Marine Navigation & Instruments - GPS - Fishfinder Combos

Axiom 2 Pro 16 S 15.6" Chartplotter/Fishfinder - No Chart or TransducerAxiom 2 Pro combines chartplotter, sonar, radar, autopilot, and video into a powerful all-in-one navigation system. With Axiom 2 Pro, you can navigate smarter and expand your system, thanks to the super intuitive LightHouse operating system. Plan your next trip and get underway confidently with Axiom 2 Pro’s HybridTouch™ — a simple touchscreen and keypad experience. Axiom 2 Pro S chartplotters feature built-in single channel High CHIRP sonar- the ideal sonar solution for reliable depth sounding and underwater exploration. Available in 9, 12, or 16-inch display sizes, Axiom Pro 2 is the perfect cruising companion.Features: Get underway faster with a fast 6-core processor HydroTough™ nano-coating repels water for reliable touchscreen control and superior sunlight visibility Confident HybridTouch™ control plus an interchangeable autopilot keypad or user-programable soft keys Integrated High CHIRP sonar with transom, in-hull and low-profile through-hull CPT-S series transducer options Smart backlighting and an ambient light sensor automatically adjust display brightness for day and evening Create your own Axiom 2 Pro system with multiple networked Axiom displays Stay entertained with streaming Apps and Axiom 2 Pro’s HDMI and audio output for remote displays and marine entertainment systems Specifications:Connections: Digital Video & Audio Out Connection: HDMI Out Micro connector type D’ External GPS Antenna Connection: TNC connector Accessory connection: USB Micro B (rear–charging, external storage device or RCR-SD/USB Accessory (A80440) Ethernet connection: RayNet (10/100/1,000 Mbits/s) x2 External storage: MicroSD card slot x2 (front)  Chart options:  Navionics+ or Navionics Platinum or C-map 4D Software, Lighthouse North America NMEA 2000 connection: DeviceNet connector Analog video connections: BNC Analog video input (on power cable) Wireless connections: Bluetooth: V4.0, Wi-Fi: 802.11/b/g/n Transducer connection: 25-pin RealVision type connector (requires adaptor cable) Audio connections: Left and Right RCA connectors via Power/Video/Audio cable GPS:GNSS compatibility: GPS, Galileo, GLONASS, BeidouSonar: Channels:  CHIRP conical sonar ( Uses CPT-S Transducers with adapter cable A80490) Depth range:  0.6 m (2 ft) to 274 m (900 ft) Depending on water conditions Lighting:Illumination:   Axiom 2 Pro 9 1300 nits / 1300 cd/m2, Axiom 2 Pro 12 & 16 1200 nits / 1200 cd/m2Storage:Internal storage: 64 GB Solid State Specifications: Cartography Brand: Navionics/C-Map Screen Size: 16" Touchscreen: Yes Transducer Included: No Box Dimensions: 10"H x 14"W x 22"L WT: 19.6 lbs UPC: 723193843550

Read more less

Axiom 2 Pro 16 S 15.6" Chartplotter/Fishfinder with Lighthouse North America Chart - No TransducerAxiom 2 Pro combines chartplotter, sonar, radar, autopilot, and video into a powerful all-in-one navigation system. With Axiom 2 Pro, you can navigate smarter and expand your system, thanks to the super intuitive LightHouse operating system. Plan your next trip and get underway confidently with Axiom 2 Pro’s HybridTouch™ — a simple touchscreen and keypad experience. Axiom 2 Pro S chartplotters feature built-in single channel High CHIRP sonar- the ideal sonar solution for reliable depth sounding and underwater exploration. Available in 9, 12, or 16-inch display sizes, Axiom Pro 2 is the perfect cruising companion.Features: Get underway faster with a fast 6-core processor HydroTough™ nano-coating repels water for reliable touchscreen control and superior sunlight visibility Confident HybridTouch™ control plus an interchangeable autopilot keypad or user-programable soft keys Integrated High CHIRP sonar with transom, in-hull and low-profile through-hull CPT-S series transducer options Smart backlighting and an ambient light sensor automatically adjust display brightness for day and evening Create your own Axiom 2 Pro system with multiple networked Axiom displays Stay entertained with streaming Apps and Axiom 2 Pro’s HDMI and audio output for remote displays and marine entertainment systems Specifications:Connections: Digital Video & Audio Out Connection: HDMI Out Micro connector type D’ External GPS Antenna Connection: TNC connector Accessory connection: USB Micro B (rear – charging, external storage device or RCR-SD/USB Accessory (A80440) Ethernet connection: RayNet (10/100/1,000 Mbits/s) x2 External storage: MicroSD card slot x2 (front)  Chart options:  Navionics+ or Navionics Platinum or C-map 4D Software Lighthouse North America Chart included NMEA 2000 connection: DeviceNet connector Analog video connections: BNC Analog video input (on power cable) Wireless connections: Bluetooth: V4.0, Wi-Fi: 802.11/b/g/n Transducer connection: 25-pin RealVision type connector (requires adaptor cable) Audio connections: Left and Right RCA connectors via Power/Video/Audio cable GPS:GNSS compatibility: GPS, Galileo, GLONASS, BeidouSONAR: Channels:  CHIRP conical sonar ( Uses CPT-S Transducers with adapter cable A80490) Depth range:  0.6 m (2 ft) to 274 m (900 ft) Depending on water conditions LIGHTING:Illumination:   Axiom 2 Pro 9 1300 nits / 1300 cd/m2, Axiom 2 Pro 12 & 16 1200 nits / 1200 cd/m2STORAGE:Internal storage: 64 GB Solid State Specifications: Cartography Brand: Navionics/C-Map Screen Size: 16" Touchscreen: Yes Transducer Included: No Box Dimensions: 1"H x 4"W x 5"L WT: 19.65 lbs

