Marine Plumbing & Ventilation

5/8" Reinforced PVC (FDA) Cold Water Feed Line Hose - Drinking Water Safe - Translucent Blue - Sold by the FootTrident 165 Series Blue - polyester reinforced PVC hose for "Cold Water" feed lines. The FDA-grade tube is non-toxic, odorless, and tasteless. Suitable for use in harsh operating conditions with temperatures as low as -18.4ºF (- 28ºC) and can handle pressures up to 250 psi (varies based on I.D size).Features:  Sold by the foot The Blue cover allows for easy identification of "Cold Water" lines on your boat   Made of 3-ply polyester for excellent abrasion resistance and sustained flexibility This hose is safe for use with drinking water Application:Perfect for cold pressurized applications, water feed, drains, and vent linesConstruction: Tube & Cover: Clear FDA tube  Color: Blue Transparent  Reinforcement: Polyester Temperature Range: -18°F to 149°F (-28°C to 65°C) Specifications: Inner Diameter: (inch) 5/8" / (mm) 15.9 Outer Diameter: (inch) .866 / (mm) 22.5 Working Pressure: (PSI Vac In./Hg) 230 / (bar) 16 Bend Radius: (inch) 1.26" / (mm) 32 *Burst Pressure is 4 x Working Pressure Specifications: ID Diameter (inches): 5/8" Box Dimensions: 1"H x 1"W x 6"L WT: 0.17 lbs Quick Guide (pdf)

Read more less

1" VAC XHD Sanitation Hose - Hard PVC Helix - White - Sold by the FootTrident Ply Extra heavy-duty sanitation hose of smooth white vinyl. Specially compounded to provide excellent resistance to odor permeation and (FDA) potable water fill. Also for the critical bilge, drain scuppers, live wells, etc. Self-draining installations are recommended for the longest odor-free service.Features: Sold by the foot A hard PVC helix gives good flexibility and bend radius No cuffs are required Applications: Specially compounded to provide resistance to odor permeation and (FDA) potable water fill Also for critical bilge, drain scupper, live well, etc Specifications: Tube & Cover: Hard PVC helix Color: White Reinforcement: PVC Helix Temperature Range: 10°F-120°F (-12°C-48°C)  Inner Diameter: (inch) 1" / (mm) 25.4 Outer Diameter: (inch) 1.262" / (mm) 32.1 Working Pressure: (Psi Vac In./Hg) 28 Weight: (Lb./ 50 ft.) 15 / (Kg/m) 0.52  Bend Radius: (inch) 3" / (mm) 76.2 *Don't use with alcohol, anti-freeze, petrochemicals, or solvents*Burst Pressure is 4 x Working Pressure Specifications: ID Diameter (inches): 1" Box Dimensions: 1"H x 1"W x 6"L WT: 0.32 lbs Quick Guide (pdf)

Read more less

3/4" Reinforced PVC (FDA) Cold Water Feed Line Hose - Drinking Water Safe - Translucent Blue - Sold by the FootTrident 165 Series Blue - polyester reinforced PVC hose for "Cold Water" feed lines. The FDA-grade tube is non-toxic, odorless, and tasteless. Suitable for use in harsh operating conditions with temperatures as low as -18.4ºF (- 28ºC) and can handle pressures up to 250 psi (varies based on i.d size).Features:  Sold by the foot The Blue cover allows for easy identification of "Cold Water" lines on your boat   Made of 3-ply polyester for excellent abrasion resistance and sustained flexibility This hose is safe for use with drinking water Application:Perfect for cold pressurized applications, water feed, drains, and vent linesConstruction: Tube & Cover: Clear FDA tube  Color: Blue Transparent  Reinforcement: Polyester Temperature Range: -18°F to 149°F (-28°C to 65°C) Specifications: Inner Diameter: (inch) 3/4" / (mm) 19 Outer Diameter: (inch) 1 / (mm) 25.4 Working Pressure: (PSI Vac In./Hg) 220 / (bar) 15 Bend Radius: (inch) 1.5" / (mm) 38 *Burst Pressure is 4 x Working Pressure Specifications: ID Diameter (inches): 3/4" Box Dimensions: 1"H x 1"W x 12"L WT: 0.23 lbs Quick Guide (pdf)

