Zeus A275L 3.15 Alternator with Case Ground (Common Rail) & Terminal BlockThe highest power output alternator in its size/class. Features: Engineered for high energy production. Suitable for marine, RV, military, and commercial applications. Rapidly charges large battery banks. Coolest operating temperatures for increased performance. Heat shedding coatings Rectifier located on housing exterior Dual cooling fans OEM components Optimized for performance at idle speeds. Reduces the need for a generator by creating additional power with your engine. Unleash peak performance with E-Coat/Cerakote, keeping the A275L cooler for sustained amperage output. Use the ARCO Zeus Bluetooth Alternator Regulator for maximum performance or lithium battery charging. SAE J1171 Certified. Models available with internal/external voltage regulator. Proudly made in the U.S.A. Technical Specifications: Voltage - 12v Field Type - P Rotor Poles - 16 Stator Size - 138mm Frame Size - Large Weight - 14.9 lbs/6.7 kg Regulation - Internal/External (Internally regulated with adaptor for optional external regulation.) Output Voltage - 14.1v (Default) Finish - (Black) Cerakote or E-coating Cut-In RPM - 1,061 Alternator RPM Maximum Alt RPM - 19,000 Battery Post - M8 Thread Post, Side Mount Standard Pulley - 49K6 (6-groove, 49mm) Pulley Mount - 17mm diameter shaft, 25mm long, threaded M17 x 1.5 Pulley Hardware - M17 x 1.5 x 24mm nut, w/ 18mm ID x 29mm OD washer (Included) Diodes - 6 positive, 6 negative, 50A Rated, Avalanche Max Output (Cold, 9,000 RPM) - 311 Amps Sustained Cruising Output (Hot, 6,000 RPM) - 227 Amps Sustained Idle Output (Hot, 3,000 RPM) - 198 Amps Max Continuous Operating Temperature - 110°C / 230°F Mounting Application:Must be used on Yanmar Common Rail introduced after 2013 (JH-CR, 3JH40, 4JH45, 4JH57, 4JH80, 4JH110) Quick Guide (pdf)Brochure (pdf)

