FRX15 Friction Ring - 15mm (19/32")Features: Efficient and light FRX Wichard thimbles are efficient, light, and reliable Very strong and can be used for heavy loads and semi-static lines FRX thimbles are designed to make your lines run smoothly with minimum wear They are hard anodized (50 microns) for a longer lifespan Applications:Mast-foot block, barber-hauler, inhauler, loop, thimble, lazy jack, running backstay, tackle, and moreSpecifications: Materials: Anodized aluminium Working load: (lb) 3520 / (kg) 1600 Weight: (lb) 0.026 / (g) 12 A: (inch) 25/64" / (mm) 10 B: (inch) 19/32" / (mm) 15 C: (inch) 19/32" / (mm) 15 D diameter: (inch) 1 3/8" / (mm) 35 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Removable Eye Deck Plate/AssemblySpecifications:  Eye Width 5/8" (16 mm) Eye Height 5/8" (16 mm) Eye Stock 1/4" (6 mm) Length 3" (76 mm) Width 3" (76 mm) Fasteners (4), 1/4" FH (6 mm) C/C A 2" (51 mm) C/C B 2" (51 mm) SWL 2250 lbs. (1020 kg) Weight 9.5 oz. (269 g) Deck plate hole is 3/4"-10

Read more less

Stainless Steel Cleat - 8"8" SS Open Base Cleat. Includes urethane washers for isolation when attaching to spars. Maximum line size 5/8" (16mm), Length 8" (203mm), Height 2.0" (51mm), Fastener size 5/16" FH, Fastener center/center 2.0" (51mm), Weight 1.3 lb (.59kg)

Read more less

2" Delrin Ball Bearing SheaveSpecifications: Material: Delrin (BB) Max Line 1/2" (13 mm) Outside Dia. 2" (51 mm) Inside Dia 3/16" (5 mm) Width 5/8" (16 mm)

Read more less

Stainless 1-1/4" T-Track Slider - Eye Slide/LinedSpecifications: Track Size 1-1/4" x 3/16" (32 mm x 5 mm) Max. Boat Length 38' (10 m) Max. Boat Weight 12000 lbs. (5455 kg) Max. Sail Area 520 sq. ft. (48 m2) Length 4" (102 mm) Width 1-11/16" (43 mm) Height 1-3/4" (45 mm) Eye 1" (25 mm) Eye29/32" (23 mm) SWL 2500 lbs. (1134 kg) Weight 7.5 oz (213 g) Specifications: Color: Stainless Box Dimensions: 2"H x 3"W x 5"L WT: 0.65 lbs UPC: 740507021343

Read more less

Shock - 3/8" Line - 3/8" Webbing - BlueThe Sheaveless BlackThe obvious choice for those kitesurfers, paragliders, control line deflections and purchase systems that require a lightweight high load capacity block.Ultimate durabilityWith no moving parts SHOCKS provide ultimate durability and are maintenance free. They are ideal where sand and grit would compromise a bearing system or where regular flushing out isn?t possible. Their gentle 3-dimensional geometry is kind on lines, but is strong enough to cope with poor leads.Soft attachment specialistsSHOCKS are designed primarily for 'soft attachment'; spliced to a line end or lashed in place. The elongated attachment aperture is also ideal for webbing attachment, ensuring the intended orientation is maintained.Virtually limitless applicationsThe applications for SHOCKS are virtually limitless, including numerous high performance dinghy and small sailboat rigging applications including tweakers, vangs, trapezes, cunninghams, barber haulers and kite bridles. They are also handy on larger boats for uses such as lazy jacks, sail covers, tie-downs, ladder and motor hoists.Hidden performanceAt a mere 2.5g (0.1 oz), SHOCKS are outstanding performers in the strength and weight stakes. The clever design and exacting finishing also provide excellent free running at moderate changes of angle. Small & hi-tech line specialists SHOCKS accept lines from 1.4mm (1/16") up to 8mm (5/16") and function just as well with hi-tech uncovered braids as with traditional double braids.Features: Performance & versatility Ultra lightweight Ultra compact Durable Color coded Impact resistant Small line optimised High load capacity Poor alignment tolerant Soft attachment compatible Grit & salt resistant Applications:Unlimited uses, including kitesurfing, paragliders, sports kites, power kites, stunt kites, depower kites, traction kites, for deflection or purchase system on control linesMaterials:Anodized AluminumSpecifications:Rope Ø:1.4mm-10mm(1/16" - 3/8")Height:14.5mm(9/16")Width: 24.8mm(1")Length:36mm(1-7/16")B. L.:1,000kg(2,200lbs)Weight:12g(0.42oz) Specifications: Color: Blue Box Dimensions: 1"H x 1"W x 1"L WT: 0.1 lbs UPC: 9316800525959

