Products

P66 Transom Mount Transducer f/Humminbird #9 Connector UnitsFeatures: Depth and temperature in one housing Plastic kick-up bracket Accommodates transom angles between 2° and 20° Recessed waterflow channel protects paddlewheel Transducer can be removed from bracket without the use of tools for easy service and storage Boat Size: Up to 12M (40') Frequency: 50/200 kHz Beamwidth: 50 kHz-45°, 200 kHz-11° RMS Power: 600W 10M Cable Fits: All 800, 900 & 1100 Series except 967 3DThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Mounting Style: Transom Imaging: Standard Chirp: No Cable Length (Feet): 32' Temperature: Yes Speed Included: Yes Pins: 7 Box Dimensions: 4"H x 8"W x 11"L WT: 2.1 lbs

Read more less

P79 In-Hull Transducer w/Humminbird #9 Plug - 7-PinOur P79 in-hull transducer easily adjusts to hull dead rise angles up to 22º. This ensures that the beam is vertically oriented to receive echoes, resulting in accurate depth readings. Unlike traditional "puck" type transducers, our P79 consists of a base that is bonded to the hull and filled with liquid. The separate transducer then attaches to the base with a twist lock. The sound waves travel more efficiently though the liquid, giving the best possible performance.Features: Adjusts to hull deadrise angles from 2° to 22° No holes to drill Depth only Recommended for solid fiberglass hulls Adheres to aluminum hulls under 3.8 mm (0.16") thick Recommended for planing-hull power boats, trailered boats, rigid inflatable boats (RIBS), and racing sailboats No hull protrusions Boat Size: Up to 8M (25') Specifications: Weight: 2.3kg (5lb) Hull Deadrise: 0° to 22°   Acoustic Window: Layered plastic urethane This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Mounting Style: In-Hull Box Dimensions: 4"H x 8"W x 10"L WT: 1.8 lbs Owner's Manual (pdf)Brochure (pdf)

Read more less

Single Handle Transducer Nut Wrench for B260, SS260, B265C, B275C260-WR-2 fits B260, SS260, B265C and B275C. Specifications: Type: Tools Box Dimensions: 1"H x 3"W x 8"L WT: 0.5 lbs

Read more less

TM165HW Chirp High Wide 600W Transom Mount Transducer - Requires Adapter CableReplacing a non-Chirp or single frequency transducer with the AIRMAR TM165HW (High Wide) 600W Chirp-ready transom mount transducer provides anglers with an inexpensive and easy performance upgrade to their current sonar systems. The TM165HW is legendary for producing the finest detail and largest coverage area of any transom mounted model in its class. The TM165HW is perfect for fishing boats up to 25 feet (8 meters) and recommended for planing hulls made from fiberglass, metal or wood - both outboard and IO.TM165HW delivers large, crisp return images on the display with a noise-free, clear picture of the action below. Better coverage from top to bottom with stronger, well-defined fish targets.Super Wide 30° Average Beamwidth Achieves 3x the Coverage Under the Boat as Compared to Standard High Frequency Chirp-ready Transducers (eg, the popular B75H)The TM165HW is compatible with the following sonar brands and models:  Lowrance: All models compatible except Hook series Humminbird: SM300; Helix and Solix can be set manually Garmin: GPSMAP 7600, 8600, 7X2/9X2/10x2/12x2, GSD26 Raymarine: compatible with all models Simrad: compatible with all models Features: Depth and fast-response water-temperature sensor Requires Mix and Match cable 600 W with a maximum depth of 152 m (500')  High Frequency: 150 kHz to 250 kHz for superior shallow water performance, bottom detail and fish target separation High-wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Super wide 30° average beamwidth for superior coverage under the boat and maximum detection area High-performance, low-profile design provides excellent resolution at speed when installed properly  Exclusive Xducer ID® technology The TM165HW is an AIRMAR Mix and Match transducer. 600W Mix and Match transducers are made as a common base transducer with a short (9m) cable attached, plus an interchangeable longer 1m) brand-specific adapter cable.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Temperature: Yes Speed Included: No Pins: 12 Mounting Style: Transom Imaging: Standard Chirp: High Wide Cable Length (Feet): 30' Box Dimensions: 4"H x 8"W x 10"L WT: 2.55 lbs UPC: 801769002775 Brochure (pdf)

Read more less

TM185C-HW High Frequency Wide Beam CHIRP Transom Mount 14-Pin Transducer for HumminbirdGet more coverage under the boat with Airmar's wide beam Chirp. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, this transducer is truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using this wide beam transducer will achieve twice the coverage under the boat compared to our current high frequency Chirp transducers.A unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's wide beam format also creates crisper and larger return images on the display.Features: CHIRPS across the following bandwidths: — High-Frequency: 150-250 kHz 25° Constant Beamwidth 1kW (1,000 Watt) RMS Power Depth Range: 600'-800' Depth & fast-response water-temperature sensor Urethane housing and stainless steel kick-up mounting bracket Boat Size: 8 m to 12 m (25' to 40') Boat Type: Outboards; I/O Hull Type: Fiberglass, Wood, Metal Can retrofit to existing TM258, TM260, TM265, and TM275 bracket This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications:Chirp: High WideOwner's Manual (pdf)