Read more less

MultiPlus 12/1200 - 50-16 - 120V - VE. BusThe MultiPlus is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology, and a high-speed AC transfer switch in a single compact enclosure. Next to these primary functions, the MultiPlus has several advanced features, as outlined below.Parallel Operation and Three-Phase CapabilityUp to six Multis can operate in parallel to achieve higher power output.  In addition to parallel connection, three units can be configured for three-phase output.  PowerControl - Dealing with Limited Generator, Shore Side or Grid PowerWith the Multi Control Panel, a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.  PowerAssist - Boosting the Capacity of Shore or Generator PowerThis feature takes the principle of PowerControl to a further dimension. It allows MultiPlus to supplement the capacity of the alternative source. Where peak power is often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load is reduced, the spare power is used to recharge the battery.  Four Stage Adaptive Charger and Dual-Bank Battery ChargingThe main output provides a powerful charge to the battery system using advanced ‘adaptive charge’ software. The software fine-tunes the three-stage automatic process to suit the condition of the battery and adds a fourth stage for long periods of float charging. The adaptive charge process is described in more detail on the Charger datasheet and Victron's website under Technical Information. In addition to this, the MultiPlus will charge a second battery using an independent trickle charge output intended for a main engine or generator starter battery.  High Start-Up PowerIt is needed to start high-inrush loads such as power converters for LED lamps, halogen lamps, or electric tools.  Search ModeWhen Search Mode is ‘on’, the power consumption of the inverter in no-load operation is decreased by approx. 70%. In this mode, the Multi, when operating in inverter mode, is switched off in case of no load or very low load and switches on every two seconds for a short period. If the output current exceeds a set level, the inverter will continue to operate. If not, the inverter will shut down again.Programmable RelayBy default, the programmable relay is set as an alarm relay, i.e. the relay will de-energize in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low).  Remote On/Off/Charger OnThree pole connector.  On-Site System Configuring, Monitoring, and ControlAfter installation, the MultiPlus is ready to go. Some settings can be changed with DIP switches. 500/800/1200VA models: remote switch/battery charge voltage/inverter frequency/search mode. 1600/2000VA models:  battery charge voltage/search mode. For more settings use VE-Config or the VE. Bus Smart dongle.  Remote Configuring and MonitoringInstall a Cerbo GX or other GX product to connect to the internet. Operational data can be stored and displayed on Victron's VRM (Victron Remote Management) website, free of charge. When connected to the internet, systems can be accessed remotely, and settings can be changed. Specifications: PowerControl: Yes PowerAssist: Yes Transfer Switch (A): 16 Inverter Specifications: Input Voltage Range (V DC): 9,5 – 17 V Output voltage: 120 VAC, ± 2%  Continuous Output Power at 25°C (VA): 1200 Continuous Output Power at 25°C (W): 1000 Continuous Output Power at 40°C (W): 900 Continuous Output Power at 65°C (W): 600 Peak Power (W): 2400 Maximum Efficiency (%): 93 Zero Load Power (W): 13 Zero Load Power in Search Mode (W): 4 Charger Specifications: AC Input voltage range 95 - 140 V AC Input Frequency range: 55-66Hz Charge Voltage Absorption (V DC): 14,4  Charge Voltage Float (V DC): 13,8  Storage Mode (V DC): 13,2 Charge Current House Battery (A): 50  Charge Current Starter Battery (A): 1 Battery Temperature Sensor: Yes General Specifications: Programmable Relay: Yes (1x) Protection: a - g VE.Bus Communication Port: For parallel and three-phase operation, remote monitoring and system integration  (RJ45-splitter ASS030065510 needed for 500 / 800 / 1200 VA models) Remote On-Off: On/off/charger only DIP Switches: Yes Internal DC Fuse: 200A Operating Temperature Range: -40 - +65°C / -40 to 150°F (fan-assisted cooling), Humidity (non-condensing) max 95% Enclosure Specifications: Common Characteristics: Material & Color: aluminum (blue RAL 5012) / Protection category: IP 21 Battery-Connection: 35 mm² AC-Connection: G-ST18i connector Weight: 8.2 kg (18.1 lbs) Dimensions (H x W x D): 406 x 250 x 100 mm / 15.98 x 9.84 x 3.94 in. Standards: Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1 Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3  Automotive Directive: ECE R10-5 Protection: Output short circuit, Overload, Battery voltage too high, Battery voltage too low, Temperature too high, 230VAC on inverter output, Input voltage ripple too high Non-linear load, crest factor 3:1                                                                               Up to 25°C ambient                                                                                                                          Programmable relay which can be set for: general alarm, DC under voltage or generator start/stop        signal function. AC rating: 4 A at 120 V DC rating: 4 A up to 35 V, 1 A up to 60 V For parallel and three-phase operation an RJ45-splitter ASS030065510 is needed. Select remote behaviour, battery charge voltages and/or search mode Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Replacement 500A PCB for Shunt on BMV 702 & 712 MonitorsReplacement PCB only for 500 Amp shunt on BMV 702 & 712 MonitorsWarranty InfoPlease contact your dealer for any returns, repairs or support issues related to this product.

Read more less

CCGX Wi-Fi Module Simple (Nano USB)Use to connect a Victron Color Control GX to a wireless network.  Enter the wireless ID and Passwords using the Color Control GX.Features: USB 2.0 interface Data rate 802.11n, 802.11g, 802.11b Frequency band 2.4 GHz Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

7456 UL-489 Circuit Breaker - 15A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 15A AC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 240V AC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 5000A Specifications: Amperage: 15a Box Dimensions: 2"H x 3"W x 5"L WT: 0.25 lbs UPC: 632085074562

Read more less

7457 UL-489 Circuit Breaker - 20A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 20A AC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 240V AC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 5000A Specifications: Amperage: 20a Box Dimensions: 2"H x 3"W x 4"L WT: 0.25 lbs UPC: 632085074579

