85mm (3-3/8") VMH-35D Diesel Multifunction GaugeThe VMH 35-D is the perfect standalone solution for monitoring your diesel engine. With a configurable dial scale of 3000 or 4000 RPM, the VMH 35-D is a compact display that shows a wide amount of data from your engine, battery, tank, and GPS.Specific information about your diesel engine is provided with alarms, either received from the SAE J1939 bus or locally set through the embedded menu. Both 12V and 24V systems are supported, and EasyLink connectivity allows your dashboard to be expanded with additional VMH 14 satellite displays to keep your sensitive data under control. The embedded high-performance GPS receiver further enhances the display capabilities by adding speed, position, and heading data.The Veratron VMH 35 is designed with a mineral glass front that's optically bonded to the sun-readable hybrid display. A sleek brushed stainless steel bezel surrounds the device and fits into classic and modern marine décors.The embedded NMEA 2000 gateway distributes sensor data inputs such as fuel, trim, and tachometer to other devices like chartplotters, saving the need for an additional external converter.Powered by the latest microprocessor, the Veratron VMH 35 is blazingly fast. Yet even when set at full brightness, it draws a mere 170mA of power—a fraction of what comparably-sized TFT screens use.Features: High-performance GPS embedded 4x analog input for external sensorsWaterproof to IPX7 NMEA 2000 certified with embedded analog gateway SAE J1939 CAN portEasyLink output for up to 16 VMH 14 satellites In the Box: VMH35-D Gauge Mounting Spinlock Wire harness  Safety Instructions  *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 3-3/8" Gauge Type: Multifunction Series: VMH-35 Voltage - Input Range (Volts): 12-24v Box Dimensions: 4"H x 6"W x 6"L WT: 0.75 lbs UPC: 7640190290466 Owner's Manual (pdf)

Read more less

52mm (2-1/16") VMH-14 Multifunction GaugeThe VMH 14 instrument is a new-generation 52 mm EasyLink satellite instrument.Every VMH Master can control up to 16 VMH 14 satellites, and the installation cannot be more easy with the Veratron well-known daisy chain concept.Launch the App, define your settings, and then simply hold your mobile device in proximity of the VMH 14 device to transfer the configuration. And the configuration can also be done powerless! Features: Stylish black-glass design with brushed stainless-steel ring Digital display with configurable color bar graph Easily configured with a smartphone App One single device to support 8 different data types Technical Specifications: Voltage - 12v Connectivity - EasyLink & NFC  Required mounting depth - 40mm Operating Temperature - -20°C to +60°C  Storage Temperature - -30°C to +80°C  In the Box: VMH 14 Gauge 52mm Mounting Spinlock 52mm Rubber Sealing Gasket Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 2-1/16" Gauge Type: Multifunction Series: VMH Voltage - Input Range (Volts): 12v Box Dimensions: 3"H x 3"W x 4"L WT: 0.3 lbs UPC: 7640178729971 Owner's Manual (pdf)

Read more less

85mm (3-3/8") VMH-35 Multifunction GaugeThe Veratron VMH 35 is engineered for single inboard or outboard engine applications. The Veratron VMH 35 has an embedded NMEA 2000 gateway that distributes sensor data inputs such as fuel, trim, and tachometer to other devices like chartplotters.  This saves the need for an additional external converter.  Highly adaptable to a wide range of onboard networks, it's equipped with analog inputs, making it ideal for refitting with older engines.An integrated GPS makes the VMH 35 the perfect standalone navigation solution.  It integrates speed, compass, and position into the engine data information.  A dedicated Veratron IBS (Intelligent Battery System) input can provide critical 12V battery monitoring capabilities.The Veratron VMH 35 has a mineral glass front that's optically bonded to the sun-readable hybrid display.  A sleek, brushed stainless steel bezel surrounds the device and fits into classic and modern marine décors.  Because small boat consoles are often fully exposed, the round display is waterproof to IPX7 criteria, both front and back.  It fits a standard 3-3/8" panel cutout size.Features: Integrated high-performance GNSS receiver Integrated Analog to NMEA 2000 Gateway Waterproof to IPX7 Stylish black-glass design with brushed stainless-steel ring New generation sun-readable color hybrid display Intelligent Battery Sensor (IBS) port NMEA 2000® certified In the Box: VMH35 Gauge Mounting Spinlock Wire harness  Safety Instructions  *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 3-3/8" Gauge Type: Multifunction Series: VMH-35 Box Dimensions: 4"H x 6"W x 6"L WT: 0.75 lbs UPC: 7640178729773 Owner's Manual (pdf)Brochure (pdf)