Read more less

SOLIX® 10 CHIRP MEGA SI+ G3 CHO Display OnlyThe SOLIX 10 CHIRP MSI+ G3 combines cutting-edge technologies like MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar and AutoChart Live on an ultra-clear Cross Touch® display. Take full advantage of the generous 10.1" touchscreen display with customizable views and settings that allow you to see multiple technologies at once and find what you want quickly via the convenient side bar menu. Leverage the networking power of built-in Wi-Fi and NMEA 2000® connectivity, as well as Bluetooth® and Ethernet connections for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota and Cannon. This CHO (Control Head Only) model is the perfect pairing for those anglers looking to select their own transducer or pair this model with MEGA 360 Imaging or a Built-in MEGA Imaging trolling motor from Minn Kota® Features: Control Head Only Model: This model does not include a transducer. This CHO model is a great choice for those looking to connect to connect to Built-in MEGA Imaging on Minn Kota trolling motors, accessory transducer options like MEGA 360 Imaging, or share sonar data from an existing Humminbird Ethernet network.  Cross Touch® Interface: Control your fish finder using the touchscreen or the keypad—it's up to you. Any menu navigation you can do on the touchscreen can also be done on the keypad, providing quick and intuitive access to technologies on your terms, no matter your situation and conditions.  Customized Experience:  Utilize an intuitive user interface and sidebar menu which provide customizable settings and view combinations to make your fishing experience all your own. NEW Dual Core Processor: Perform any task with speed and ease, thanks to the ultra-responsive interface and upgraded processing power.   Industry-leading Humminbird sonar: Equipped with MEGA Side Imaging+, MEGA Down Imaging+ and Dual Spectrum CHIRP sonar to keep you on the fish. MEGA Imaging+ provides views up to 250' under and out to either side of your boat and Dual Spectrum CHIRP shows exceptional 2D sonar with superior target separation and fish clarity.  Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.  AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat.  Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity. One-Boat Network Compatible: Many Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.  Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and display of smart phone notifications on your Humminbird.  NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking. Compatible with CZone® Contact 6, Contact 6 Plus and digital switching devices Includes control head, power cable and gimbal mounting bracket. This CHO model does not include a transducer, allowing you to pick the best fit for your rigging needs.  Product comes with 2-Year Limited Warranty. Specifications: Cartography Brand: Humminbird/Navionics Touchscreen: Yes Screen Size: 10" Transducer Included: No Box Dimensions: 10"H x 13"W x 19"L WT: 10.65 lbs UPC: 082324055836 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

HELIX 10® MEGA DI+ GPS G4N CHO Display OnlyThe HELIX 10 CHIRP MDI+ GPS G4N CHO features a 10.1" display, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 10 includes standard features such as AutoChart Live, Wi-Fi and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota and Cannon. This CHO (Control Head Only) model allows you to pick the right accessory transducer for your needs, including compatibility with Minn Kota Built-in MEGA Imaging trolling motors. Features: Control Head Only Model: This model does not include a transducer. This CHO model is a great choice for those looking to connect to connect to Built-in MEGA Imaging on Minn Kota trolling motors, accessory transducer options like MEGA 360 Imaging, or share sonar data from an existing Humminbird Ethernet network.  Keypad control: Master HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft key controls that allow you to reliably operate your fish finder in any condition. MEGA Down Imaging+: Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below your boat. You'll unlock more fish and structure with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.  AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat.  Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity. One-Boat Network Compatible: Many Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.  Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and display of smart phone notifications on your Humminbird.  NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking. Includes control head, power cable, gimbal mounting bracket. This CHO model does not include a transducer, allowing you to pick the best fit for your rigging needs. 2-Year Limited Warranty Specifications: Transducer Included: No Touchscreen: No Screen Size: 10" Cartography Brand: Humminbird/Navionics Box Dimensions: 11"H x 13"W x 20"L WT: 10.95 lbs UPC: 082324055058 Brochure (pdf)

