer), 3,500 ft (optional 50 kHz) Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: XNT-9-HW-MDI-75-T Screen Size: 7" Touchscreen: No Transducer Included: Yes Box Dimensions: 5"H x 14"W x 17"L WT: 5.65 lbs UPC: 082324056239 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

HELIX 5 CHIRP/GPS G3 PortableIf fishing is in your DNA, there's no such thing as "too early" or "too far." The HELIX 5 Series answers the call with an uncompromising 5" widescreen, color display. This HELIX 5 CHIRP GPS G3 PT model features Dual Spectrum CHIRP 2D sonar, internal GPS with Humminbird Basemap, and AutoChart Live built-in, with additional compatibility for Humminbird and Navionics premium fishing charts. Take all of these features on the go thanks to a portable shuttle, battery, charger, and suction cup transducer.Features: Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions. Portable Carrying Case: Take your fishing system on the go. The soft-sided carrying case protects your Humminbird for safe transport. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts. AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity. Includes control head, Shuttle, bag, suction cup mount transducer, power cable, gimbal mounting bracket and mounting hardware. 1-Year Limited Warranty Specifications: Display Size - Diagonal: 5" Display Pixel Matrix: 800H x 480V Sonar-Standard: Dual Spectrum CHIRP Sonar-Coverage: 20°, 42° & 60° @ -10dB Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz) Sonar-Frequencies Supported: 50/80/200 kHz Depth-Sonar: 1,200 ft (standard transducer), 3,000 ft (optional 50 kHz) Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: XNT-9-HW-T Screen Size: 5" Touchscreen: No Transducer Included: Yes Box Dimensions: 7"H x 12"W x 14"L WT: 12 lbs UPC: 082324056314

Read more less

HELIX 7 GPS CHIRP MSI G4The HELIX 7 MEGA SI GPS G4 fish finder features MEGA Side Imaging, MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options, so users never miss a fish.Features: Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any condition. MEGA Side Imaging: See the world below like never before with crystal-clear viewing out to 125 feet on either side of the boat. Users unlock new details with up to 3X more detail than standard Side Imaging sonar. MEGA Down Imaging: Get unprecedented underwater clarity with coverage down to 125 feet below your boat. Unlock new details with up to 3X more detail than standard Down Imaging sonar. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts. AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity. Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware. 1-Year Limited Warranty Specifications: Display Size - Diagonal: 7" Display Pixel Matrix: 1024H x 600V Transducer Included: XNT 9 HW MSI 150 T Compatible With: Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, AIS, AutoPilot Features: Down Imaging, Built-In GPS, Side Imaging, Dual Spectrum CHIRP, Built In Mapping, MEGA Imaging Memory Card Slot: Single Micro SD Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging, MEGA Side Imaging Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP CHIRP - Frequencies Supported: Narrow Mode (180-240 kHz), 83/200 (75-155/130-250 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz) Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz Depth-Sonar: 3,500' (optional 50 kHz), 1,200 ft (standard transducer) CHIRP - Imaging Frequencies Supported: 455 kHz (440-500 kHz), MEGA SI (1075-1150 kHz), MEGA DI (1075-1150 kHz) Depth-Down Imaging: 75 ft (MEGA), 400 ft (455 kHz) Range-Side Imaging (Side-To-Side): 800 ft (455 kHz), 250 ft (MEGA) Interface: Keypad Control Power Draw: 800 mA Power Input: 10.8-20 VDC Power Output Peak-to-Peak: 4000 Watts Power Output RMS: 500 Watts Screen Snap Shot: Included Sonar Recording: Included Mount-Standard: Gimbal Mount-Standard Size: 10.54 in W x 5.8 in H x 3.68 in D Mount-Optional: In-Dash Mounting Kit Mount-Optional Size: 10.54 in W x 5.44 in H x 1.13 in D Transducer Mount Location: Transom GPS Chartplotting: Included GPS Receiver: Internal GPS Trackplotting: Included Waypoints, Routes, Tracks/Points: 2,750, 47, 50/20,000 360 Imaging Compatibility: No MEGA Live Compatibility: No Humminbird Basemap: Included LakeMaster Compatibility: Yes CoastMaster Compatibility: Yes Navionics Gold/HotMaps Compatibility: Yes Navionics Platinum+ Compatibility: Yes Platinum Compatibility: Yes Minn Kota i-Pilot Link Compatibility: No Minn Kota Talon Shallow Water Anchor Compatibility: No Radar Compatibility: No 5-Port Ethernet Switch Compatibility: No AIS Compatibility: Optional Autopilot Compatibility: Yes Heading Sensor GPS Compatibility: Yes Target Separation: 2.5" Interference Rejection: 6 Modes Noise Rejection: 10 Steps Upgradable Software: Yes View Preset Keys: No X-Press Menu System: Yes Custom Digital Readout: Yes Custom View Selections: No Display Colors Grayscale: 16-Bit Display Type: Color TFT Speed: Included Temperature: Built In Temperature Alarm: Yes Temperature Graph: Yes HDMI Compatible: No Warranty: One-Year Warranty Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: XNT-9-HW-MSI-150-T Screen Size: 7" Touchscreen: No Transducer Included: Yes Box Dimensions: 5"H x 14"W x 17"L WT: 5.2 lbs UPC: 082324058295 Owner's Manual (pdf)

