Marine Navigation & Instruments

Marine Network Cable - 500'Our marine network cable offers an additional 500'(152.4M) of cable length.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Cable Length (Feet): 500' Box Dimensions: 4"H x 11"W x 11"L WT: 12.8 lbs UPC: 753759049966

Read more less

GT8HW-IF Ice Fishing, Plastic, High Wide CHIRP Transducer - 150-240kHz, 250W, 4-PinGT8HW-IF transducer is perfect for ice fishermen who want clear bottom definition under the ice as well as crisp, clear and wide fish arches with excellent target separation. The wider beam width - up to 24 degree beam angle - provides a larger coverage area in the water.The 4-pin transducer features high wide band CHIRP traditional sonar (150-240 kHz) and has a power rating of 250 W. Its shape and beam widths have been optimized for ice fishing and feature a silicon-coated cable that remains flexible in harsh winter conditions.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Temperature: No Speed Included: No Pins: 4 Mounting Style: Ice Chirp: High Wide Cable Length (Feet): 8' Imaging: Standard Box Dimensions: 3"H x 6"W x 7"L WT: 0.8 lbs UPC: 753759148560

Read more less

B265LH Bronze Thru-Hull Mount Transducer w/Depth & Temp - 12-PinGarmin's best performing 1 kW thru-hull transducer, this mount performs well in deep water and has exceptional bottom and water column detail.This transducer has a depth of 3,000 feet; an operating frequency of 42 to 65 kHz and 130 to 210 kHz; a beamwidth of 16 to 25 degrees and 6 to 10 degrees; and a 0 to 20 degree deadrise.Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.Compatible Devices: GPSMAP® 7607xsv, 7608xsv, 7610xsv, 7612xsv, 7616xsv GSD™ 25 Premium Sonar Module WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Mounting Style: Thru-Hull Temperature: Yes Speed Included: No Imaging: Standard Chirp: Low/High Cable Length (Feet): 39' Pins: 12 Box Dimensions: 7"H x 19"W x 26"L WT: 24.2 lbs UPC: 753759142414

Read more less

Tilt/Swivel Quick-Release MountSecure your compatible echoMAP™ with this mount, which features tilt/swivel capabilities for optimum viewing. With the mount's quick cable disconnect feature, you can plug the necessary cords into the mount, allowing you to seat/unseat your device with ease.Compatible Devices: echoMAP™ 43dv echoMAP™ 44dv WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Mounting Brackets Box Dimensions: 3"H x 4"W x 8"L WT: 0.5 lbs UPC: 753759133559

Read more less

Power CablePower your Garmin radar with this 48' long threaded cable.Compatible Devices: GMR™ 1204 xHD Open Array Radar and Pedestal GMR™ 1206 xHD Open Array Radar and Pedestal GMR™ 18 HD Radome GMR™ 18 Radome GMR™ 8 xHD Radome GMR™ 24 GMR™ 24 HD Radome GMR™ 24 xHD Radome GMR™ 404 xHD Open Array Radar and Pedestal GMR™ 406 xHD Open Array Radar and Pedestal GMR™ 604 xHD Open Array Radar and Pedestal GMR™ 606 xHD Open Array Radar and Pedestal WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Airmar B744VL 200/50kHz Bronze Long Stem Thru-hull Transducer (8-pin)010-10193-22Our bronze, thru-hull mount long stem transducer provides depth, speed and temperature data. This transducer has an operating frequency of 50 or 200 kHz and mounts on a 0-28° deadrise angle.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Temperature: Yes Speed Included: Yes Pins: 8 Mounting Style: Thru-Hull Imaging: Standard Chirp: No Cable Length (Feet): 39' Box Dimensions: 3"H x 12"W x 16"L WT: 8.9 lbs UPC: 753759971793 Owner's Manual (pdf)Brochure (pdf)