Read more less

HELIX 12 CHIRP MEGA MSI+ GPS G4NThe HELIX 12 CHIRP MSI+ GPS G4N features a 12.1" display, MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar, and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 12 includes standard features such as AutoChart Live, Wi-Fi, and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota, and Cannon.FeaturesKeypad ControlMaster HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft-key controls that allow users to reliably operate the fish finder in any conditions.MEGA Side Imaging+See the world below like never before with a crystal-clear side imaging view out to 200 feet on either side of the boat. Users will unlock more fish and structures with 20% more detail and 60% more range capability than MEGA Side Imaging sonar.MEGA Down Imaging+Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below the boat. Users will unlock more fish and structures with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar.Dual Spectrum CHIRP SonarBefore users cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by Humminbird's proprietary Low-Q CHIRP transducer, the Dual Spectrum offers two ways to search: wide mode for maximum coverage and narrow mode for focusing on the slightest detail.Internal GPS and Humminbird BasemapHumminbird's enhanced basemap provides users with a clear view of underwater terrain and surrounding points of interest, so users can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.Premium Chart CompatibleHumminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as compatible Navionics® charts.AutoChart LiveCreate real-time maps of the fishing spots with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as users drive the boat. It comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually unlimited AutoChart Live mapping capacity.One-Boat Network CompatibleMany Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Users can take advantage of the time on the water by using the exclusive boat control and fish-catching features of the One-Boat Network.Ethernet NetworkingHigh-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.BluetoothTake control right from the screen of a Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and the display of smartphone notifications on the Humminbird.NMEA 2000 Networking Built-inConnect an accessory NMEA 2000 network to a control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.Includes:Includes control head, screen cover, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.Specifications: Series: HELIX Display Size – Diagonal: 12.1 in Display Pixel Matrix: 1280H x 800V Sonar-Standard: Dual Spectrum CHIRP / MEGA Down Imaging+ / MEGA Side Imaging+ Sonar-Coverage: 20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP Live Sonar Coverage: 20 degrees x 120 degrees CHIRP - Frequencies Supported: Full Mode (150-220 kHz) / Narrow Mode (180-240 kHz) / Wide Mode (140-200 kHz) Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz Depth-Sonar: 1,200 ft (standard transducer) / 3,500 ft (optional 50 kHz) CHIRP - Imaging-Frequencies Supported: 455 kHz DI+ (435-535 kHz) / 455 kHz SI+ (405-505 kHz) / 800 kHz DI+ (800-860 kHz) / 800 kHz SI+ (780-840 kHz) / MEGA DI+ (1100-1200 kHz) / MEGA SI+ (1050-1175 kHz) Depth-Down Imaging: 125 ft (800 kHz) / 200 ft (MEGA) / 400 ft (455 kHz) Range-Side Imaging (Side-To-Side): 800 ft (455 kHz) / 250 ft (800 kHz) / 400 ft (MEGA) Memory Card Slot: Dual SD Compatible With: AIS / AutoPilot / Minn Kota US2 Sonar / Minn Kota Built-In MEGA DI / Minn Kota Built-In MEGA SI / MEGA Live / One-Boat Network / Minn Kota i-Pilot Link / Minn Kota Talon/Raptor/ NMEA 2000 Power Draw; 3.2 Amps Power Input: 10.8-20 VDC Power Output Peak-to-Peak; 8000 Watts Power Output RMS: 1000 Watts Screen Snap Shot: Included Sonar Recording: Included Mount-Standard: Gimbal Mount-Standard Size: 14.86 in W x 8.83 in H x 4.25 in D Mount-Optional: In-Dash Mounting Kit Mount-Optional Size: 14.86 in W x 8.52 in H x 1.36 in D Transducer Mount Location: Transom GPS Chartplotting: Included GPS Receiver: Internal GPS Trackplotting: Included Waypoints, Routes, Tracks/Points: 2,750, 47, 50/20,000 360 Imaging Compatibility: Yes LakeMaster Compatibility: Yes Coast Master Compatibility: Yes Navionics Gold/HotMaps Compatibility: Yes Navionics Platinum + Compatibility: Yes Platinum Compatibility: Yes Minn Kota i-Pilot Link Compatibility: Yes Minn Kota Talon Shallow Water Anchor Compatibility: Yes Radar Compatibility: Yes 5-Port Ethernet Switch Compatibility: Yes AIS Compatibility: Optional Autopilot Compatibility: Yes Heading Sensor GPS Compatibility: Yes NMEA2000: Included Target Separation: 2.5 in Interference Rejection: 6 Modes Noise Rejection: 10 Steps Upgradable Software: Yes View Preset Keys: Yes X-Press Menu System: Yes Custom Digital Readout: Yes Custom View Selections: Yes Display Colors Grayscale: 16-Bit Display Type: Color TFT Speed: Included Temperature: Built In Temperature Alarm: Yes Temperature Graph: Yes Transducer Included: XM 9 HW MSI T HDMI Compatible: No MEGA Live Compatibility: Yes Humminbird Basemap: Included Warranty: Two-Year Warranty Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: XM-9-HW-MSI-T Screen Size: 12" Touchscreen: No Transducer Included: Yes Box Dimensions: 11"H x 13"W x 20"L WT: 15.75 lbs UPC: 082324058257