Read more less

52MM (2-1/16") ViewLine Oil Temperature Gauge 120-300°F - Black Dial & BezelVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in identical color. Interchangeable bezel option.Features: 8 pole Tyco/Hirschmann MQS plug  Red LED Via Plus And Min Warning Light Operating voltage 8–32 V  Input signal: standard Ω values  Optional make-point switch can be connected  Reverse polarity protection  Anti-fog double lens  Front side protection rating IP67  52 mm installation diameter  50 mm installation depth  In the Box: Gauge Connection Cable Bezel Rubber Seal Spinlock Installation Instructions Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 2-1/16" Series: ViewLine Voltage - Input Range (Volts): 12/24 V Gauge Type: Oil Temp Box Dimensions: 5"H x 5"W x 5"L WT: 0.35 lbs UPC: 7640178723054 Owner's Manual (pdf)Brochure (pdf)

Read more less

52MM (2-1/16") ViewLine Transmission Oil Pressure 30 Bar/435 PSI - Black Dial & Round BezelVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in identical color. Interchangeable bezel option.Features: 8 pole Tyco/Hirschmann MQS plug  Red LED Via Plus And Min Warning Light Operating voltage 8–32 V  Input signal: standard Ω values  Optional make-point switch can be connected  Reverse polarity protection  Anti-fog double lens  Front side protection rating IP67  52 mm installation diameter  50 mm installation depth  In the Box: Gauge Connection Cable Bezel Rubber Seal Spinlock Installation Instructions Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Voltage - Input Range (Volts): 12/24 V Series: ViewLine Gauge Type: Oil Pressure Gauge Size: 2-1/16" Box Set: No Box Dimensions: 3"H x 3"W x 4"L WT: 0.35 lbs UPC: 7640178723009 Owner's Manual (pdf)

Read more less

52mm ViewLine Bezel - Triangular - BlackThe VDO ViewLine modular bezel concept offers true design flexibility in the layout of instrument panels.  The three attractive designs in Black, White or Chrome are suitable for every machinery instrument panel or special vehicle cockpit.  The range also includes bezels with flat, round and triangular profiles.  Each of the bezel designs is compatible with every ViewLine product.Features: Color - Black Bezel Profile - Triangular Size - 52mm Interchangeable Clip System *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Color: Black Box Dimensions: 1"H x 2"W x 2"L WT: 0.1 lbs UPC: 7640178724273

Read more less

52MM (2-1/16") ViewLine Trim Indicator Gauge Up/Down - Black Dial & Round BezelVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in identical color. Interchangeable bezel option.Features: 8 pole Tyco/Hirschmann MQS plug  Red LED Via Plus And Min Warning Light Operating voltage 8–32 V  Input signal: standard Ω values  Optional make-point switch can be connected  Reverse polarity protection  Anti-fog double lens  Front side protection rating IP67  52 mm installation diameter  50 mm installation depth  In the Box: Gauge Connection Cable Bezel Rubber Seal Spinlock Installation Instructions Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Series: ViewLine Gauge Type: Trim Guage Gauge Size: 2-1/16" Box Set: No Voltage - Input Range (Volts): 12/24 V Box Dimensions: 3"H x 3"W x 4"L WT: 0.35 lbs UPC: 7640178723085 Owner's Manual (pdf)

Read more less

Integrated Rudder Feedback UnitsOC15SUK27ETypically one of the most complex and time consuming aspects of autopilot installation is fitting the rudder feedback unit and ensuring that the geometry matches the full range of rudder movement. The solution is an integrated rudder feedback unit that directly mounts to the drive unit itself.The standard RFB unit's (OC15SUK27A - OC15SUK27E) are dedicated to a particular manufacturer.Both types are attached directly to the drive unit for simple installation. Specifications: Type: Parts Box Dimensions: 3"H x 6"W x 6"L WT: 0.5 lbs UPC: 628309166595

