Sailing - Blocks

40mm Carbo Air Pivoting Lead Block with Aluminum Cam-Matic® CleatHigh-strength pivoting lead blocks with cams are used for halyard controls on larger keelboats and as “headknockers” on dinghies and beachcats for sheeting directly from the boom. Hole spacing and rivet size are the same as Classic models, making upgrades easy. Cam reverses for either up or down cleating.Can be used as becket block.Specifications: Sheave Ø (mm)40 mm Sheave Ø (in)1 9/16 in Maximum line Ø (mm)10 mm Maximum line Ø (in)3/8 in Maximum working load (kg)136 kg Maximum working load (lb)300 lb

Read more less

40mm Carbo Air Fiddle Block with Swivel & BecketLow-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to the popular Harken® Black Magic® line, these small, compact blocks have very high working loads for safe, easy trimming. The 40 mm fiddle is an excellent choice for 3:1 and 4:1 tackles on dinghy vangs and mainsheets, as well as for controls such as cunninghams and internal boom outhauls on larger boats.Specifications: Sheave: 40mm / 1-9/16in Length: 131mm / 5-1/8in Weight: 54g / 1.9oz Shackle pin: 4mm / 5/32in Maximum line: 10mm / 3/8in Maximum working load: 220kg / 485lb Breaking load: 735kg / 1620lb

Read more less

22mm Double Micro BlockLow-friction Micro blocks are compact and lightweight. Specifications: Sheave: 22mm / 7/8in. Length: 51mm / 2in. Weight: 43g / 1.5oz. Maximum line: 6mm / 1/4in. Maximum working load: 159kg / 350lb Breaking load: 544kg/ 1200 lb

Read more less

Spring Loaded/Lined Slide/Aluminum for 1" T-TrackDelrin™ sheave ensures smooth operation and high safe working load. Anodized aluminum cheeks and stainless steel slider ensure reliability. Polyethylene liner and pin stop allow for easy adjustment. Specifications: Track Size 1" x 1/8" (25 mm x 3 mm) Max. Boat Length- 27' (8m) Max. Boat Weight- 5000 lbs. (2270 kgs) Sail Area- 315 sq. ft (29 m2) Sheave Diameter 2" (51 mm) Max Line 7/16" (11 mm) Length 3" (76 mm) Width 1-1/4" (31 mm) Height 4-5/32" (105 mm) Bearing Height 2-7/32" (56 mm) SWL 1750 lbs. (795 kg) Weight 7.0 oz. (198 g)

Read more less

Series 30 Ball Bearing Orbit Block™ - Stand Up SwivelBall Bearing Orbit Blocks™ boast the highest strength-to-weight ratio available. This is achieved through all-composite reinforced polymer materials and multiple attachment options. Their precision design provides the optimum number of ball bearings for minimum friction while weight reduction is achieved through the use of fiber-reinforced composites in the block head, cleat arms and beckets.Features: Lightweight Highest working load in its class Secure, versatile and secure attachement Low profile and compact Applications: Mainsheet systems and spinnaker sheets on dinghies to 5M(16') Halyard, vang and backstay applications on boats to 5M(16') Control line applications on larger yachts Materials: Sheave: High compression strength carbon black Acetal Ball Bearings: High compression strength Acetal Frame/Cheeks: Toughened, glass fiber reinforced Nylon Link: UV stabilized, multi-strand impregnated SK75 Dyneema® Specifications:Sheave Ø: 30mm(1-3/16")Max. Rope Ø: 8mm(5/16")M.W.L.: 300kg(660lbs)B. L.: 600kg(1,320lbs)Weight: 33g(1.2oz)

