Marine Navigation & Instruments - NMEA Cables & Sensors

NMEA 2000 Drop Cable - 2MThis 2 meter NMEA 2000 drop cable offers connection between a NMEA 2000 device and T-connector. The couplers connect to the corresponding T-connectors, creating a simplified installation.Features: Includes (1) NMEA 2000 drop cable Cable length: 2 meter (3.25 ft) 1-Year Limited Warranty

Read more less

NMEA 2000 Blanking Cap - FemaleCovers unused couplers. Protects unused tee connectors from dust and water. Comes in a 2-Pack.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Connection Gender: Female Data Interface: NMEA 2000 Box Dimensions: 2"H x 3"W x 5"L WT: 0.05 lbs UPC: 091887982367

Read more less

NMEA 2000 Single Device Backbone Starter KitBasic starter kit for adding a new NMEA 2000 network to your boat.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Data Interface: NMEA 2000 Box Dimensions: 3"H x 7"W x 7"L WT: 1.9 lbs UPC: 091887991338

Read more less

GPS160 TriNav Sensor w/iKonvert NMEA 2000 Interface BundleThe GPS160, a high performance positioning sensor using GPS, Galileo and Glonass satellite systems for exceptional positioning accuracies and redundancies.TriNav technology allows all three systems to be simultaneously utilized for navigation. The device can also be field programmed for a variety of modes such as single GNSS operation (eg Galileo only) as well as output configurations such as update rate, NMEA sentence structure etcThe GPS160 is available with a NMEA 0183 output (4800, 38400 and 115200 baud programmable) and a USB variant for PC, MAC and Linux. For NMEA 2000 systems, a bundle is available with iKonvert allowing easy and flexible NMEA 2000 installation without the need for cumbersome drop cables.The GPS160 also support an external MOB switch or device. When activated, it creates a “synthesized” AIS SART MOB message on the NMEA output which can be interfaced with a local plotter for MOB identification.The GPS160 supports GPS, Glonass and Galileo positioning. Our TriNav technology is used to combine signals from all three systems to compute the best possible fix accuracy and reliability.Galileo is the global navigation satellite system (GNSS) that has been developed over the past two decades. It joins the GPS and GLONASS systems and offers mariners a 3rd reliable positioning source. It is planned to be fully operational in 2020.Features: 72 channel GPS, Glonass and Galileo GNSS positioning receiver Typically sub 1m accuracy thanks to TriNav technology –combines all satellite data for optimum accuracy Can be configured as dedicated GPS, Glonass or Galileo only device Sophisticated anti-spoofing algorithm for robust positioning performance and interference rejection Available in NMEA 0183, NMEA 2000 (with iKonvert interface)and wireless (with WLN10SM) variants GPS160USB also available with USB connection for PC/MAC User/field selectable 4800, 38400 and 115200 baud operation through simple internal DIP switches Multiple formats of NMEA data output including datum information –user configurable through internal DIP switches Up to 18Hz update rate (user selectable) Ultra low (<20mA) power consumption at 12V DC Input for MOB switch/system – when activated generates synthetic AIS MOB NMEA output to activate MOB position on plotter Professional system (ECDIS) support with datum sentence structure (DTM/GBS/GNS/GRS/GSA/GST) Puck installation or fits 3rd party industry standard 1” x 14 TPI threaded mount Specifications: Data Interface: NMEA 2000 Box Dimensions: 4"H x 7"W x 10"L WT: 1.5 lbs UPC: 703791696055 Brochure (pdf)

Read more less

WLN10 Smart NMEA to WiFi Converter - 4800 BaudDigital Yacht’s WLN10 Smart NMEA to WiFi gateway takes iPad and tablet integration afloat even further with the ability to connect to existing on board GPS, AIS and instrument systems and transfer data wirelessly to an iPad or tablet – allowing compatible apps to display and compute with real time information. The WLN10 creates a secure, password protected wifi network on board to footprint the boat with data.When connected to, for example, an AIS system, real time AIS target positions and identity data will be displayed on detailed electronic charting through compatible apps including NavLink, TimeZero, iAIS, iSailor, Seapilot and hundreds more. The tablet becomes a full function navigation display.This version of the WLN10 can now be programmed through its simple browser interface for NMEA 0183 data at 4800 or 38400 baud and for initial programming: Just logon to the IP address and you can set baud rate, SSID and password.  No complicated programming! Through the web interface, you can also view NMEA data received for easy fault finding of issues.The WLN10 Smart supports both UDP (for multiple connections) and TCP/IP interfaces for maximum compatibility with apps so you can be using a PC at the chart table with an iPad on deck. It’s also bidirectional so apps can control an autopilot if this function is enabled.The Smart WLN10 has one NMEA0183 input which can be configured through the web interface. You can also utilise our SeaTalk to NMEA adaptor to allow SeaTalk instrument data to be interfaced directly to the WLN10 Smart.Features: NMEA 0183 to WiFi server (4800 baud or 38400 baud) Web interface for setup and initial programming Set baud rate, SSID and password through web interface Supports both UDP (for multiple connections) and TCP/IP interfaces View NMEA data received for easy fault finding of issues. Supports a bi directional Wi-Fi interface Fully compatible with popular navigation apps and software Easy to install IPX4 black box solution Specifications: Data Interface: NMEA 0183 Box Dimensions: 2"H x 6"W x 8"L WT: 0.35 lbs UPC: 081159830885