Read more less

Main + 22 Positions(16) 15A Single Pole Circuit Breakers(1) 100A C-Series Main Circuit Breaker(1) 8028 DC Micro Voltmeter(1) 8250 DC Analog Micro AmmeterWhite SwitchesFeatures: All positive, negative and grounding buses installed, fully pre-wired Panels with meters include toggle switch for mounting up to 3 battery banks All panels with analog meters are owner upgradable to 24 Volts with 8240 or 8243 (18-32V DC meters) All circuit label positions are backlit on standard panels - No kit required "ON" indicating LEDs installed in all circuit positions MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance Two-part polyurethane slate gray finish Heavy 1/8" aluminum 5052 alloy Industry standard height and width Countersunk mounting holes throughout Detailed installation instructions and cutout template included Includes set of 30 common Large Format Panel Labels Over 500 individual labels available WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Max Breaker Quantity: 22 AC/DC: DC Voltage: 12v Box Dimensions: 7"H x 14"W x 22"L WT: 8.3 lbs UPC: 632085083809 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Orion-TR 12/24-10A (240W) Isolated DC-DC ConverterIsolated Model - separate in and out (-) leads Remote On/Off TerminalThe remote on/off terminal eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or for example the engine run/stop switch. All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output CurrentAn unlimited number of units can be connected in parallel.  High Temperature Protected The output current will reduce at high ambient temperatures.  IP43 Protection When installed with the screw terminals oriented downward.  Screw Terminals No special tools are needed for installation.  Input Fuse (not replaceable) On 12 V and 24 V input models only.  Adjustable Output Voltage Not intended for battery charging (consider using an Orion-Tr Smart for battery charging).Specifications: Input Voltage Range: 8-17 V Under Voltage Shut Down: 7 V Under Voltage Restart: 7.5 V Nominal Output Voltage: 12.2 V Output Voltage Adjust Range: 10-15 V Output Voltage Tolerance: +/- 0,2 V Output Noise: 2 mV rms Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 10 A Maximum Output Current (10 S) at Nominal Output Voltage: 15 A Short Circuit Output Current: 25 A Cont. Output Power at 25 Degrees C: 280 W Cont. Output Power at 40 Degrees C: 240 W Efficiency: 88 % No Load Input Current (2): < 100 mA  Current Consumption: < 200uA when disabled via its remote port Galvanic Isolation: 200 VDC between input, output, and case Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C) Humidity: Max. 95 % non-condensing DC Connection: Screw terminals Maximum Cable Cross-Section: 16 mm² AWG6 Weight: 1.3 kg (3 lb) Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch) Safety Standards: EN 60950 Emission: EN 61000-6-3, EN 55014-1 Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2 Automotive Directive Standards: ECE R10-5 Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

7443 UL-489 Circuit Breaker - 20A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 20A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 80V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 10000A Specifications: Amperage: 20a Box Dimensions: 2"H x 3"W x 5"L WT: 0.25 lbs UPC: 632085074432

Read more less

360 Panel - Rocker Switch SPST - ON-OFFThe 360 Panel System uses an open frame to mount a broad selection of modules, allowing multiple functions to be combined in a single panel.This innovative design offers a wide choice of panel features, can accommodate future changes and permits rapid assembly. With options ranging from battery management to source selection, the 360 Panel System provides unmatched design flexibility.For use in 360 panels in the following modules: Gauge, DC Push Button + Switch, and DC Battery ManagementSpecifications: Action*:tON-OFF Pole/Throw**:tSPST Maximum Amperage***:10A @ 125V AC / 10A @ 12V DC / 10A @ 24V DC / 10A @ 250V AC Terminal Type:tQuick Connect Tab Terminal Size: 0.187" (4.75mm) Weight:0.08lb (0.04kg) *Action () = Momentary ON**Pole/Throw: SPST - Single Pole/Single ThrowSPDT - Single Pole/Double ThrowDPST - Double Pole/Single ThrowDPDT - Double Pole/Double Throw***Maximum Amperage - Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Throw/Pole: SPST Color: Black Action: On/Off Box Dimensions: 1"H x 3"W x 5"L WT: 0.01 lbs UPC: 632085074807 Quick Guide (pdf)Brochure (pdf)

Read more less

Mini OLED DC VoltmeterMonitors DC voltage on a bright, waterproof, daylight readable OLED screen Compact size enables mounting in any convenient location IP66 waterproof Reverse polarity protected Mounts in a common 1-1/8 in hole Specifications Meter: Voltage Nominal Voltage:12V/24V DC Resolution: 0.01DC Input Voltage Range: 8-36V DC Operating Current: 15mA Voltage Accuracy:±1.0% WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

m-LVD Low Voltage DisconnectSenses low battery voltage and automatically disconnects devices to save power for starting or to preserve battery lifeA dead battery is one of the most common reasons for a tow. Don't get stranded with a dead battery. The m-LVD senses low battery voltage and automatically disconnects non-essential devices to save power for starting or to preserve battery life. The m-LVD is ideal for any single battery boat or vehicle that wants to avoid getting stranded with a dead battery. Status light in both m-LVD and Remote Control Switch provides visual warning of low voltage state prior to disconnect Alarm output available for audible warning of low voltage state prior to disconnect (optional alarm required) Remote Control Switch Functions: Disconnect Voltage Adjustment - Sets desired disconnect voltage Override - Temporarily delays circuit disconnect for 10 minutes OFF - Temporarily disconnects circuits until voltage rises Override or OFF - Silences alarm (optional alarm required) Case design allows surface, front panel, or rear panel mounting Rear insulating cover protects rear contacts Waterproof - rated IP67 for temporary immersion WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