Read more less

SOLIX® 15 CHIRP MEGA SI+ G3The SOLIX 15 CHIRP MSI+ G3 combines cutting-edge technologies like MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar and AutoChart Live on an ultra-clear Cross Touch® display. Take full advantage of the generous 15.4" touchscreen display with customizable views and settings that allow you to see multiple technologies at once and find what you want quickly via the convenient side bar menu. Leverage the networking power of built-in Wi-Fi and NMEA 2000®, as well as Bluetooth® and Ethernet connections for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota and Cannon. Features: Cross Touch® Interface: Control your fish finder using the touchscreen or the keypad—it's up to you. Any menu navigation you can do on the touchscreen can also be done on the keypad, providing quick and intuitive access to technologies on your terms, no matter your situation and conditions.  Customized Experience:  Utilize an intuitive user interface and sidebar menu which provide customizable settings and view combinations to make your fishing experience all your own. NEW Dual Core Processor: Perform any task with speed and ease, thanks to the ultra-responsive interface and upgraded processing power.   Industry-leading Humminbird sonar: Equipped with MEGA Side Imaging+, MEGA Down Imaging+ and Dual Spectrum CHIRP sonar to keep you on the fish. MEGA Imaging+ provides views up to 250' under and out to either side of your boat and Dual Spectrum CHIRP shows exceptional 2D sonar with superior target separation and fish clarity.  Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.  AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat.  Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity. One-Boat Network Compatible: Many Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.  Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and display of smart phone notifications on your Humminbird.  NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking. Compatible with CZone® Contact 6, Contact 6 Plus and digital switching devices Includes control head, transom mount transducer, mounting hardware, power cable, and gimbal mounting bracket.  Product comes with 2-Year Limited Warranty. Specifications: Transducer Included: Yes Touchscreen: Yes Screen Size: 15" Included Transducer: XM-14-HW-MSI-T Cartography Brand: Humminbird/Navionics Box Dimensions: 12"H x 15"W x 22"L WT: 10 lbs UPC: 082324054877 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

HELIX 15® CHIRP MEGA SI+ GPS G4NThe HELIX 15 CHIRP MSI+ GPS G4N features a 15.4" display, MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 15 includes standard features such as AutoChart Live, Wi-Fi and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota and Cannon.Features: Keypad control: Master HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft key controls that allow you to reliably operate your fish finder in any condition. MEGA Side Imaging+: See the world below like never before with a crystal-clear Side Imaging viewing out to 200 feet on either side of your boat. You'll unlock more fish and structure with 20% more detail and 60% more range capability than MEGA Side Imaging sonar. MEGA Down Imaging+: Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below your boat. You'll unlock more fish and structure with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.  AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat.  Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity. One-Boat Network Compatible: Many Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.  Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and display of smart phone notifications on your Humminbird.  NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking. Includes control head, transom mount transducer and mounting hardware, power cable, gimbal mounting bracket. 2-Year Limited Warranty Specifications: Transducer Included: Yes Touchscreen: No Included Transducer: XM-9-HW-MSI-T Cartography Brand: Humminbird/Navionics Screen Size: 15" Box Dimensions: 12"H x 15"W x 22"L WT: 18.4 lbs UPC: 082324054792 Brochure (pdf)

Read more less

HELIX 15® CHIRP MEGA SI+ GPS G4N CHO Display OnlyThe HELIX 15 CHIRP MSI+ GPS G4N CHO features a 15.4" display, MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 15 includes standard features such as AutoChart Live, Wi-Fi and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota and Cannon. This CHO (Control Head Only) model allows you to pick the right accessory transducer for your needs, including compatibility with Minn Kota Built-in MEGA Imaging trolling motors. Features: Control Head Only Model: This model does not include a transducer. This CHO model is a great choice for those looking to connect to connect to Built-in MEGA Imaging on Minn Kota trolling motors, accessory transducer options like MEGA 360 Imaging, or share sonar data from an existing Humminbird Ethernet network.  Keypad control: Master HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft key controls that allow you to reliably operate your fish finder in any condition. MEGA Side Imaging+: See the world below like never before with a crystal-clear Side Imaging viewing out to 200 feet on either side of your boat. You'll unlock more fish and structure with 20% more detail and 60% more range capability than MEGA Side Imaging sonar. MEGA Down Imaging+: Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below your boat. You'll unlock more fish and structure with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.  AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat.  Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity. One-Boat Network Compatible: Many Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.  Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and display of smart phone notifications on your Humminbird.  NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking. Includes control head, power cable, gimbal mounting bracket. This CHO model does not include a transducer, allowing you to pick the best fit for your rigging needs. 2-Year Limited Warranty Specifications: Screen Size: 15" Cartography Brand: Humminbird/Navionics Transducer Included: No Touchscreen: No Box Dimensions: 12"H x 15"W x 22"L WT: 16.15 lbs UPC: 082324055782 Brochure (pdf)

