Marine Navigation & Instruments

Voyager CompassFeatures: 3″ (76 mm) CombiDial Adjustable and Removable with Bracket and Thumbscrews Exclusive Built-in Green NiteVu Night Illumination Built-in Compensators to Easily Adjust for Deviation Scientifically Matched Sapphire Jewel and Hardened Steel Pivot Dial Movement Powerful DirectiveForce Magnets for Fast Heading Lock-on Movable Sun Shield High Temperature Composite Construction for Extended Operating Range Custom Fitted Protective Covers Available 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 1lb 8oz (680g)Notes:All magnetic compasses come standard with 12v lighting. 24 & 32v lighting options are available.Uses 2 sets of lights. Specifications: Read: Both Mounting Style: Bracket Backlight: Yes Lubber Lines: Yes Box Dimensions: 6"H x 6"W x 6"L WT: 1.4 lbs UPC: 010342141101 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Ritchie GM-5-C 5" GlobeMaster Binnacle Mount Compass Cover - WhiteProtective cover for Globemaster binnacle models.For: SP-5B, SP-5C, D-515, and D-515-EPApprox. Shipping Weight: 1lb (454g)

Read more less

Voyager CompassFeatures: 3″ (76 mm) Open Face Dial Adjustable and Removable with Bracket and Thumbscrews Exclusive Built-in Green NiteVu Night Illumination Built-in Compensators to Easily Adjust for Deviation Scientifically Matched Sapphire Jewel and Hardened Steel Pivot Dial Movement Powerful DirectiveForce Magnets for Fast Heading Lock-on Movable Sun Shield 45 Degree Lubber Lines High Temperature Composite Construction for Extended Operating Range Custom Fitted Protective Covers Available 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 1lb 8oz (680g)Notes:All magnetic compasses come standard with 12v lighting. 24 & 32v lighting options are available.Uses 2 sets of lights. Specifications: Read: Rear Lubber Lines: Yes Backlight: Yes Mounting Style: Bracket Box Dimensions: 6"H x 6"W x 6"L WT: 1.7 lbs UPC: 010342140104 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Nitron XD Pro Full Color Marine Night Vision Camera with Standard MountThe Nitron XD PRO Marine Night Vision Camera displays the highest resolution possible, giving you crystal clear imagery in pitch black darkness. Without relying on thermal temperatures, you will have the perfect HD image in any nighttime condition.With the ability to connect right into your Garmin, Simrad, Raymarine, or many other monitors, installing our marine video camera is practically plug-and-play. With your included cable, plug right into your video input port.Features: Ultra Sensitive .0000025 Camera Offers up to 4k Resolution 60 Frames Per Second  Connect Directly to Your MFD - Analog, HDMI, or Digital POE Marine Grade IP69 Waterproof Housing Flexible Installation (Top or Bottom Mount) 12V DC Power Manual Vertical Tilt Adjustment 50° Field of View Automatic Day & Night Filter Specifications: Operating Voltage: 12V DC Frame Rate: 60 FPS Resolution: Up to 4K Filter: Auto Day to Night Field of View: 50° FOV Horizontal Image: Full Color What's In The Box? Nitron XD Pro Marine Camera  25' Quick Connect Wiring Harness 5 Amp In-line Fuse Anodized Aluminum Mount Stainless Screws Single Use Dielectric Grease Packet