Read more less

Swivel Mounting BracketMount your chartplotter or sounder with Garmin's swivel mounting bracket.Compatible Devices: GPSMAP® 500 Series GXM™ 31 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Mounting Brackets Box Dimensions: 3"H x 4"W x 7"L WT: 0.4 lbs UPC: 753759067496

Read more less

Rear Panel Mount NMEA2000 Wired Micro 5-Pin - MalePanel mount wired connectors available from Actisense allow NMEA 2000 installations through watertight bulkheads (or panels) to be achieved.Waterproof seals ensure the integrity of the NMEA 2000 connection and bulkhead/panel.The female panel mount wired connector can easily replace any of the existing ‘drop’ glands on the Actisense QNB-1 to create a quick pluggable NMEA 2000 connection option.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications:Electrical Rated Current - 4A Rated Voltage - 60VDC Mechanical Contacts - Brass, gold-plated Contact Carrier - Nylon & GF Contact Polarization - Standard M12-"A"-Polarization Mating Thread - M12 Housing - Brass, nickel-plated Mounting Thread - PG9 Mounting Nut - Brass, nickel plated - PG9 Mounting Hole Diameter - 15.3mm Wires - 18 AWG (stripped and tinned) Wire Jacket - PVC Weight - 20g Approvals and Certifications Protection - IP67 (when mated) Operating Temperature - -25°C to +90°C Connector Specification - Meets IEC61076-2-101 This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Connection Gender: Male Data Interface: NMEA 2000 Box Dimensions: 1"H x 4"W x 6"L WT: 0.05 lbs UPC: 5060998710164 Owner's Manual (pdf)Brochure (pdf)

Read more less

NMEA2000 to WiFi GatewayThe W2K-2 is a rugged and reliable NMEA 2000 to Wi-Fi Gateway with built-in data logger and Actisense-i diagnostic tools.Transfer data from an NMEA 2000 backbone to any device (e.g, laptop, tablet, or smartphone) connected to the W2K-2 via Wi-Fi and additionally convert this data to NMEA 0183 using Actisense’s renowned conversion engine. Actisense-i is a suite of diagnostic tools and a health checker for your network.Fully compatible with the industry’s most popular apps.The W2K-2 has built-in conversion of NMEA 2000 messages into NMEA 0183 sentences, thus allowing a wide variety of vessel data (e.g., position, speed, course, wind speed, depth, engine data, AIS messages, etc.) to be shared with NMEA 0183 compatible software applications running on connected devices.All the data received (or a selected subset) can be logged to an internal micro SD card for later downloading to use for analyzing the voyage. This is very useful for analyzing race data, generating logbooks, diagnosing problems, or even sharing your voyage details. Data can be stored on any micro SD card (up to 128GB), giving weeks or more of storage for all onboard NMEA data.The W2K-2 has adopted the latest WPA3 standards for password protection. Whilst most wireless gateways still use WPA2, WPA3 adds an extra layer of security.Actisense-i comes included as standard. Benefit from our full suite of diagnostic tools to help check and diagnose potential issues on a boat’s electronics network, including voltage issues, and the working status of all devices attached to the network. Actisense-i has been designed