Read more less

GMI™ 20 Marine Instrument DisplayPerfectly Designed for Power & Sail VesselsThe GMI 20 digital marine instrument display is perfectly designed for both power and sail vessels. Designed to clearly show depth, speed, wind and 100+ marine and vessel parameters, its large, bright 4" color display with extra large digits is easy to read at a distance and 170 degree viewing angle.A glass-bonded finish lens prevents fogging and increases contrast. Daylight readability is enhanced with a high contrast color scheme. For enhanced night visibility, you have a choice of red/black, green/black or the normal night mode color scheme along with a dimmer control. Screens can be set to auto-scroll, cycling between pages automatically without your having to do a thing. This is especially advantageous to sailors as it allows you to install the unit(s) in a greater variety of locations on the vessel. Default profiles can be customized for powerboat, sailboat, fishing, engine/fuel, plus several other user-specified profiles. Power is supplied by the NMEA 2000® network.In addition, the GMI 20 also features a dedicated race timer that counts down and counts up, with an internal beeper. Included are 2 trim snap piece cover options which allow you to match the GMI 20 with the GPSMAP® 500/700 series, GPSMAP 8000 Glass Helm series or legacy Garmin chartplotters.Features: Marine instrument display clearly shows depth, speed, wind and 100+ marine and vessel parameters Large, bright 4" color glass-bonded lens display with anti-glare finish Easy to read from a distance and 170 degree viewing angle Enhanced night time readability with backlight dimmer and full color or red/black or green/black color schemes Enhanced daylight readability with new high contrast color option Specifications: Dimensions without sun cover (HxWxD): 110 x 115 x 30 mm (4.33" x 4.53" x 1.18") Dimensions with sun cover (HxWxD): 115 x 120 x 35.5 mm (4.53" x 4.72" x 1.40") Weight without sun cover: 247 g (8.71 oz) Weight with sun cover: 283 g (9.98 oz) Temperature range: From 5x to 158x F (from -15x to 70x C) Compass-safe distance: 209 mm (8.25") Case material: Polycarbonate, waterproof to IPX7 Power usage: 2.5 W max Unit max. voltage: 32 Vdc NMEA 2000r input voltage: 9-16 Vdc NMEA 2000 load equivalency number (LEN): 6 (300 mA at 9 Vdc) In The box GMI™ 20* Black trim piece snap cover Protective cover Flush mount gasket and hardware NMEA 2000® T-connector NMEA 2000 drop cable Documentation WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Shape: Square Screen Size: 4" Instrument Function: Multifunction Box Dimensions: 4"H x 9"W x 10"L WT: 2.75 lbs UPC: 753759996918 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

A295 Dual Payload 384x288 Thermal + 1080P (10x Zoom) Visible Spectrum IP PTZ CameraThe IRIS-A295 Low-Cost Dual Payload Night Vision PTZ From Iris Innovations.With an industry-leading 400×300 thermal resolution, the cameras also feature a 2MP high-definition visible spectrum camera core with excellent low light performance, super sharp footage, and 10x optical zoom capabilities.Available with side entry or base entry cable options, the cameras are built into a robust yet compact waterproof case, designed to protect the unit from the harshest environmental conditions.Each sensor has its IP address meaning the cameras can be configured, controlled, and switched independently, and are compatible with many leading marine chart plotters via our range of CMAC camera management interfaces. An RS485 Serial Data connection is also provided to maximize control options so Atom cameras can be controlled using suitable joystick control devices and NVRs. With its rugged, compact footprint and extremely competitive pricing, our ATOM range of IP PTZ cameras is the perfect solution for vessels of all types and sizes and our industry-leading thermal imaging technology opens up a world of boating at night in safety. Standing only 8″ high, ATOM cameras blend into the vessel's aesthetic without standing out, and because they are so small they are the perfect camera solution for RIBs, center consoles, and sports fishing boats.To maximize compatibility, the ATOM-A295 is both ONVIF compliant and as the camera is also NDAA compliant, can be used for government, military, and other security-sensitive applications.Features: Dual Spectrum Cameras - Thermal & Visible Spectrum Visible Spectrum Camera 2MP HD Resolution 10x Optical Zoom 384x288 (A295) thermal core resolution - 4x Digital Zoom Miniature - Lightweight Compact Form Factor Dimensions 206mm x 160mmø / 2Kg Weight Available with single IP address or dual IP addresses Side mount or Rear mount Waterproof Cable Connector Push Lock Quick Connector - IP66 17µm Pixel Pitch Features IP and RS485 Serial Data Control 750mA @ +12VDC Power / 8.4W IP66 Environmental Rating Technical Specifications: Thermal Camera Resolution - 384x288 Thermal Camera Lens - 19mm Pixel Pitch - 17µm Refresh Rate - 25/30Hz Color Pallets - White Hot / Black Hot / Fulgurite / Iron Red / Hot Iron / Medical / Arctic / Rainbow 1 / Rainbow 2 / Tint Image Enhancement - ICE® Image Contrast Enhancement - 7 Levels Zoom - x4 Smooth Digital Zoom - Continuous Visible Spectrum Camera - 1/2.8” High-Performance Low Illumination SONY CMOS Sensor IMX327 Resolution - 1920 x 1080 25/30 frames/sec Focal Length / Iris / Zoom - F = 4.7mm 94mm / F1.6 F3.5 / 20x Optical Zoom Compression - H.264 / H.265 Bit Rate - 32Kbps 16Mbps Frame Rate - 1-25fps(50Hz) / 1-30fps(60Hz) Streams - Supports dual stream, main stream (1080P; 960P; 720P), Sub Stream (D1; VGA; CIF) Cellular/WiFi/GPS - Optional Protocols - Network Protocols: ONVIF Profile S / Others TBC Serial Data: RS485 / Pelco D Power Requirements - +12vDC / 750mA / 8.4W This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