Read more less

Aurora PRO Night Vision CameraThe SIONYX Aurora PRO is the flagship full-color digital night vision optic.  The PRO is the latest development with both new sensor technology and enhanced optics giving the viewer the most advanced digital night vision capabilities.  The PRO performs best in the darkest conditions.  It's designed with extreme environments in mind and has all of the great recording and streaming functionality as the rest of the Aurora line.The Aurora PRO is a top choice for law enforcement agencies across the globe and has been leveraged for both surveillance and evidence gathering.  If you're looking for the best in color night vision, that can see further into the darkness spectrum, the Aurora PRO is the night vision camera for you.Features: Moonless starlight night vision w/GPS, compass & accelerometer Wi-Fi enabled Weapons-rated Water-resistant (IP67) Wirelessly stream to a smart device via the SIONYX app Storage Capacity 256 GB In the Box: Aurora PRO color night vision camera Hardshell waterproof case Two (2) camera batteries USB charge/data cable 32 GB microSD card *Sold as an Individual Specifications: Reverse Image: No Box Dimensions: 5"H x 8"W x 10"L WT: 3.4 lbs UPC: 811251020064 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

AS-ETH-5PGL 5 Port Ethernet SwitchThis Ethernet switch allows you to connect to up to five compatible Humminbird fish finders and Ethernet-compatible devices to create an integrated network capable of sharing information across all connected devices. The amber power light lets you know you are connected to power, while the amber and green connection lights give you a quick status of what’s connected. Features: Connect up to five Humminbird fish finders and other compatible Ethernet devices for data sharing across the network. Expand your network's capacity up to 20 devices by linking additional switches together (sold separately). Compatible with all XPLORE, APEX, SOLIX, HELIX G4N and HELIX G3N fish finder models. Connection Light: Solid = Connected; Flashing = Data Transfer in Progress; No Light = No Connection Amber Connection Light: XPLORE, HELIX G4N & G3N, AS ETH NMEA2K, Minn Kota Trolling Motor, Radar Green Connection Light: APEX, SOLIX, MEGA Live, TargetLock, AS ETH 5PXG, AS ETH 5PGL Amber Power Light: Connected to power Additional Ethernet cables are required to connect devices to this switch. AS EC QDE connectors will also be required to connect compatible HELIX models to the Ethernet switch. Includes: Ethernet switch, power cable, mounting hardware 1-Year Limited Warranty

Read more less

XNT-9-HW-MSI-150-T MEGA SI/DI Dual Spectrum CHIRP Transducer with Temp f/HELIX® 7/8 MEGA SI Transom Mount, MEGA Down Imaging, 455 kHz and 1.2 MHz and Dual Spectrum CHIRP 2D Sonar with a CHIRP range of 150-220kHz. Includes built-in temperature. Compatible with: HELIX 7 CHIRP MEGA SI GPS G3/G4, HELIX 7 CHIRP MEGA SI GPS G3N/G4N. Features: Compatible with: HELIX 7 CHIRP MSI GPS G3, HELIX 7 CHIRP MSI GPS G3N, HELIX 7 CHIRP MSI GPS G4, HELIX 7 CHIRP MSI GPS G4N Cable Length:  20 Feet Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz Dual Spectrum CHIRP Max Depth: 1200ft (365m) Side Imaging Frequencies - Max Range (side-to-side): 455kHz: 440-500 kHz - 800ft (146m), MEGA SI: 1075-1150 kHz - 250ft (76m) Down Imaging Frequencies - Max Depth: 455kHz: 440-500 kHz - 125ft (38m), MEGA DI: 1075-1150 kHz - 75ft (23m) WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Temperature: Yes Pins: 7 Mounting Style: Transom Speed Included: No Imagining: Standard/Down/Side Chirp: High Wide Cable Length (Feet): 20' Box Dimensions: 4"H x 8"W x 9"L WT: 1.45 lbs UPC: 082324053498 Owner's Manual (pdf)