to save installers and boaters time and ultimately, money, by giving them confidence in their electronics onboard.The W2K-2 has the legendary Actisense “Reliability Built-In” along with useful diagnostic LEDs, an internal antenna, enhanced password security, full certification, and all packaged in an extremely rugged IP67 case.Features: Converts NMEA 2000 to/from NMEA 0183 (streamed over Wi-Fi) Supports both TCP and UDP, streams data using up to three separate data servers Data protocols are selectable to be compatible with a huge range of navigation software and apps Voyage data recording (install SD card up to 128GB) Diagnostic LEDs for NMEA 2000 bus activity and Wi-Fi Status Works as an access point and a client simultaneously Remote Firmware Upgradability Low power- 2 LEN (100 mA) Supports 802.11 b/g/h (up to 150Mbps) Automatically measures and reports the NMEA 2000 bus voltage User Manual embedded on the device, easily accessible via browser Each device has a unique default SSID and Password for enhanced security Actisense-i diagnostic tools Two-in-one NMEA 2000 to Wi-Fi Gateway and data logger Enables the use of mobile devices and laptops without the hassle of a physical connection Allows compatibility with a wide range of NMEA 2000 & NMEA 0183 applications Ruggedized IP67 casing suitable for wet and harsh environments Works out of the box – just install your choice of SD card for logging data An integrated antenna has less chance of physical damage Quick and easy to install Technical Specifications:Power Supply Supply Voltage (NMEA 2000 Port) - 9 to 30V DC     Supply Current (NMEA 2000 Port) - 70mA (avg.) @ 12V DC, 100mA (avg.) @ 9V DC Load Equivalent Number (LEN) - 2     Supply protection - Continuous reverse polarity protection and transient overvoltage protection to 40V Wi-Fi Radio Compatibility - IEEE 802.11 b/g/n     Speed - 802.11n up to 150Mbps     Frequency Band - 2.4GHz 2.5GHz     Max Output power - 20 dBm     Antenna - Integrated internal antenna     Range (Open space) - 30 meters     Security - WPA_PSK,  WPA2_PSK,  WPA_WPA2_PSK Configuration IP support - Supports TCP and UDP broadcast     Data servers - Three separate data servers     Data protocols - NMEA 0183 & Five proprietary     Security - SSID and Password configurable (Unique defaults per device) Diagnostics Power LED - Blue     NMEA 2000 Tx LED - Orange     NMEA 2000 Rx LED - Green     Status LED - Yellow     Micro SD card - Not supplied – customer to install as required. Mechanical  Housing Material (body) - Polycarbonate     Housing Material (endcaps) - PBT     NMEA 2000 Connector - M12 Male (A polarized) connector molded into the case     NMEA 2000 Connector Material - Nickel-plated brass     Weight - 80g     Dimensions - 106mm (L) x 73mm (W) x 24mm (H) Environmental Environmental Protection - IP67     Operating Temperature - -20°C to +55°C     Storage Temperature - -40°C to +85°C     Recommended Humidity - 0 – 93% RH Approvals and CertificationsGuarantee - 5 yearsThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Data Interface: NMEA 2000 Box Dimensions: 2"H x 4"W x 8"L WT: 0.4 lbs UPC: 5060998710829 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