Read more less

HELIX 10 CHIRP MEGA MSI+ GPS G4N CHOThe HELIX 10 CHIRP MSI+ GPS G4N CHO features a 10.1" display, MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar, and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 10 includes standard features such as AutoChart Live, Wi-Fi and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota, and Cannon.This CHO (Control Head Only) model allows users to pick the right accessory transducer for almost any need, including compatibility with Minn Kota Built-in MEGA Imaging trolling motors.FeaturesControl Head Only ModelThis model does not include a transducer. This CHO model is a great choice for those looking to connect to built-in MEGA Imaging on Minn Kota trolling motors, accessory transducer options like MEGA 360 Imaging, or share sonar data from an existing Humminbird Ethernet network.Keypad ControlMaster HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft-key controls that allow users to reliably operate the fish finder in any conditions.MEGA Side Imaging+See the world below like never before with a crystal-clear side imaging view out to 200 feet on either side of the boat. Users will unlock more fish and structures with 20% more detail and 60% more range capability than MEGA Side Imaging sonar.MEGA Down Imaging+Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below the boat. Users will unlock more fish and structures with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar.Dual Spectrum CHIRP SonarBefore users cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by Humminbird's proprietary Low-Q CHIRP transducer, the Dual Spectrum offers two ways to search: wide mode for maximum coverage and narrow mode for focusing on the slightest detail.Internal GPS and Humminbird BasemapHumminbird's enhanced basemap provides users with a clear view of underwater terrain and surrounding points of interest, so users can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.Premium Chart CompatibleHumminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as compatible Navionics® charts.AutoChart LiveCreate real-time maps of the fishing spots with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as users drive the boat. It comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually unlimited AutoChart Live mapping capacity.One-Boat Network CompatibleMany Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Users can take advantage of the time on the water by using the exclusive boat control and fish-catching features of the One-Boat Network.Ethernet NetworkingHigh-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.BluetoothTake control right from the screen of a Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and the display of smartphone notifications on the Humminbird.NMEA 2000 Networking Built-inConnect an accessory NMEA 2000 network to a control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.Includes:Includes control head, screen cover, power cable, gimbal mounting bracket, and mounting hardware. This CHO model does not include a transducer, allowing users to pick the best fit for their rigging needs.Specifications: Series: HELIX Display Size – Diagonal: 10.1 in Display Pixel Matrix: 1024H x 600V Sonar-Standard: Dual Spectrum CHIRP / MEGA Down Imaging+ / MEGA Side Imaging+ Sonar-Coverage: 20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP Live Sonar Coverage: 20 degrees x 120 degrees CHIRP - Frequencies Supported: Full Mode (150-220 kHz) / Narrow Mode (180-240 kHz) / Wide Mode (140-200 kHz) Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz Depth-Sonar: 1,200 ft (standard transducer) / 3,500 ft (optional 50 kHz) CHIRP - Imaging-Frequencies Supported: 455 kHz DI+ (435-535 kHz) / 455 kHz SI+ (405-505 kHz) / 800 kHz DI+ (800-860 kHz) / 800 kHz SI+ (780-840 kHz) / MEGA DI+ (1100-1200 kHz) / MEGA SI+ (1050-1175 kHz) Depth-Down Imaging: 125 ft (800 kHz) / 200 ft (MEGA) / 400 ft (455 kHz) Range-Side Imaging (Side-To-Side): 800 ft (455 kHz) / 250 ft (800 kHz) / 400 ft (MEGA) Memory Card Slot: Dual SD Compatible With: AIS / AutoPilot / Minn Kota US2 Sonar / Minn Kota Built-In MEGA DI / Minn Kota Built-In MEGA SI / MEGA Live / One-Boat Network / Minn Kota i-Pilot Link / Minn Kota Talon/Raptor / NMEA 2000 Power Draw: 2.7 Amps Power Input: 10.8-20 VDC Power Output Peak-to-Peak: 8000 Watts Power Output RMS: 1000 Watts Screen Snap Shot: Included Sonar Recording: Included Mount-Standard: Gimbal Mount-Standard Size: 13.44 in W x 7.5 in H x 4.2 in D Mount-Optional: In-Dash Mounting Kit Mount-Optional Size: 13.44 in W x 7.12 in H x 1.32 in D Transducer Mount Location: N/A GPS Chartplotting: Included GPS Receiver: Internal GPS Trackplotting: Included Waypoints, Routes, Tracks/Points: 2,750, 47, 50/20,000 360 Imaging Compatibility: Yes LakeMaster Compatibility: Yes Coast Master Compatibility: Yes Navionics Gold/HotMaps Compatibility: Yes Navionics Platinum + Compatibility: Yes Platinum Compatibility: Yes Minn Kota i-Pilot Link Compatibility: Yes Minn Kota Talon Shallow Water Anchor Compatibility: Yes Radar Compatibility: Yes 5-Port Ethernet Switch Compatibility: Yes AIS Compatibility: Optional Autopilot Compatibility: Yes Heading Sensor GPS Compatibility: Yes NMEA2000: Included Target Separation: 2.5 in Interference Rejection: 6 Modes Noise Rejection: 10 Steps Upgradable Software: Yes View Preset Keys: Yes X-Press Menu System: Yes Custom Digital Readout: Yes Custom View Selections: Yes Display Colors Grayscale: 16-Bit Display Type: Color TFT Speed: Included Temperature: Built In Temperature Alarm: Yes Temperature Graph: Yes Transducer Included: N/A HDMI Compatible: No MEGA Live Compatibility: Yes Humminbird Basemap: Included Warranty: Two-Year Warranty Specifications: Cartography Brand: Humminbird/Navionics Included Transducer: Not Included Screen Size: 10" Touchscreen: No Transducer Included: No Box Dimensions: 10"H x 13"W x 19"L WT: 11.1 lbs UPC: 082324058233