Read more less

TZT16X 16" Multi-Touch Multi-Function DisplayThe 16” TZT16X features a super-wide all-glass display with exceptional clarity and brightness. The all-glass design allows these powerful MFDs to be mounted side-by-side for a seamless and stylish all-glass appearance to enhance both the functionality and sophistication of the helm.The TZT16X incorporates a powerful internal 1kW dual channel TruEcho CHIRP™ Fish Finder* designed to operate across a wide range of frequencies. For those who want to go even deeper, the 2kW/3kW DFF3-UHD TruEcho CHIRP™ Network Fish Finder delivers the ability to penetrate the deepest waters to find a catch. Also, with the BT-5 Booster Box, users can boost that output power up to 5 or 10 kW to take advantage of high-power transducer options that will unveil the deepest waters like users never experienced before.Features: 16 in. all glass display  TZ MAPS for highly detailed navigation and fishing charts Purchase and update charts directly from MFD with an internet connection Powerful hexacore processor for rapid response Video converter kits stream compatible sonar video data directly to TZtouchXL MFD Furuno’s exclusive Fish-It, Drift-It, & Follow-It features save time and fuel and increase fish catch Built-in Dual Channel 1kW TruEcho CHIRP™ & CW Fish Finder Built-in 235kHz or 455kHz CHIRP Side-Scan Built-In CHIRP Side-ScanFuruno’s CHIRP Side-Scan for NavNet TZT16X scans both port and starboard, illuminating the shape of the bottom structure in high definition. CHIRP Side-Scan 6 reveals the shape of fish targets and fish-hoarding structure on each side of the vessel. CHIRP from 235kHz or 445kHz center frequencies with thru-hull, paired, or transom mount transducer options.TZ MAPSOne of the most exciting TZtouchXL features is a chart offering called TZ MAPS. Not only are these some of the most detailed charts in the industry, but TZ MAPS users are in complete control of the chart content they want to download, such as raster or vector charts, satellite photos, and bathymetric data. Custom user objects can be shared with other registered TZ MAPS users through TimeZero's moderated service. Since custom objects reside on their chart layer on the TZtouchXL MFD, they can easily be displayed or hidden as desired. Additionally, for the first time, customers can purchase and update charts directly on their TZtouchXL MFD!BathyVisionOne of the most groundbreaking aspects of TZ MAPS is called BathyVision, providing amazingly detailed bathymetric data that can be configured to an incredible resolution of a mere 3 inches between contours! That's 3 times better than any other bathymetric chart currently on the market. BathyVision data, along with custom depth shading, can easily be overlaid on TZ MAPS navigation charts to create the ultimate "Fishing Charts"!AI RoutingTZ MAPS unlocks the ability to utilize the powerful AI Routing function that intelligently plans out routes, taking into consideration the boat's draft and navigational obstacles. AI Routing takes traditional auto-routing to another level by automatically creating suggested routes based on varying navigational conditions.Risk Visualizer & AI Avoidance RouteWhen connected to an NXT radar, two powerful safety features are unlocked: the Risk Visualizer and the AI Avoidance Route tool. Risk Visualizer provides a 360° visual representation of the potential collision risks of approaching objects around the vessel. Dynamic icons are automatically created for targets with the highest probability of collision, ensuring the captain has the necessary information to maintain safe distances when passing. The AI Avoidance Route function processes all available information provided to dynamically provide a safe route around those hazards, which can be sent to a Furuno NavPilot autopilot with a single tap.Enhanced User Interface for Ease of Use & CustomizabilityIn addition to offering all the great features that make NavNet super simple to operate, NavNet TZtouchXL MFDs also deliver BIG power and versatility! Users