PRO NMEA 0183 Multiplexer/NMEA 2000 GatewayInterconnectivity, reimagined!The PRO-NDC-1E2K is much more than an NMEA 0183 Multiplexer…Rugged, Robust, Type Approved Multiplexer with built-in NMEA 2000 connectivity, high-speed Ethernet streaming of data, flexible configuration, auto-switching and sentence level filtering.Managing and routing your NMEA data is straight forward, hassle free using the PRO-NDC-1E2KFeatures: Auto-switching between inputs to allow for a primary, secondary, tertiary priority input. Configurable baud rates to allow 38400 and 4800 baud devices to operate through the same multiplexer. Sentence filtering to block unwanted sentences from specific outputs helps to limit bandwidth consumption. Easy to configure using the web based UI, no need to manually enter and edit strings of text. RINA type approved device means the multiplexer is fit for leisure, commercial and class / type installations. Multiple LED’s allow for ‘quick glance’ diagnostics to ensure everything is operating correctly. Certified NMEA 2000 device connectivity allows for conversion and output of data onto NMEA 2000 network. Bi-directional conversion to and from N2K Network allows for seamless integration between legacy and new equipment. NMEA 0183 data streaming over Ethernet enables connectivity to existing Ethernet devices and systems. NMEA 2000 data streaming over Ethernet. 5 OPTO-Isolated NMEA 0183 inputs and 2 ISO-Drive NMEA 0183 outputs provide protection for all connected instruments. Type-approved (RINA). NMEA 0183 Ethernet streaming NMEA 2000 Ethernet streaming NMEA 2000 output via M12 5x Configurable Opto-isolated NMEA 0183 inputs. 2x Configurable ISO-Drive isolated NMEA 0183 outputs. 1x Bi-directional, configurable, isolated serial port. Automatic baud rate matching on inputs. Advanced data filtering / routing. Free firmware updates making the device future-proof. Diagnostic LEDs on all inputs and outputs. Bi-colour status LED. Panel mountable. Stainless Steel housing for added durability Quick and easy to install Configuration using standard web browser, no PC operating system compatibility issues Advanced features solve NMEA 0183 data routing problems Fully isolated with ISO-Drive technology for peace of mind Easy firmware updates make the device future-proof Type Approved (RINA) Technical Specifications:Power Supply Input supply voltage - 9 to 35 V DC Input supply current - 150mA max @ 12V DC (all outputs @ full drive into 100 ohm loads) Input protection - Continuous reverse polarity, transient overvoltage and ESD protection Power indicator - LED, Blue – indicates unit is functioning correctly Input Supply connector - Pluggable 2-way screw terminal, 5.08mm pitch (12 to 30 AWG) NMEA 0183 Port – Listener & Talker Number of Listener / Input Ports - 5 isolated NMEA 0183 Listeners Number of Talker / Output Ports - 2 isolated NMEA 0183 Talkers Compatibility - Fully NMEA 0183, RS422 & RS232 compatible. RS485 Listener compatible Speed / baud rate - 4800 to 38400 bps Talker Output Voltage Drive - >= 2.2V (differential) into 100 ohm Talker Output Current Drive - 20 mA maximum per output Talker Output Protection - Short circuit and ESD Talker Data Indicator - LED, Orange (Flashes with data rate) Listener Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) Listener Input Protection - Current limited, overdrive protection to 40 VDC and ESD protection Listener Data Indicator - LED, Green (Flashes with data rate) Connectors - Pluggable 2/3 way screw terminals, 5.08mm pitch (12 to 30 AWG) Serial Port Compatibility - RS422 & RS232 compatible. RS485 Listener compatible Speed / baud rate - 115200 bps Output voltage drive - >= 2.1V (differential) into 100 ohm Output current drive - 20 mA max. Output protection - Short circuit and ESD Input voltage tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) Input protection - Current limited, overdrive protection to 40 VDC and ESD protection Data Indicators - LED’s: Green = Receive, Orange = Transmit Connectors - Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Ethernet Port Host interface - 10/100BaseT, automatic polarity detection Supported protocols - TCP/IP for configuration and firmware updating, TCP/IP and UDP for NMEA 0183 comms Connector - RJ45 Indicators - Green – Link, Yellow – 100 Mbps NMEA 2000 Port Compatibility - NMEA 2000 Certification Pending Speed / baud rate - 250 kbps Connectivity - M12 male (A-coded) connector Isolation NMEA 0183 Listener - Uses IsoDriveTM, Hi-Pot tested to 1000V NMEA 0183 Talker - Uses IsoDriveTM, Hi-Pot tested to 1000V Serial Port - Uses IsoDriveTM, Hi-Pot tested to 1000V Ethernet Port - 2kv for 60s NMEA 2000 Port - OPTO-Isolated, Hi-Pot tested to 1000V Mechanical Housing Material - 316 Stainless Steel Dimensions - 139mm (W) x 98mm (H) x 26mm (D) Weight - 360g Mounting - Bulkhead mount or DIN rail mount (DIN kit 1) Approvals and Certifications EMC - IEC 60945:2002-08, DNVGL-CG-0339:2019 & IACS UR E10 Rev7 Compass Safe Distance - 300mm Type Approval Certificate - RINA Operating Temperature - -25 to +70°C Storage Temperature - -40 to +85°C Relative Humidity (RH) - 95% @ 55°C Environmental Protection - IP40 Guarantee - 5 Years when registered This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Data Interface: NMEA 0183 Box Dimensions: 2"H x 6"W x 10"L WT: 1.05 lbs UPC: 5060998710751 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