HDMI to IP Encoder - Converts HDMI to IP - Compatible with Raymarine, Simrad & FurunoConvert your HDMI video source to a high-definition IP stream compatible with Raymarine, Simrad, B & G, and Furuno Chart-Plotters using the HDMI2IP-01 Single Channel Encoder from Iris Innovations.This small and compact little box takes your HDMI video and uses H.265 / H.264 compression algorithms to encode the video into a high-definition IP stream which leading a chartplotters process as if it were an IP camera device. Simply configure the device to sit on your MFD network, hook up your HDMI camera, and then configure your MFD in the same way you would configure an IP camera. If your MFD works as an RTSP server (such as Raymarine Axiom and Furuno TZT devices) simply set the HDMI2IP unit to accept its IP address via RTSP and you are good to go.Your MFD will treat the stream as if it were an IP camera, which means once configured, the video will display on all compatible devices connected to your MFD network, greatly simplifying installation.The device is powered from your vessel (or vehicle’s) +12VDC supply and draws less than 200mA.Features: Converts High Definition HDMI video into IP video streams using H.265 / H264 Compression Compatible with Raymarine, Navico (Simrad / B & G), and Furuno Chart-Plotters HDMI Devices Handled as IP Cameras by Compatible MFD’s Perfect for Displaying HD Video Ouput from CMAC on your Chartplotter Connect to the MFD Network to View Video on all Connected, Compatible Devices Low Power, +12VDC Operation. Small, Compact, and Easy to Install Supports Audio Can be Used to Encode any HDMI Video Source This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

Hi-Resolution Analog Mini Dome Camera - 316 Stainless Steel - CVBS - TVI - 3.6Iris’s SX60 range of miniature marine grade stainless steel cameras are available in multiple formats and deliver the highest quality video to suit your application.The IRIS-S060 features a multi-format 4-in-1 camera module (CVBS, TVI, CVI, AHD) designed for maximum compatibility with most marine chart plotters, digital recorders, and monitors.The IRIS-S060 can be set to output analog video (CVBS), or a range of Analogue Hi-Def formats (HD-TVI, HD-CVI, AHD) providing up to 1080P high-definition resolutions in real-time. When used with an IRIS HD switcher or HVR or our TVI to HDMI converter, the IRIS-S060 can be connected to HD TVs and MFDs with digital inputs such as Garmins 8000 series or Simrads NSO Series.Like all models in our 60 range, the cameras are shipped as standard with a 3.6mm lens offering 80 HFOV, with a wide-angle 2.1mm lens (110 HFOV) and ultra-wide-angle 1.8mm lens (125 HFOV) options available.The S060’s 316 stainless steel housing provides the ultimate protection in the harsh marine environment and is, therefore, the perfect solution for deck monitoring aboard workboats, fishing vessels, and passenger vessels, while fitting in equally as well with the high-end aesthetic of luxury vessels and mega yachts.Measuring only 58mm high by 60mm in diameter, the S060 is small enough to provide unobtrusive surveillance and also for use in areas where space is tight, such as engine rooms or anchor wells.Whether you need high quality and rugged camera as part of your onboard surveillance system, for the engine room, deck, and companionway monitoring, or as a robust and stylish docking or backup camera, our IRIS-SX60 range of cameras is the perfect solution.Features: Marine Grade 316 Stainless Steel Rugged Corrosion Free Case Features 4-in-1 Video Format Camera Module (CVBS/TVI/CVI/AHD) Available in High Polish (standard), Brushed, or Custom Paint Finish Analog (CVBS/Composite Video) Resolution 1000TVL Set to TVI for 1080P HD Resolution in Real Time (No Network Latency) Built In Infra Red LED Illumination (10M Range) Extremely Low Power Consumption IP66 Environmental Protection This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Quick Guide (pdf)
