Marine Safety - Fume Detectors

Fixed Heat Detector with BaseThe Fireboy-Xintex Heat Detector uses a single thermistor to sense the air temperature around the detector. This heat detector was designed to detect how fast the temperature is increasing.Features: 163°F Fixed Heat Detector Housing: White flame-retardant polycarbonate Terminals: Nickel-plated stainless steel Ideal in environments that are dirty or smoky Unaffected by wind or atmospheric pressure Remote test feature Specifications: Detection Principle: Measurement of heat using a thermistor Sampling Frequency: Once every four seconds Supply Voltage: 8.5 V dc to 33 V dc Supply Wiring: Two wire supply, polarity sensitive Power-up Time: < 20 seconds Minimum: ‘detector active’ voltage: 6 V Holding Voltage: 5 V - 33 V Minimum Holding Current: 8 mA  Minimum Voltage to Light Alarm LED: 5 V  Alarm Reset Voltage: < 1 V  Alarm Reset Time: One second  Alarm Indicator: Integral indicator with 360º visibility Operating & Storage Temperature: -40ºC to +70ºC Operation: Open-web casing that enables air to flow freely across a thermistor which measures the air temperature every two seconds  A microprocessor stores the temperatures and compares them with pre-set values to determine whether a fixed upper limit - the alarm level - has been reached Detectors the microprocessor uses algorithms to determine how fast the temperature is increasing

Read more less

Gasoline Fume Detector w/Blower Control -  Chrome Bezel - 12VThe Single Channel Gasoline Fume Detector is an effective means to monitor gasoline fumes in an engine compartment, fuel tank storage area or in other areas where gasoline fumes might accumulate.  Complete system includes Blower Control Relay, easy installation and precise monitoring.  Features: Simple Installation Audible and visual alarm to indicate LEL (Lower Explosive Level) presence  Monitors one (1) single area  Automatically activates bilge blower Technical Specifications: Operating Temperature: -40° to 185°F (-40° to 85°C) Current Draw Nominal - 55mA  Current Draw Maximum - 95mA Operating Voltage - 9 to 30V DC Alarm Horn - 68 dB Display Style - Round with Chrome Bezel Display Dimensions - 2-3/16" (5.6 cm) round Cutout Dimension - 2-1/16" (5.2 cm) round hole In the Box: Fume Detector Fuel sensors x one (1) 20' Extension Cable x one (1) Blower Relay x one (1) Instruction manual *Sold as an Individual  Specifications: Blower Relay: Yes Fume Type: Gasoline Generator Shutdown: No Sensors Included: 1 Voltage - Input Range (Volts): 9 to 30 Box Dimensions: 4"H x 4"W x 8"L WT: 1 lbs UPC: 619749202547 Owner's Manual (pdf)Brochure (pdf)

Read more less