Read more less

TM185C-HW-MM CHIRP Transducer Transom Mount Needs Mix & Match CableGet more coverage under the boat with Airmar's wide beam Chirp. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, this transducer is truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using this wide beam transducer will achieve twice the coverage under the boat compared to our current high frequency Chirp transducers.A unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's wide beam format also creates crisper and larger return images on the display.Features: CHIRPS across the following bandwidths: — High-Frequency: 150-250 kHz 25° Constant Beamwidth 1kW (1,000 Watt) RMS Power Depth Range: 600'-800' Depth & fast-response water-temperature sensor Urethane housing and stainless steel kick-up mounting bracket Boat Size: 8 m to 12 m (25' to 40') Boat Type: Outboards; I/O Hull Type: Fiberglass, Wood, Metal Can retrofit to existing TM258, TM260, TM265, and TM275 bracket Needs Mix & Match Cable This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications:Chirp: High Wide

Read more less

TM265C-LM-12F Transom Mount Transducer with 12-Pin Connector for Furuno TZT12F, TZT16F & TZT19FRely on Airmar's broadband transducers for the ultimate fishing mission! Whether you're a commercial fisherman, charter captain, or tournament angler, there's a new game in town. Traditional marine fishfinders operate at discreet frequencies such as 50 kHz and 200 kHz, use relatively short-duration pulses, and use narrowband sonar transducers. In contrast, CHIRP uses a precise sweep pattern of many frequencies within a long-duration transmits pulse from a broadband transducer, so the equivalent sound energy transmitted into the water is 10 to 1,000 times greater than a conventional marine fishfinder.Specifically designed for smaller boats (25'-40'), the TM265C-LM CHIRPS across the following bandwidths:Low & Medium-Frequency (LM)Low—Chirps from 42 kHz to 65 kHz, 25° to 16° beamwidthMedium—Chirps from 85 kHz to 135 kHz, 16° to 11° beamwidthMedium-frequency benefits include the ability to sound deeper than the high-frequency, along with better target resolution than the low-frequencyFeatures: 8-Internal, Broadband Ceramic Elements Depth & fast-response water-temperature sensor Fishing Profile: Commercial and recreational inshore and offshore fishing (deep-water canyon and sea-mount tracking) Operating frequencies: Low—Chirps from 42 kHz to 65 kHz Medium—Chirps from 85 kHz to 135 kHz Beamwidth (Adjustable): Low—25° to 16° Medium—24° to 16° 10 m (33’) cable The depth and fast-response water-temperature sensor 12 Pin Connector for use with Furuno TZT12F and TZT16F Displays Urethane transducer housing and stainless steel mounting bracket Boat Size: 8 m to 12 m (25’ to 40’) Hull Type: Fiberglass, wood, or metal Exclusive Transducer ID This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Cable Length (Feet): 30' Chirp: Low/Medium Imaging: Standard Mounting Style: Transom Pins: 12 Speed Included: No Temperature: Yes

Read more less

UDST800P-N2 Ultrasonic Smart Sensor - N2KThe UDST800 just turned your maintenance time into more cruising time…and made your boat smarter too. Ultrasonic speed, depth, and temperature in one single housing with no moving parts make this sensor high precision, low maintenance solution for use on power and sailboats of all types and sizes. Say goodbye to paddlewheel maintenance and hello to Smart technology, from the company that invented the Smart™ Sensor.Features: Ultrasonic Depth, Speed and Temperature in one housing Precise readings at high speeds ideal for powerboats, cruising, and sailing Data Update Rate: up to 10 x per second Advanced filtering & sampling rates for increased accuracy at all speeds Adapts automatically to boat speed, water depth, and water clarity keeping speed-accuracy consistent No moving parts – no paddlewheel Specifications: Correlation Speed Sensor Transmitting Frequency: 4.5 MHz Correlation Pulse Repetition Frequency: 0.5 kHz to 12 kHz (varies with speed) Speed Range: 0.1 to 50 knots (.1 MPH to 57 MPH) Available Outputs: NMEA2000® Water Temperature Range: -4°C to 40°C (32°F to 104°F) Depth: 235 kHz Depth Range: Minimum 0.6 m ( 2'), Maximum 100 m (328') Supply Voltage—NMEA2000®: 9 VDC to 16 VDC Supply Current: 80 mA - 200 mA, Average 125 mA @12VDC Thru-Hull Housing Material: Plastic (bronze or stainless steel optional) Thru-Hull Housing Diameter: 51 mm (2") CE Compliant: Yes Retrofits into AIRMAR P617V housing This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less
