Fibre reinforced engineering nylon offers strength, resilience and reliability. Also comes with a removable gimbal pin Comes with no mount, enabling you to choose whichever mount suits your needs seperately.
Screwless Flush Mount Rod Holder - 0 Degree - Black Liner - No LogoFeatures:
316L Stainless steel
1-5/8” Inner diameter
2-1/8” Outer diameter
Fits 2-3/16” hole diameter
Cap size 4-1/2” long x 3-5/8” wide
9” Tube length
1/4” wide x 1/2” tall gimbal bar
Cast models feature a 1/2” drain hole
No logo on the cap for a sleek, low profile
The liner runs the full length of the tube
Each rod holder includes a backing plate and installation nut
Installation requires Model # 53679 Installation Socket
Swivel Base Flush Mount Rod HolderPart #: RH-5365SS Medium 30 Stainless SteelWithout a doubt, our swivel base rod holder is the "Ultimate Rod Holder" for the serious sportsman. Primarily designed to be used with bent butt tackle, the rod holders unique swivel base allows the rod butt to rotate in the rod holder when side pressure is applied to the tip of the rod. This is an indispensable tool, especially important in Giant Blue Fin Tuna fishing, where reel drags in the neighborhood of 60 pounds are frequently used and can result in tremendous forces being applied to the rod holder pin. Not only does this make sheared rod holder pins a thing of the past but, more importantly, it allows the tip of the rod to follow the fish. This reduces the possibility of line fraying and enhanced drag as the line streams sideways out of the roller tip instead of over the roller. The rod is also more easily removed from the holder since it is not locked on a rigid pin. The swivel base holder functions as a standard rod holder when used with straight butt rods. Straight butt rods can be manually rotated so that the line remains on the tip's roller. The amount of torque required to rotate the swivel is set by adjusting the pressure on two nylon drag washers with a half inch stainless steel lock nut at the bottom of the rod holder. Specifications:
Angle: 30 Degrees
Construction: Stainless Steel
Diameter (Inches): 2"
Finish: Polished
Length (Inches): 9"
Mounting Style: Flush
Box Dimensions: 5"H x 6"W x 15"L WT: 2 lbs
UPC: 096811530713
30° Stainless Steel Swivel Base Flush Mount Rod Holder 2.25" OD X 14.5" TubeThis holder is 4" longer than the standard length allowing the bent butt to sit deeper in the holder thus reducing the leverage and stress on the mounting surface.Without a doubt, our swivel base rod holder is the Ultimate Rod Holder for the serious sportsman. Primarily designed to be used with bent butt tackle, the rod holder's unique swivel base allows the rod butt to rotate in the rod holder when side pressure is applied to the tip of the rod. This is an indispensable tool, essential in Giant Blue Fin Tuna fishing, where reel drags in the neighborhood of 60 pounds are frequently used and can result in tremendous forces being applied to the rod holder pin.Not only does this make sheared rod holder pins a thing of the past but, more importantly, it allows the tip of the rod to follow the fish. This reduces the possibility of line fraying and enhanced drag as the line streams sideways out of the roller tip instead of over the roller. The rod is also more easily removed from the holder since it is not locked on a rigid pin. The swivel base holder functions as a standard rod holder when used with straight butt rods. Straight butt rods can be manually rotated so that the line remains on the tips roller. The torque required to rotate the swivel is set by adjusting the pressure on two nylon drag washers with a 1/2-inch stainless steel lock nut at the bottom of the rod holder.Features:
Standard Angle: 30°
Stainless Steel Flush Mount
Swivel Base: Extra Long
Specifications:
Angle: 30 Degrees
Construction: Stainless Steel
Diameter (Inches): 2-1/4"
Finish: Polished
Length (Inches): 16"
Mounting Style: Flush
Box Dimensions: 4"H x 6"W x 17"L WT: 4.1 lbs
UPC: 096811517516
Oval Head Closed Base Rod Holder - 30° - 9"Heavy duty oval head closed end base, with drain hole to accept 1/4"NPT pipe to hose fitting
Head Size: 3.28" x 4.06"
Length: 9"
Angle: 30° Head
Inner Diameter: 1-5/8"
Specifications:
Angle: 30 Degrees
Construction: Stainless Steel
Diameter (Inches): 1-5/8"
Length (Inches): 9"
Box Dimensions: 4"H x 4"W x 11"L WT: 1.8 lbs
UPC: 661033885356
Elite Screwless Stainless Steel 30° Rod & Cup Holder - Drain - Round Top*Must have access to underneath side of gunwale for installation*Features
316 Stainless with Round Top
30º Rod Angle
3/8" NPT Drain Fitting
Specifications:
Angle: 30 Degrees
Construction: Stainless Steel
Mounting Style: Gunwale
Box Dimensions: 6"H x 7"W x 15"L WT: 3.7 lbs
UPC: 857515002162
Quick Guide (pdf)