can now configure their MFD in many ways, thanks to an increased number of Page Builder configurations from four (4) to ten (10) custom combinations. Additionally, users can now custom-build a 6-way screen split of various components and sensors.Match all those great screen layout options with enhanced Edge-Swipe feature access for the smoothest, easiest, and very best user experience Furuno has ever delivered! This is all driven by the most system memory and the highest level of processing power Furuno has ever integrated into a NavNet MFD. Specifications:Display Unit: Type: Color TFT multi-touch IPS LCD Screen Size: 15.6" Wide Screen Resolution: FHD 1920 x 1080 Screen Brightness: 900 cd/m2 (typical) Display Colors: 16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder) Language: Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, Polish GPS/WAAS: Receiver Type: GPS: 72 channels, SBAS: 1 channel (C/A mode, WAAS) Receiving Frequency: L1 (1575.42 MHz) Time to First Fix: 100 s (cold start) Accuracy: 10 m (GPS), 7 m (MSAS), 3 m (WAAS) Position Update Interval: 100 ms or 10 Hz Chartplotter: Cartography: TZ MAPS, MM3 Vector, and CMOR capable (U.S. only) Memory Capacity: 30,000 user points, 100,000 points for ship's tracks, 200 planned routes (500 points per route) Alarms: Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge* (*external data required) Radar: Display Modes: Head-up, North-up*   *Heading input required.  Echo Trails: Interval: 15 s, 30 s, 1 min, 3 mins, 6 mins, 15 mins, 30 mins, and continuous (Heading input required)  Target Tracking: 100 ARPA Targets (Radar dependent) with fully automatic target acquisition (Heading input required)  Radar Alarms: Guard Zone, CPA/TCPA, Video, Azimuth, Heading Line Fishfinder: Transmit Frequency*: CW: 50/200 kHz, CHIRP: 40 kHz to 240 kHz (Low, Medium, and High) Transducer: 300/600 W or 1 kW*   *Matching box MB1100 required for some transducers Display Range: 2 to 1,200 m; shift 0 to 1,200 m (1,200-2,400m / 4,000-8,000ft)  Extension Mode: ACCU-FISH™, A-Scope, Auto (Fishing/Cruising), Bottom Discrimination, TruEcho CHIRP™ (with compatible transducer)  Picture Advance: 8 steps: x4, x2, x1, 1/2, 1/4, 1/8, 1/16, stop  Fish Finder Alarms: Fish School, Fish School for the bottom lock Side-Scan:  Transmit Frequency*: CHIRP: 220-240KHz/445-465KHz Transducer: 225kHz: 225T-PR904, 225T-SS904. 225T-TM904 / 455kHz: 455T-PR903, 455T-SS903. 455T-TM903  Display Range: 750 feet to each side  Display Colors: Green, Blue, Amber, White  Display Screen Sizes: Full Screen, 1/2 Screen, 1/4 Screen, 1/6 Screen Full Screen, 1/2 Screen, 1/4 Screen, 1/6 Screen  Direct Connect to MFD: Direct connect to TZ10X, TZT13X, TZT16X only; may be networked with TZT22X/TZT24X Interface: NMEA200: 1 Port Input: 065280, 126992/993/996, 127237/245/250/251/257/488/489/505, 128259/267, 129025/026/029/330/038/039/040/041/291/538/540, 129793/794/798/801/802/808/809/810, 130306/310/311/312/313/314/316/576/577/578, 130817/818/820/822/823/826/827/828/880 Output: 126992/993/996, 127250/251/257/258, 128259/267/275, 129025/026/029/033/283/284/285, 130306/310/311/312/313/314/316 NMEA0183: 1 Serial Output Port Output: AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB, RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA LAN: 1 Port (1000 BASE-T) USB: 1 Port (USB 3.0) for touch monitor and control unit: 1 Port USB touch output for HDMI device Video I/O: Input: 1 port (NTSC/PAL) and 1 port HDMI 1920 x 1080p or less (progressive only); Output: 1 port (HDMI 1080p) AUX I/O: 2 Ports (Event Switch and External Power Switch) SD Card Slot: 1 Slot (Micro SDXC, rear) Wireless LAN: IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max Transducer Connection: 1 Port 12 pin for CHIRP/CW, 1 Port 12 pin for Side-Scan Environment: Temperature (IEC60945)-15°C to +55° C Relative Humidity: 93% or less at +40° C Waterproofing: IP56 Power:12-24 VDCThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Screen Size: 16" Touchscreen: Yes Box Dimensions: 13"H x 16"W x 19"L WT: 17.3 lbs Brochure (pdf)