Read more less

HELIX 12® CHIRP MEGA DI+ GPS G4N CHO Display OnlyThe HELIX 12 CHIRP MDI+ GPS G4N CHO features a 12.1" display, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 12 includes standard features such as AutoChart Live, Wi-Fi and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota and Cannon. This CHO (Control Head Only) model allows you to pick the right accessory transducer for your needs, including compatibility with Minn Kota Built-in MEGA Imaging trolling motors. Features: Control Head Only Model: This model does not include a transducer. This CHO model is a great choice for those looking to connect to connect to Built-in MEGA Imaging on Minn Kota trolling motors, accessory transducer options like MEGA 360 Imaging, or share sonar data from an existing Humminbird Ethernet network.  Keypad control: Master HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft key controls that allow you to reliably operate your fish finder in any condition. MEGA Down Imaging+: Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below your boat. You'll unlock more fish and structure with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar. Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail. Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S. Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.  AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat.  Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity. One-Boat Network Compatible: Many Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.  Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar. Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and display of smart phone notifications on your Humminbird.  NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking. Includes control head, power cable, gimbal mounting bracket. This CHO model does not include a transducer, allowing you to pick the best fit for your rigging needs. 2-Year Limited Warranty Specifications: Cartography Brand: Humminbird/Navionics Transducer Included: No Touchscreen: No Screen Size: 12" Box Dimensions: 10"H x 13"W x 19"L WT: 12.95 lbs UPC: 082324055140 Brochure (pdf)