Read more less

Chesapeake White SS 5" Tachometer w/Digital Hourmeter - 6000 RPM (Gas) (Inboard)Perimeter-lighted White dial with stylish Blue and White graphics, polished stainless steel bezel, contoured White pointer and domed glass lens. Electronic tachometers work by counting pulses generated by the ignition system, alternator, tach signal generator or magnetic pickup sender. The tach is hooked up to +12vDC, Ground and one of the signal sources listed above.By selecting the right tach and setting the switch on the back to the correct position you let the tachometer know how many pulses are sent per each engine revolution.5" - Hole size: 4.375" (112mm)Specifications: Anti-scratch glass lens Perimeter lighted back light 12 VDC negative ground Can be adapted for 24 VDC systems Scale - 0 to 10000 Hours Factory P/N TC9381*Sold as an Individual**Gauge Cover not IncludedThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 5" Voltage - Input Range (Volts): 12/24 V Gauge Type: Tachometer w/Hourmeter Series: Chesapeake White Box Dimensions: 9"H x 9"W x 9"L WT: 1.35 lbs UPC: 759266338630

Read more less

Power Cable - 15M with Bare WiresFeatures: Power Cable 15M Comes with bare wires Specifications: Type: Power Cords Box Dimensions: 2"H x 10"W x 10"L WT: 3.1 lbs UPC: 723193813454

Read more less

Solid-State Rate/Gyro Compass without CablesMaretron's SSC300, implementing the second generation of Maretron's award-wining compass technology, is a solid state, rate gyro electronic compass that provides better than 0.7x heading accuracy through q45x of roll and pitch angle, and better than 1x roll and pitch accuracy in static conditions. Each SSC300 is factory calibrated for maximum accuracy. It delivers precise, reliable heading information ten times per second, plus vessel attitude including pitch and roll readings once per second. A micromachined 3-axis rate gyro is used, in conjunction with a 3-axis accelerometer, by advanced stabilization algorithms to provide accurate, stable readings during dynamically changing conditions such as hard turns or rough seas, making it an ideal heading sensor for autopilot or radar overlay applications.Maretron's SSC300 is certified to the NMEA 2000 network standard and compatible with the NMEA 0183 digital interface standard. It connects directly with any NMEA 2000 network and with the optional NMEA 0183 cable accessory, with NMEA 0183 listeners to share information with navigational software, chart plotters, autopilots, and dedicated instrument displays - including Maretron's N2KView vessel monitoring system, or Maretron's DSM150 /DSM250 color graphics displays.The SSC300 can be automatically calibrated for deviation. Its dynamic accuracy is improved with advanced digital filtering of the 3-axis magnetometer, 3-axis accelerometer and rate gyro.Features: Better than 0.7x heading accuracy in static conditions Better than 1.5x heading accuracy in dynamic conditions Better than 1x/second rate of turn in Better than 1x pitch/roll accuracy Three axis magnetometer, three axis rate gyro, and three axis accelerometer Outputs NMEA 0183 and NMEA 2000 data simultanously IP67 waterproof enclosure Applications: Navigation Autopilot Radar stabilization Satellite antenna stabilization Swing meter WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

Dress White Boxed Set - Inboard MotorsPerimeter-lighted White dial with bold Black graphics, White aluminum bezel, contoured Black pointer, and flat glass lens.Packaged and ready for the display counter.  This 6 Gauge Boxed Sets offers a complete set of gauges ready to install.Inboard Motors Boxed Set Includes Speedometer (55 MPH) (Mechanical) Tachometer (6000 RPM) Fuel Level Voltmeter (10-16 VDC) Water Temp (100-250 F) Oil PSI (80 PSI) Factory P/N KT9797*Sold as a Box Set**Gauge Covers not Included This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Gauge Type: Box Set Series: Dress White Box Set: Yes Voltage - Input Range (Volts): 12/24 V Box Dimensions: 6"H x 10"W x 21"L WT: 4.3 lbs UPC: 759266097971

Read more less

Mini Gender ChangersMaretron cables have a male connector on one end and a female connector on the other end. Normally, the male connector points back towards the network power supply, but on some occasions, this gets reversed and a gender changer can be used to get back to the desired connector type.Waterproof seals for reliable connections Easily swap connector gender to get back to desired connector type Specifications: Connection Gender: Female-Female Box Dimensions: 1"H x 1"W x 1"L WT: 0.2 lbs UPC: 873804002408

Read more less