Read more less

HELIX 9® CHIRP MEGA DI+ GPS G4NThe HELIX 9 CHIRP MDI+ GPS G4N features a 9" display, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 9 includes standard features such as AutoChart Live, Wi-Fi and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota and Cannon. Features: Keypad control: Master HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft key controls that allow you to reliably operate your fish finder in any condition. MEGA Down Imaging+: Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below your boat. You'll unlock more fish and structure with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.  AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat.  Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity. One-Boat Network Compatible: Many Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.  Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and display of smart phone notifications on your Humminbird.  NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with  NMEA 2000 networking. Includes control head, transom mount transducer and mounting hardware, power cable, gimbal mounting bracket. 2-Year Limited Warranty Specifications: Transducer Included: Yes Touchscreen: No Screen Size: 9" Included Transducer: XM-9-HW-MDI-T Cartography Brand: Humminbird/Navionics Box Dimensions: 10"H x 11"W x 17"L WT: 11.1 lbs UPC: 082324055119 Brochure (pdf)

Read more less

Axiom™ Pro 16 S MFD with Single Channel High CHIRP SonarWith single channel high CHIRP Sonar and Raymarine HybridTouch control, Axiom Pro 9 is the new standard for “all-in-one” display. And with a blazing fast quad core processor, a super bright IPS display, and the smart LightHouse OS, Axiom Pro delivers a fluid and intuitive navigation experience.Axiom Pro is engineered for captains that want it all. The new standard for “all in-one” multifunction devices. And with a blazing fast quad core processor, a super bright high-definition IPS display, and the smart LightHouse OS, Axiom Pro delivers a fluid and intuitive navigation experience. Axiom Pro is easy to expand into an advanced navigation network that includes multiple Raymarine Axiom displays, CHIRP radar, Evolution autopilot, FLIR thermal night vision technology, and more.Blazing FastQuad core processor delivers instantaneous response and the ability to run multiple apps simultaneously without any slowdowns.Bold & BrightOptical bonding technology and IPS display panels give you stunning Color, clarity, and contrast in all lighting conditions. Axiom Pro looks great even through polarized sunglasses.HybridTouch™Control Axiom Pro from its multi-touch screen, its buttons and rotary knob, or any combination of both. This choice is yours.Custom KeyGet instant access to your favorite function with user-programmable Custom Key.Lighthouse 3 OSFast, fluid and easy to learn. The Lighthouse 3 interface is uncluttered and easy to personalize for your style of boating.Specifications: Screen Size: 15.6" Display Resolution: 1920 x 1080 Screen Type: Super bright IPS display with optical bonding. Multitouch support Mounting Options: Front Waterproofing: IPX6 / IPX7 Memory: 16GB Internal / x2 microSDXC slots USB: 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Voltage: 12 / 24 V dc Weight: 6.25lbs / 2.84kg Operating Temperature: -25ºC to +55ºC (13ºF to 131ºF) Wi-Fi Ethernet: 2 x 10/100 Mbits/ Network (RayNet) NMEA 0183: x2 NMEA 0183 input and x1 NMEA 0183 output (part of power cable) NMEA2000: 1 x NMEA2000 port (DeviceNet microC) Radar Compatible Thermal Night Vision Compatible Video Cameras: 1 x Analogue input (BNC). Up to 10 IP Cameras Built-in Sonar: High CHIRP Sonar built in – S models only - Uses CPT-S Transducers Only External Sonar Compatible GPS: Built-in GNSS Receiver: GPS/GLONASS/Beidou - 10Hz 167 Channel | External Accessory: GA150 (A80288) Optional Remote Controls AIS Audio Integration Autopilot Control: Evolution Autopilot Control Digital Switching: Empirbus compatible Dimensions (w x h x d): 17.8" x 10.2" x 2.72" / 452 x 258 x 69 mm In the Box: MFD Display (E70483) RayNet (F) to Raynet (F) Cable – 2M (A62361) Micro-C DeviceNet (F) to STNG (F) Cable - 1M (A06075) Suncover (A80534) Panel Seal Gasket Power / Video / NMEA0183 Cable - Straight, 1.5M (R62379) Mounting Fixings Bezel Pieces and Home / Menu Button Quick Start Guide Warranty Card Raymarine window decal Specifications: Transducer Included: No Cartography Brand: Navionics/C-Map/CMOR Screen Size: 16" Touchscreen: Yes Box Dimensions: 9"H x 14"W x 21"L WT: 16.55 lbs UPC: 723193822241