Read more less

Stainless Steel Cleat - 4.75"4.75" SS Open Base Cleat. Includes urethane washers for isolation when attaching to spars. Maximum line size 3/8" (10mm), Length 4.75" (120mm), Height .9" (23mm), Fastener size #10 FH, Fastener center/center 1.25" (32mm), Weight 4.1oz (.12kg)

Read more less

Deck Organizer - Size 2 - 2 Sheave - Black Designed for use when diverting mast base control lines and halyards back to the cockpit.  Allowing the crew to sail from the security of the cockpit.Suitable for boats up to 32' (9.75 M) with halyard size up to 9/16"Deck organizers can be double stacked.Technical Specifications: Material - Spectro Anodized Aluminum  Dimensions (L x W x H) - 5.83" x 1.5" x 1.1" (148 x 38 x 28 mm)  Weight -  7.23 oz  (205 g)   Sheave Material - Molded Acetal Sheave Diameter - 1.73" (44 mm) Sheave Width - .71" (18 mm) Maximum Line Diameter - .55" (14 mm) *Sold as an Individual  Brochure (pdf)

Read more less

"Captain Hook" Chain Snubber Small Snubber Hook Only (5/16" T-316 Stainless Steel Stock)The "Captain Hook" Chain Snubber can be used in a few different ways: Use the claw and attached line to relieve tension from your windlass while anchored by snubbing the chain overboard and tying off the line to a cleat or samson post on deck Use the snubber on deck for security to hold the chain in your anchor roller and tie off on a cleat while underway for peace of mind Relieve the tension on the windlass (like in 1) by attaching the snubber to the chain in the anchor roller and pulling back and tying it off securely All T-316 stainless. Version with 3-strand nylon line includes professional eye splice.Note: Always keep the bitter end of the anchor chain secure in the windlass while using the chain snubber.

Read more less

Quick Link - 8mm(5/16") DiameterQuick Links have large openings and secure threaded locking sleavesGrade 316 Stainless Steel Specifications: Color: Stainless Box Dimensions: 1"H x 2"W x 3"L WT: 0.18 lbs UPC: 9316800040797

Read more less

Size 1 30mm Plain Bearing Pulley Block Single Fixed EyeThe Size 1 Plain Bearing Blocks have a 30mm (1 3/16") sheave. The range is designed with an internal steel frame for added strength and durability. Also available in ball bearing sheave options, the lightweight modern design is available in variations that allow for a multitude of uses on every size craft.The 30mm sheave Size 1 block range is designed with an internal steel frame for added strength and durability. Available in plain and ball-bearing sheave options, the lightweight modern design is available in variations that allow for a multitude of uses on every size craft.Suitable for up to 8mm (5/16") rope. Quick Guide (pdf)

Read more less

13mm Low Beam Track - 2MThis track is extruded from high-grade 6061-T6 aluminum and hard coat-anodized for a hard, long-lasting surface.Specifications: Weight (g): 429 g Weight (oz): 15.1 oz Mounting Hole Spacing (mm): 50 mm Mounting Hole Spacing (in): 1-31/32 in Fasteners (mm): 4 FH mm Fasteners (in): #8 FH in Minimum Curved Track Radius (m): 1.52 m Minimum Curved Track Radius (ft): 5 ft Length (m): 2 m Length (ft in): 6' 7" ft in Line Shedding Endstop: 2706 Splice Link: 2711