Read more less

1-1/2" Premium Marine Sanitation Hose - White with Green Stripe - Sold by the FootTrident Premium Sanitation Hose resistant to odor permeation. Simply the BEST solution for marine environments, built with EPDM rubber to ensure the overall performance and resistance to odor permeation that you would expect in a sanitation hose. Features: Sold by the foot Resistance to Odor Permeation and winterizing with antifreeze  With wire helix between 2-ply reinforcement, this hose has excellent bend radius, flexibility, and fitting acceptance and retention This makes for easy installations with no heat gun or lubricant necessary 10 Year Warranty Application: Premium Sanitation Hose for all head & holding tank connections NOT for potable water Construction: Tube & Cover: EDPM/SBR Rubber Color: White with Green Stripe Reinforcement: Polyester reinforcement + spring steel wire helix Temperature Range: -20F-220°F (-29°C-104°C) Specifications: Inner Diameter: (inch) 1-1/2" / (mm) 38.1 Outer Diameter: (inch) 2 / (mm) 50.8 Working Pressure: (Psi) 60 / (bar) 4.1 Weight: (Lb./50ft.) 44 / (Kg/m) 19.9 Bend Radius: (inch) 3" / (mm) 76.2 *Burst Pressure is 4 x Working Pressure Quick Guide (pdf)

Read more less

3" Blue Polyduct Blower Hose - Sold by the FootTrident Polyduct is the most flexible, crush proof and rugged blower duct hose for heat, ventilation, and air conditioning* (HVAC). Heavy Duty polypropylene hose, reinforced with a flexible polypropylene rod helix.Features: Sold by the foot Excellent flexibility & compressibility Excellent resistance to crushing, flex fatigue, tearing, and moisture  Stomp on it and it returns to shape without damage  Shove it thru tight openings and overheads and it delivers full airflow Application:Rugged blower duct hose for heat, ventilation, and air conditioningSpecifications:  Temperature Range: -40°F to +225°F (-40°C to 107°C) (when insulated) Inner Diameter (inch): 3" *Meets FMVSS 302 flame resistance Specifications: ID Diameter (inches): 3" Box Dimensions: 3"H x 3"W x 12"L WT: 0.19 lbs

Read more less

1/2" Reinforced PVC (FDA) Hot Water Feed Line Hose - Drinking Water Safe - Translucent Red - Sold by the FootTrident 166 Series Red - polyester reinforced PVC hose for "Hot Water" feed lines. The FDA-grade tube is non-toxic, odorless, and tasteless. Suitable for use in harsh operating conditions with temperatures of up to 149ºF (65ºC) and can handle pressures to a maximum of 250 psi (varies based on i.d size). Features:  Sold by the foot The Red cover allows for easy identification of "Hot Water" lines on your boat Made of 3-ply polyester for excellent abrasion resistance and sustained flexibility This hose is safe for use with drinking water Application:Perfect for hot, pressurized applications, hot water feed, drains, and vent linesConstruction: Tube & Cover: Clear FDA tube  Color: Red Transparent  Reinforcement: Polyester Temperature Range: -18°F to 149°F (-28°C to 65°C) Specifications: Inner Diameter: (inch) 1/2" / (mm) 12.7 Outer Diameter: (inch) .777 / (mm) 19.6 Working Pressure: (PSI Vac In./Hg) 250 / (bar) 17 Bend Radius: (inch) 0.98" / (mm) 25 *Burst Pressure is 4 x Working Pressure Specifications: ID Diameter (inches): 1/2" Box Dimensions: 1"H x 1"W x 6"L WT: 0.15 lbs Quick Guide (pdf)