0183 to N2K Gateway with PC Interface, USB ConnectionIntelligent Gateway technology enables PC interfacing and NMEA data conversion…The NGX-1 is an intelligent multi-function gateway, combining the power of our two previous generation products (NGT-1 and NGW-1) into one, cost effective, flexible product.Configure the NGX-1 to operate as an NMEA 2000 <–> PC interface, or as a bi-directional NMEA 0183 <–> NMEA 2000 conversion gateway.Features: View all NMEA 2000 network data on Actisense NMEA Reader. The device supports every available PGN in the NMEA 2000 standard. View converted NMEA 0183 data on Actisense NMEA Reader. The device sports the largest conversion library of any gateway. Easily interface with a wide range of PC applications via the NGX-1, such as TimeZero (NMEA 2000) and OpenCPN (NMEA 0183). Configure the Actisense EMU-1, NGW-1 and NGX-1 via Actisense Toolkit using an NGX-1. Connect legacy NMEA 0183 instruments together with new NMEA 2000 networks, greatly reducing upgrade costs. Vital NMEA 2000 diagnostic tool Fully isolated to prevent dangerous ground loops Up to 230,400 baud data transfer rate Advanced configuration using Actisense Toolkit allows Tx / Rx lists and Tx rates to be set Supports Fast Heading at 10Hz Multiple diagnostic LEDs Allows all major PC Chartplotter applications to interface with the NMEA 2000 bus Provides a rule-enforcing firewall between the PC and the NMEA 2000 bus Powerful diagnosis of the NMEA 2000 network using the FREE NMEA Reader software provided Configure and flash-update Actisense products on the bus Upgrade NMEA 0183 equipment to NMEA 2000 Allow NMEA 0183 devices to receive vital NMEA 2000 data Use the NMEA 2000 bus to multiplex several NMEA 0183 signals together Reliable, renowned bi-directional conversion engine Supports a wide range of conversions including AIS Easily configurable using Actisense Toolkit Technical SpecificationsPower Supply Supply Voltage (NMEA 2000 Port) - 9 to 30V DC Supply Current (NMEA 2000 Port) - 62mA @ 9V DC Load Equivalent Number (LEN) - 2 NMEA 2000 Port Speed / Baud Rate - 250kbps Connectivity - M12 Male (A coded) USB Port Compatibility - USB 1.1, 2.0 and 3.0 Speed / Baud Rate - 4800 to 230400 Baud Connectivity - Male type A plug moulded onto cable Cable Length - 1.8m Isolation NMEA 2000 Port to ISO Port - Uses IsoDriveTM, Hi-Pot tested to 1000V NMEA 2000 Port to USB Port - Galvanic Isolation, Hi-Pot tested to 1000V Mechanical Housing Material Body - Flame retardant Polycarbonate Housing Material End Caps - Flame retardant PBT Weight - 113g Approvals and Certifications NMEA 2000 - NMEA 2000 Certified NMEA 0183 - Meets IEC 61162-1 & 61162-2 Requirements RoHS and REACH - Compliant Module Certification - KCC / BQB / IC / Wi-Fi / NCC / MIC / FCC DSS / FCC DTS / SRRC / CE, EN 60945:2002 Edition 4 (section 9.3), EN 301 489-1 V2.2.3, EN 301 489-17 V3.2.4 EMC - EN 300 328 V2.2.2 Radiated Spurious Emissions, FCC Part 15b, ICES-003 Iss 7 Environmental Protection    IP67 Operating Temperature    -25°C to +70°C Storage Temperature    -30°C to +70°C Recommended Humidity    0 to 93% RH @ 40°C Guarantee    3 years, extended to 5 years upon registration This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Data Interface: NMEA 0183 Box Dimensions: 2"H x 6"W x 6"L WT: 0.5 lbs UPC: 5060998710560 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

High-Speed HDMI CableUse this 15-foot cable to connect your compatible Garmin marine product to an HDMI device. The water-resistant and secure connection supports 4K video and audio playback. Refer to your device owner’s manual for more information on supported A/V features.

Read more less