Read more less

HELIX 7 CHIRP MEGA DI GPS G4The HELIX 7 CHIRP MEGA DI GPS G4 fishfinder features MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish. Features: Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions. MEGA Down Imaging: Get unprecedented underwater clarity with coverage down to 125 feet below your boat. You'll unlock new details with up to 3X more detail than standard Down Imaging sonar. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts. AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity. Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware. 1-Year Limited Warranty Specifications: Display Size - Diagonal: 7" Display Pixel Matrix: 1024H x 600V Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz) Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz Depth-Sonar: 1,200 ft (standard transducer), 3,500 ft (optional 50 kHz) Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: XNT-9-HW-MDI-75-T Screen Size: 7" Touchscreen: No Transducer Included: Yes Box Dimensions: 5"H x 14"W x 17"L WT: 5.3 lbs UPC: 082324056147 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

HELIX 5 CHIRP/GPS Combo G3If fishing is in your DNA, there's no such thing as "too early" or "too far." The HELIX 5 Series answers the call with an uncompromising 5" widescreen, color display. This HELIX 5 CHIRP GPS G3 model features Dual Spectrum CHIRP 2D sonar, internal GPS with Humminbird Basemap, and AutoChart Live built-in, with additional compatibility for Humminbird and Navionics premium fishing charts.Features: Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts. AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity. Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware. 1-Year Limited Warranty Specifications: Display Size - Diagonal: 5" Display Pixel Matrix: 800H x 480V Sonar-Standard: Dual Spectrum CHIRP Sonar-Coverage: 20°, 42° & 60° @ -10dB Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz) Sonar-Frequencies Supported: 50/80/200 kHz Depth-Sonar: 1,200 ft (standard transducer), 3,000 ft (optional 50 kHz) Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: XNT-9-HW-T Screen Size: 5" Touchscreen: No Transducer Included: Yes Box Dimensions: 5"H x 10"W x 16"L WT: 3.35 lbs UPC: 082324056291

Read more less

HELIX 5 CHIRP DI GPS G3If fishing is in your DNA, there's no such thing as "too early" or "too far." The HELIX 5 Series answers the call with an uncompromising 5" widescreen, color display. This HELIX 5 CHIRP DI GPS G3 model features Dual Spectrum CHIRP 2D sonar, internal GPS with Humminbird Basemap, and AutoChart Live built-in, with additional compatibility for Humminbird and Navionics premium fishing charts.Features: Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions. CHIRP Down Imaging: Filter out noise and clutter for a clear view beneath your boat. CHIRP Digital Sonar processing of Down Imaging Sonar means that you'll see great detail to make finding the fish simple and easy. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts. AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity. Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware. 1-Year Limited Warranty Specifications: Display Size - Diagonal: 5" Display Pixel Matrix: 800H x 480V Sonar-Standard: Dual Spectrum CHIRP, CHIRP Down Imaging Sonar-Coverage: 20°, 42° & 60° @ -10dB Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz) Sonar-Frequencies Supported: 50/83/200/455 kHz Depth-Sonar: 1,200 ft (standard transducer), 3,000 ft (optional 50 kHz) Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: XNT-9-HW-DI-T Screen Size: 5" Touchscreen: No Transducer Included: Yes Box Dimensions: 5"H x 10"W x 16"L WT: 5 lbs UPC: 082324056321

Read more less