Read more less

5/8" Reinforced PVC (FDA) Hot Water Feed Line Hose - Drinking Water Safe - Translucent Red - Sold by the FootTrident 166 Series Red - polyester reinforced PVC hose for "Hot Water" feed lines. The FDA-grade tube is non-toxic, odorless, and tasteless. Suitable for use in harsh operating conditions with temperatures of up to 149ºF (65ºC) and can handle pressures to a maximum of 250 psi (varies based on i.d size). Features:  Sold by the foot The Red cover allows for easy identification of "Hot Water" lines on your boat Made of 3-ply polyester for excellent abrasion resistance and sustained flexibility This hose is safe for use with drinking water Application:Perfect for hot, pressurized applications, hot water feed, drains, and vent linesConstruction: Tube & Cover: Clear FDA tube  Color: Red Transparent  Reinforcement: Polyester Temperature Range: -18°F to 149°F (-28°C to 65°C) Specifications: Inner Diameter: (inch) 5/8" / (mm) 15.9 Outer Diameter: (inch) .866 / (mm) 22.5 Working Pressure: (PSI Vac In./Hg) 230 / (bar) 16 Bend Radius: (inch) 1.26" / (mm) 32 *Burst Pressure is 4 x Working Pressure Specifications: ID Diameter (inches): 5/8" Box Dimensions: 1"H x 1"W x 6"L WT: 0.19 lbs Quick Guide (pdf)

Read more less

3/4" x 50' Boxed Reinforced PVC (FDA) Cold Water Feed Line Hose - Drinking Water Safe - Translucent BlueTrident 165 Series Blue - polyester reinforced PVC hose for "Cold Water" feed lines. The FDA-grade tube is non-toxic, odorless, and tasteless. Suitable for use in harsh operating conditions with temperatures as low as -18.4ºF (- 28ºC) and can handle pressures up to 250 psi (varies based on i.d size).Features:  The Blue cover allows for easy identification of "Cold Water" lines on your boat   Made of 3-ply polyester for excellent abrasion resistance and sustained flexibility This hose is safe for use with drinking water Application:Perfect for cold pressurized applications, water feed, drains, and vent linesConstruction: Tube & Cover: Clear FDA tube  Color: Blue Transparent  Reinforcement: Polyester Temperature Range: -18°F to 149°F (-28°C to 65°C) Length: 50’ (15.24m) Specifications: Inner Diameter: (inch) 3/4" / (mm) 19 Outer Diameter: (inch) 1 / (mm) 25.4 Working Pressure: (PSI Vac In./Hg) 220 / (bar) 15 Bend Radius: (inch) 1.5" / (mm) 38 *Burst Pressure is 4 x Working Pressure Specifications: Length (Feet): 50' ID Diameter (inches): 3/4" Box Dimensions: 5"H x 18"W x 18"L WT: 11.6 lbs UPC: 704917023984 Quick Guide (pdf)

Read more less

5/8" x 50' Boxed Reinforced PVC (FDA) Hot Water Feed Line Hose - Drinking Water Safe - Translucent RedTrident 166 Series Red - polyester reinforced PVC hose for "Hot Water" feed lines. The FDA-grade tube is non-toxic, odorless, and tasteless. Suitable for use in harsh operating conditions with temperatures of up to 149ºF (65ºC) and can handle pressures to a maximum of 250 psi (varies based on i.d size). Features:  The Red cover allows for easy identification of "Hot Water" lines on your boat Made of 3-ply polyester for excellent abrasion resistance and sustained flexibility This hose is safe for use with drinking water Application:Perfect for hot, pressurized applications, hot water feed, drains, and vent linesConstruction: Tube & Cover: Clear FDA tube  Color: Red Transparent  Reinforcement: Polyester Temperature Range: -18°F to 149°F (-28°C to 65°C) Length: 50’ (15.24m) Specifications: Inner Diameter: (inch) 5/8" / (mm) 15.9 Outer Diameter: (inch) .866 / (mm) 22.5 Working Pressure: (PSI Vac In./Hg) 230 / (bar) 16 Bend Radius: (inch) 1.26" / (mm) 32 *Burst Pressure is 4 x Working Pressure Specifications: Length (Feet): 50.0 ID Diameter (inches): 5/8" Box Dimensions: 5"H x 18"W x 18"L WT: 9.4 lbs UPC: 704917024042 Quick Guide (pdf)