Read more less

Series 40 Ratchet Orbit Block™ - Single - Auto - Swivel Shackle HeadAutomatic RatchetWith automatic models, the ratchet mechanism engages when load is applied, but switches off when it's released. This lets the sheet run out smoothly and freely-great for rapid easing of the sheet and for gybing asymmetric spinnakers.Awesome Ratchet Block Holding PowerQuite simply, Ronstan Ratchet Orbit Blocks™ have the highest holding power available. The sophisticated NC-machined sheave features Generation 2 of our sheave cross-hole geometry. The Series 40 delivers up to 14:1 holding power, almost double that of our nearest competititor.The unique sheave design has 8 gripping faces which directly resist loaded line movement. Traditional designs have an angled resistance to line movement. Our Generation 2 design has straight resistance faces which both distribute the load and minimise rope wear. These faces are offset from the radial line, to draw the rope down into the gripping area when under load.Simple and Secure AttachmentThe Dyneema® Link is easily fitted and is retained securely by a moulded retainer clip. The flexible link can be left with one end attached to the block when fitting - no more lost shackle pins.The system is compatible with Dyneema®/Spectra® strops, webbing and carbon connection points - much more so than steel loop tops or shackles.Smooth Easing of SheetsWith auto models the sheet runs out smoothly and freely as soon as the ratchet mechanism disengages. Low Profile Stand-Up Kit Allows 0™ or 90™ AlignmentStand-up kits feature a clatter-free rubber boot. You can attach the Dyneema® link so that the block is aligned with the stand-up base or across it. It's a neat low-profile solution which allows full articulation.Features: Up to 14:1 holding power - highest available! Smooth easing of sheets Fully Automatic load sensing ratchet engagemen Swivel shackle head for unlmited block rotation Stainless steel shackle head for ultimate durability and compatibility with harsh fixing points Applications: Dinghy mainsheet systems Mainsheet fine tune systems on sportsboats & small keel boats Mainsheet systems on sportsboats using RF7 mainsheet swivel cleat unit Spinnaker and job sheets on dinghies - especially modern asymmetric classes Control line applications on larger yachts Materials: Sheave: Hard anodised Aluminium Ball Bearings: High compression strength carbon black Acetal Frame/Cheeks: Toughened, glass fiber reinforced Nylon Rope Link: UV stabilized, multi-strand impregnated SK75 Dyneema® Specifications:Sheave Ø: 40mm(1-9/16")Max. Rope Ø: 9mm(5/16")M.W.L.: 175kg(385lbs)B. L.: 500kg(1,100lbs)Weight: 44g(1.5oz)

Read more less

Size 2 Single Cheek BlockPlain Bearing BlocksBarton plain bearing blocks have a precision molded acetal sheave running on a large diameter brass bearing, ensuring free running under the highest of loads.Specifications Sheave size: 35mm x 12mm Max rope diameter: 8mm Safe working load: 370kg / 815lbs Breaking load: 740kg / 1630lbs Length: 80mm Weight: 73g

Read more less

40mm Carbo Air Block with Cam CleatLow-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to the popular Harken Black Magic block line, these small, compact blocks have very high working loads for safe, easy trimming. Specifications: Sheave Ø (mm)40 mm Sheave Ø (in)1 9/16 in Maximum line Ø (mm)6 mm Maximum line Ø (in)1/4 in Maximum working load (kg)68 kg Maximum working load (lb)150 lb

Read more less

16mm Block with SwivelThe 16 mm is Harken’s® smallest block. It is perfect for small synthetic control lines found on high-tech dinghies. The patented bearing system uses stainless steel balls in a captive grooved race and has a 250 lb (113 kg) maximum working load.Specifications: Sheave: 16mm / 5/8in. Length: 46mm / 1-13/16in. Weight: 18g / .63oz Shackle pin: 4mm / 5/32in Maximum line: 5mm / 7/32 Maximum working load: 113kg/ 250lb Breaking load: 339kg / 750lb

Read more less

Series 40 All Purpose Block - Double Block - Full Swivel HeadAll purpose (AP) blocks are a great all around solution. Self-lubricating Acetal polymer sheaves running on polished stainless steel races perform equally well with dynamic loads and high static loads. For durability and a long service life, these blocks are the right choice for sheets, halyards and control line applications for cruising and racing. Head swivels freely.Features: Exceptionally high working loads Low maintenance, long service life Self-lubricating sheave Slotted pin shackle eliminates fouled lines Two way head post Applications: Mainsheet Halyard Vang Spinnaker control lines on off-the-beach catamarans, one design classes and sportsboats up to 8M(26') Materials: U.V. stabilized Acetal sheaves Impact and U.V. resistant, fiber reinforced Nylon cheeks Grade 316 stainless steel bearing race Grade 316 stainless steel load strap and head fitting Specifications: Sheave Ø: 40mm(1-9/16") Max. Rope Ø: 10mm(7/16") Pin Ø: 5mm(3/16") M.W.L.: 600kg(1,320lbs) B. L.: 1,200kg(2,650lbs) Weight: 135g(4.8oz)

Read more less

Series 5 Fiddle Swivel Block- 54mmPlain Bearing BlocksBarton plain bearing blocks have a precision moulded acetal sheave running on a large diameter brass bearing, ensuring free running under the highest of loads.Specifications Sheave size: 54mm x 17mm Max rope diameter: 12mm Safe working load: 750kg / 1650lbs Breaking load: 1500kg / 3300lbs Length: 185mm Weight: 300g

Read more less

Plain Bearing Pulley Block Back to Back Swivel Block - Size 1, 30mmThe Size 1 Plain Bearing Blocks have a 30mm (1-3/16") sheave. The range is designed with an internal steel frame for added strength and durability. Also available in ball bearing sheave options, the lightweight modern design is available in variations that allow for a multitude of uses on every size craft.Suitable for up to 8mm (5/16") rope.

Read more less
