Self-Locking Large Shackle - Diameter 5mm - 3/16"Features:  Self-locking large shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications:For applications where a large opening shackle is requiredSpecifications: Materials 316 stainless steel grade Working load (lb) 550 WLL (lb) 480 Breaking load (lb) 2420 Weight (lb) 0.035 Dimensions (see 2nd image): A (inch) 1-27/64" B (inch) 25/32" C (inch) 13/64" D (inch) 7/16" D diameter (inch) 13/64" E (inch) 13/64" F (inch) 1-57/64" G (inch) 1-3/8"

Read more less

Self-Locking Long D Shackle - 10mm Diameter - 13/32"Features:  Self-locking D shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications Standard applications of shackle requiring more length Attachment applications: blocks, head Specifications: Materials: 316 stainless steel grade Working load: (lb) 3350 / (kg) 1520  WLL: (lb) 1890 / (kg) 860  Breaking load: (lb) 9470 / (kg) 4300  Weight: (lb) 0.282 / (kg) 4300  Dimensions: A: (inch) 2 11/64" / (mm) 55  B: (inch) 25/32" / (mm) 20  C: (inch) 25/64" / (mm) 10  D: (inch) 3/4" / (mm) 19  D diameter: (inch) 25/64" / (mm) 10  E: (inch) 23/64" / (mm) 9  G: (inch) 3 7/64" / (mm) 79  H: (inch) 2 3/64" / (mm) 52  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Long D Shackle - Diameter 6mm - 1/4"Features: Self-locking long shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications CE Marking and batch number Applications: Standard applications of shackle requiring more length Attachment applications: blocks, head... Specifications: Materials 316 stainless steel grade Working load (lb) 1320 WLL (lb) 700 Breaking load (lb) 3520 Weight (lb) 0.06 Dimensions (see 2nd image): A (inch) 1-19/64" B (inch) 15/32" C (inch) 15/64" D (inch) 15/32" D diameter (inch) 15/64" E (inch) 13/64" F (inch) 1-27/32" G (inch) 1-7/32"

Read more less

Self-Locking Long D Shackle - Diameter 8mm - 5/16"Features: Self-locking long shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications CE Marking and batch number Applications: Standard applications of shackle requiring more length Attachment applications: blocks, head… Specifications: Materials 316 stainless steel grade Working load (lb) 2200 WLL (lb) 1190 Breaking load (lb) 5950 Weight (lb) 0.146 Dimensions (see 2nd image): A (inch) 1-49/64" B (inch) 5/8" C (inch) 5/16" D (inch) 5/8" D diameter (inch) 5/16" E (inch) 9/32" F (inch) 2-33/64" G (inch) 1-39/64"

Read more less

Self-Locking Twisted Shackle - Diameter 10mm - 13/32" Features: Self-locking twisted shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads Applications: Perfect for applications where a  90° angle twist setup is required Often used to attach an unarticulated part (block on a rail) or on purchases Specifications: Materials: 316 stainless steel grade Working load: (lb) 3170 / (kg) 1440  Breaking load: (lb) 9920 / (kg) 4500  Weight: (lb) 0.28 / (g) 127  Dimensions: A: (inch) 1 31/32" / (mm) 50  B: (inch) 25/32" / (mm) 20  C: (inch) 25/64" / (mm) 10  D: (inch) 3/4" / (mm) 19  D diameter: (inch) 25/64" / (mm) 10  E: (inch) 23/64" / (mm) 9  F: (inch) 2 29/32" / (mm) 74  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Twisted Shackle - Diameter 6mm - 1/4"Features: Self-locking twisted shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads Applications: Perfect for application where a  90° angle twist setup is required Often used to attach an unarticulated part (block on a rail) or on purchases Specifications: Materials 316 stainless steel grade Working load (lb) 1320 Breaking load (lb) 3300 Weight (lb) 0.06 Dimensions (see 2nd page): A (inch) 1-3/16" B (inch) 15/32" C (inch) 15/64" D (inch) 15/32" D diameter (inch) 15/64" E (inch) 13/64" F (inch) 1-49/64"

Read more less

Self-Locking Twisted Shackle - Diameter 8mm - 5/16"Features: Self-locking twisted shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads Applications: Perfect for application where a 90° angle twist setup is required Often used to attach an unarticulated part (block on a rail) or on purchases Specifications: Materials 316 stainless steel grade Working load (lb) 2200 Breaking load (lb) 6610 Weight (lb) 0.148 Dimensions (see 2nd image): A (inch)1-37/64" B (inch) 5/8" C (inch) 5/16" D (inch) 5/8" D diameter (inch) 5/16" E (inch) 9/32" F (inch) 2-23/64"

Read more less

Single Articulated Fairlead for 25mm & 28mm Diameter StanchionFeatures:Stainless steel Applications:The perfect solution to deviate furling line of manual furlers or flying sail furlers with drumSpecifications: Max line diameter: (inch) 25/32" / (mm) 20  Materials: 316L stainless steel grade Weight: (lb) 0.243 / (g) 110 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Single Fairlead - 25mm Diameter Stanchion - FixedThe single fairlead has been designed to be installed on a 25 mm stanchion and can be fitted with a 20 mm furling line. This fairlead has no moving parts and thus offers a greater lifespan and minimal maintenance.Applications:Perfect solution to deviate furling line of manual furlers or flying sail furlers with drumSpecifications: Materials: 316L stainless steel grade Weight: (lb) 0.176 / (g) 80 Diameter: (inch) 0.98" / (mm) 25 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Small Anchor Swivel 1/4" - 5/16"Wichard anchor swivels are designed to simplify anchoring operations, especially when hoisting the anchor. Their unique design ensures that the anchor automatically aligns itself correctly in the bow roller, even if it comes up in the wrong orientation. The Small Anchor Swivel suits 1/4" and 5/16" (6mm and 8mm) anchor chains.Features: Anchor chains from 6 to 8 mm Self-aligning to the bow roller Optimized dimensions Compatible with most anchors on the market Quality stainless steel construction for strength and corrosion resistance 316L Stainless Steel Brochure (pdf)