Read more less

1-1/2" x 50' VAC XHD Bilge & Live Well Hose - Hard PVC Helix - BlackTrident VAC XHD Bilge and Live Well Hose. Helical PVC reinforcement provides excellent flexibility and bend radius for live well and heavy-duty bilge applications. It has a smooth outer surface to allow for easy clamping. The excellent bend radius of this product gives you the flexibility of a rubber hose making installations a breeze.Features:149 series of hoses is extra flexible Application:Bilge and live well hoseSpecifications: Tube & Cover: Hard PVC helix Color: Black Reinforcement: PVC Helix Temperature Range: 10°F-120°F (-12°C-48°C)  Boxed: 50ft. / (15.2m) Inner Diameter: (inch) 1-1/2" / (mm) 38.1 Outer Diameter: (inch) 1.792" / (mm) 45.5 Working Pressure: (Psi Vac In./Hg) 28 / (Bar) 1.93 Weight: (Lb./ 50 ft.) 22 / (Kg/m) 9.98 Bend Radius: (inch) 4" / (mm) 101.6 *Burst Pressure is 4 x Working Pressure Specifications: ID Diameter (inches): 1-1/2" Box Dimensions: 8"H x 23"W x 23"L WT: 23.2 lbs UPC: 704917010472 Quick Guide (pdf)

Read more less

3/4" x 50' Boxed Reinforced PVC (FDA) Hot Water Feed Line Hose - Drinking Water Safe - Translucent RedTrident 166 Series Red - polyester reinforced PVC hose for "Hot Water" feed lines. The FDA-grade tube is nontoxic, odorless, and tasteless. Suitable for use in harsh operating conditions with temperatures of up to 149ºF (65ºC) and can handle pressures to a maximum of 250 psi (varies based on i.d size). Features:  The Red cover allows for easy identification of "Hot Water" lines on your boat Made of 3-ply polyester for excellent abrasion resistance and sustained flexibility This hose is safe for use with drinking water Application:Perfect for hot, pressurized applications, hot water feed, drains, and vent linesConstruction: Tube & Cover: Clear FDA tube  Color: Red Transparent  Reinforcement: Polyester Temperature Range: -18°F to 149°F (-28°C to 65°C) Length: 50’ (15.24m) Specifications: Inner Diameter: (inch) 3/4" / (mm) 19 Outer Diameter: (inch) 1 / (mm) 25.4 Working Pressure: (PSI Vac In./Hg) 220 / (bar) 15 Bend Radius: (inch) 1.5" / (mm) 38 *Burst Pressure is 4 x Working Pressure Specifications: Length (Feet): 50' ID Diameter (inches): 3/4" Box Dimensions: 5"H x 18"W x 18"L WT: 11.1 lbs UPC: 704917024066 Quick Guide (pdf)

Read more less

1" x 50' Boxed Heavy Duty Reinforced PVC (FDA) Hose - Drinking Water Safe - ClearClear FDA-grade PVC hose with heavy-duty nylon reinforcement provides excellent flexibility and bend radius.Features:  Good flexibility and bend radius Resists odor, taste, and up to 250 PSI/WP (depending on I.D. size) @ 70°F (21°C)  This hose is safe for use with drinking water Application: For pressurized drinking water systems and many other uses For cold and hot tap water Construction: Tube: Plasticized PVC (FDA) Color: Clear with white nylon reinforcement Reinforcement: PVC and HD nylon reinforcement Temperature Range: 20°F to 150°F (-7ºC to 66ºC) Length: Boxed, 50’ (15.24m) Specifications: Inner Diameter: (inch) 1" / (mm) 25.4 Outer Diameter: (inch) 1.185 / (mm) 30.1 Burst Pressure: (PSI @ 70ºF) 25.7 / (bar) 1.77 Working Pressure: (PSI @ 70ºF) 90  Bend Radius: (inch) 4" / (mm) 101.6 Specifications: Length (Feet): 50.0 ID Diameter (inches): 1" Box Dimensions: 5"H x 22"W x 23"L WT: 14.1 lbs UPC: 704917006741 Quick Guide (pdf)

Read more less