Read more less

TZT10X 10" Chartplotter/FishfinderThe hybrid control 10” TZT10X incorporates all of NavNet TZtouchXL's multi-touch capabilities with Furuno’s RotoKey™ control knob and dedicated buttons, making navigation intuitive and easy under any sea conditions.The TZT10X incorporates a powerful internal 1kW dual channel TruEcho CHIRP™ Fish Finder* designed to operate across a wide range of frequencies. For those who want to go even deeper, the 2kW/3kW DFF3-UHD TruEcho CHIRP™ Network Fish Finder delivers the ability to penetrate the deepest waters to find a catch. Also, with the BT-5 Booster Box, users can boost that output power up to 5 or 10 kW to take advantage of high-power transducer options that will unveil the deepest waters like users never experienced before.Features: 10 in. display with hybrid controls TZ MAPS for highly detailed navigation and fishing charts Purchase and update charts directly from MFD with an internet connection Powerful hexacore processor for rapid response Video converter kits stream compatible sonar video data directly to TZtouchXL MFD Furuno’s exclusive Fish-It, Drift-It, & Follow-It features save time and fuel and increase fish catch Built-in Dual Channel 1kW TruEcho CHIRP™ & CW Fish Finder Built-in 235kHz or 455kHz CHIRP Side-Scan Built-In CHIRP Side-ScanFuruno’s CHIRP Side-Scan for NavNet TZT10X scans both port and starboard, illuminating the shape of the bottom structure in high definition. CHIRP Side-Scan 6 reveals the shape of fish targets and fish-hoarding structure on each side of the vessel. CHIRP from 235kHz or 445kHz center frequencies with thru-hull, paired, or transom mount transducer options.TZ MAPSOne of the most exciting TZtouchXL features is a chart offering called TZ MAPS. Not only are these some of the most detailed charts in the industry, but TZ MAPS users are in complete control of the chart content they want to download, such as raster or vector charts, satellite photos, and bathymetric data. Custom user objects can be shared with other registered TZ MAPS users through TimeZero's moderated service. Since custom objects reside on their chart layer on the TZtouchXL MFD, they can easily be displayed or hidden as desired. Additionally, for the first time, customers can purchase and update charts directly on their TZtouchXL MFD!BathyVisionOne of the most groundbreaking aspects of TZ MAPS is called BathyVision, providing amazingly detailed bathymetric data that can be configured to an incredible resolution of a mere 3 inches between contours! That's 3 times better than any other bathymetric chart currently on the market. BathyVision data, along with custom depth shading, can easily be overlaid on TZ MAPS navigation charts to create the ultimate "Fishing Charts"!AI RoutingTZ MAPS unlocks the ability to utilize the powerful AI Routing function that intelligently plans out routes, taking into consideration the boat's draft and navigational obstacles. AI Routing takes traditional auto-routing to another level by automatically creating suggested routes based on varying navigational conditions.Risk Visualizer & AI Avoidance RouteWhen connected to an NXT radar, two powerful safety features are unlocked: the Risk Visualizer and the AI Avoidance Route tool. Risk Visualizer provides a 360° visual representation of the potential collision risks of approaching objects around the vessel. Dynamic icons are automatically created for targets with the highest probability of collision, ensuring the captain has the necessary information to maintain safe distances when passing. The AI Avoidance Route function processes all available information provided to dynamically provide a safe route around those hazards, which can be sent to a Furuno NavPilot autopilot with a single tap.Enhanced User Interface for Ease of Use & CustomizabilityIn addition to offering all the great features that make NavNet super simple to operate, NavNet TZtouchXL MFDs also deliver BIG power and versatility! Users can now configure their MFD in many ways, thanks to an increased number of Page Builder configurations from four (4) to ten (10) custom combinations. Additionally, users can now custom-build a 6-way screen split of various components and sensors.Match all those great screen layout options with enhanced Edge-Swipe feature access for the smoothest, easiest, and very best user experience Furuno has ever delivered! This is all driven by the most system memory and the highest level of processing power Furuno has ever integrated into a NavNet MFD. Specifications:Display Unit: Type: Color TFT multi-touch IPS LCD Screen Size: 10.1" Wide Screen Resolution: WUXGA 1920 x 1200 Screen Brightness: 900 cd/m2 (typical) Display Colors: 16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder) Language: Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, Polish GPS/WAAS: Receiver Type: GPS: 72 channels, SBAS: 1 channel (C/A mode, WAAS) Receiving Frequency: L1 (1575.42 MHz) Time to First Fix: 100 s (cold start) Accuracy: 10 m (GPS), 7 m (MSAS), 3 m (WAAS) Position Update Interval: 100 ms or 10 Hz Chartplotter: Cartography: TZ MAPS, MM3 Vector, and CMOR capable (U.S. only) Memory Capacity: 30,000 user points, 100,000 points for ship's tracks, 200 planned routes (500 points per route) Alarms: Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge* (*external data required) Radar: Display Modes: Head-up, North-up*   *Heading input required.  Echo Trails: Interval: 15 s, 30 s, 1 min, 3 mins, 6 mins, 15 mins, 30 mins, and continuous (Heading input required)  Target Tracking: 100 ARPA Targets (Radar dependent) with fully automatic target acquisition (Heading input required)  Radar Alarms: Guard Zone, CPA/TCPA, Video, Azimuth, Heading Line  Fishfinder: Transmit Frequency*: CW: 50/200 kHz, CHIRP: 40 kHz to 240 kHz (Low, Medium, and High) Transducer: 300/600 W or 1 kW*   *Matching box MB1100 required for some transducers Display Range: 2 to 1,200 m; shift 0 to 1,200 m (1,200-2,400m / 4,000-8,000ft)  Extension Mode: ACCU-FISH™, A-Scope, Auto (Fishing/Cruising), Bottom Discrimination, TruEcho CHIRP™ (with compatible transducer)  Picture Advance: 8 steps: x4, x2, x1, 1/2, 1/4, 1/8, 1/16, stop  Fish Finder Alarms: Fish School, Fish School for the bottom lock  Side-Scan:  Transmit Frequency*: CHIRP: 220-240KHz/445-465KHz Transducer: 225kHz: 225T-PR904, 225T-SS904. 225T-TM904 / 455kHz: 455T-PR903, 455T-SS903. 455T-TM903  Display Range: 750 feet to each side  Display Colors: Green, Blue, Amber, White  Display Screen Sizes: Full Screen, 1/2 Screen, 1/4 Screen, 1/6 Screen Full Screen, 1/2 Screen, 1/4 Screen, 1/6 Screen  Direct Connect to MFD: Direct connect to TZ10X, TZT13X, TZT16X only; may be networked with TZT22X/TZT24X Interface: NMEA200: 1 Port Input: 065280, 126992/993/996, 127237/245/250/251/257/488/489/505, 128259/267, 129025/026/029/330/038/039/040/041/291/538/540, 129793/794/798/801/802/808/809/810, 130306/310/311/312/313/314/316/576/577/578, 130817/818/820/822/823/826/827/828/880 Output: 126992/993/996, 127250/251/257/258, 128259/267/275, 129025/026/029/033/283/284/285, 130306/310/311/312/313/314/316 NMEA0183: 1 Serial Output Port Output: AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB, RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA LAN: 1 Port (1000 BASE-T) USB: 1 Port (USB 3.0) for control unit Video I/O: Input: 1 port (NTSC/PAL) AUX I/O: 2 Ports (Event Switch and External Power Switch) SD Card Slot: 1 Slot (Micro SDXC, rear) Wireless LAN: IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max Transducer Connection: 1 Port 12 pin for CHIRP/CW, 1 Port 12 pin for Side-Scan Environment: Temperature (IEC60945)-15°C to +55° C Relative Humidity: 93% or less at +40° C Waterproofing: IP56 Power:12-24 VDCThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Screen Size: 10" Box Dimensions: 13"H x 14"W x 18"L WT: 15.1 lbs Brochure (pdf)

Read more less

Axiom Pro 12 RVX MFD w/RealVision 3D and 1kW CHIRP Sonar - Navionics+ ChartWith RealVision 3D and 1kW CHIRP Sonar and Raymarine HybridTouch control, Axiom Pro 12 is the new standard for “all-in-one” display. And with a blazing fast quad core processor, a super bright IPS display, and the smart LightHouse OS, Axiom Pro delivers a fluid and intuitive navigation experience.Axiom Pro is engineered for captains that want it all. The new standard for “all in-one” multifunction devices. And with a blazing fast quad core processor, a super bright high-definition IPS display, and the smart LightHouse OS, Axiom Pro delivers a fluid and intuitive navigation experience. Axiom Pro is easy to expand into an advanced navigation network that includes multiple Raymarine Axiom displays, CHIRP radar, Evolution autopilot, FLIR thermal night vision technology, and more.Blazing FastQuad core processor delivers instantaneous response and the ability to run multiple apps simultaneously without any slowdowns.Bold & BrightOptical bonding technology and IPS display panels give you stunning Color, clarity, and contrast in all lighting conditions. Axiom Pro looks great even through polarized sunglasses.HybridTouch™Control Axiom Pro from its multi-touch screen, its buttons and rotary knob, or any combination of both. This choice is yours.Custom KeyGet instant access to your favorite function with user-programmable Custom Key.Lighthouse 3 OSFast, fluid and easy to learn. The Lighthouse 3 interface is uncluttered and easy to personalize for your style of boating.Specifications: Screen Size: 12.1" Display Resolution: 1280 x 800 Screen Type: Super bright IPS display with optical bonding. Multitouch support Mounting Options: Front and trunnion mount Front Waterproofing: IPX6 / IPX7 Memory: 16GB Internal / x2 microSDXC slots USB: 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Voltage: 12 / 24 V dc Weight: 4.5lbs / 2.04kg Operating Temperature: -25ºC to +55ºC (13ºF to 131ºF) Wi-Fi Ethernet: 2 x 10/100 Mbits/ Network (RayNet) NMEA 0183: x2 NMEA 0183 input and x1 NMEA 0183 output (part of power cable) NMEA2000: 1 x NMEA2000 port (DeviceNet microC) Radar Compatible Thermal Night Vision Compatible Video Cameras: 1 x Analogue input (BNC). Up to 10 IP Cameras Built-in Sonar: RealVision 3D and 1kW CHIRP Sonar Built-In - RVX Models Only External Sonar Compatible GPS: Built-in GNSS Receiver: GPS/GLONASS/Beidou - 10Hz 167 Channel | External Accessory: GA150 (A80288) Optional Remote Controls AIS Audio Integration Autopilot Control: Evolution Autopilot Control Digital Switching: Empirbus compatible Dimensions (w x h x d): 14.1" x 9.17" x 2.56" / 358 x 223 x 65 mm The Axiom Pro 12 RVX includes surface and trunnion mounting kits and hardware, suncover, power/video/NMEA0183 cable, micro-C DeviceNet (F) to STNG (F) 1M cable, Raynet (F) to Raynet (F) 2M cable and installation instructions. Navionics+ Chart Specifications: Cartography Brand: Navionics/C-Map/CMOR Screen Size: 12" Touchscreen: Yes Transducer Included: No Box Dimensions: 1"H x 4"W x 6"L WT: 14.8 lbs Brochure (pdf)

Read more less