Read more less

NMEA 2000 Backbone Cable - 2MAncor's NMEA 2000 Approved Backbone Cables offer connection to an NMEA 2000 tee connector. The yellow couplers connect to the corresponding Ancor tees creating a simplified, color coded network installation. The backbone cables are available in four lengths from 0.5 meter (1.6 feet) to 10 meters (32.8 feet) to cover a wide variety of applications.Features: Color coded for easy installation and component identification Large 18 AWG power conductors to reduce voltage drop and provide better reliability for critical backbone cables NMEA 2000 Approved, 100 percent universal and compatible with other manufacturers' products WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Cable Length (Feet): 6' Data Interface: NMEA 2000 Box Dimensions: 3"H x 5"W x 8"L WT: 0.6 lbs UPC: 091887982237 Brochure (pdf)

Read more less

NMEA 2000 Drop Cable - 5MAncor's NMEA 2000 Approved Drop Cables offer connection between an NMEA 2000 device and tee connector. The black couplers connect to the corresponding Ancor tees creating a simplified, color coded network installation. The drop cables are smaller in diameter and more flexible than backbone cables for easy connection to NMEA 2000 devices. The drop cables are available in four lengths from 0.5 meter (1.6 feet) to 5 meters (16.4 feet) to cover a wide variety of applications.Features: Color coded for easy installation and component identification Super flexible 22 AWG power conductors for ease of installation and wire routing NMEA 2000 Approved, 100 percent universal and compatible with other manufacturers' products WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Cable Length (Feet): 16' Data Interface: NMEA 2000 Box Dimensions: 3"H x 7"W x 8"L WT: 0.8 lbs UPC: 091887988468 Brochure (pdf)

Read more less

Motion Detector for SIM100Passive Infrared Motion Detector (PIR)Attaches to Maretron SIM100 for NMEA 2000® network monitoringWARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

Read more less

Fuel Flow MonitorPart #: FFM100-01Maretron's FFM100 provides precision fuel flow information to help optimize fuel consumption, which can save thousands of dollars in fuel operating cost. The FFM100 uses state-of-the-art, positive displacement metering technology for unprecedented accuracy. In fact, the accuracy of the FFM100 is nearly that of commercial vessel systems costing tens of thousands of dollars, yet the FFM100 cost less than existing recreational systems found on the market today. Additional benefits of the positive displacement metering technology are the elimination of flow conditioning components such as straighteners and pulsation dampers. Other flow meter technologies require flow conditioning components that increase system and installation cost. The FFM100 also uses true temperature compensation with embedded temperature sensors within the meters. The returning fuel is generally hotter than the supply fuel and if not properly compensated, inaccuracies as much as 5% can occur in computing the engine's fuel consumption. The FFM100 also detects momentary reverse flow in the fuel lines due to fluctuating pressure caused by the injection pump. Less accurate systems count the reverse fuel flow as part of the consumed fuel where the FFM100 properly accounts for momentary reverse flow.Lastly, the FFM100 can be used for fluid types other than fuel (e.g., water, oil, etc.) by ordering the appropriate flow sender.The FPM100 is NMEA 2000® certified so you can view any and all information anywhere on the vessel using a compatible NMEA 2000® display. The FFM100 is a key component of Maretron's N2KView® vessel monitoring and control system. Features: FFM100 converts a variety of flow senders (e.g., fuel, water, etc.) to NMEA 2000® Network Data All flow senders ordered separately depending on application (i.e., single fuel flow sender for gas engine, dual fuel flow senders for diesel engine, water flow sender for sea water, etc.) Fuel flow senders facilitates fuel consumption optimization for reduced fuel operating cost Fuel flow senders use positive displacement metering technology for superior accuracy over other measurement technology such as turbine meters Fuel flow senders do not require costly fuel conditioning components like flow straighteners and pulse dampers Fuel flow senders implement true temperature compensation with precision built-in thermistors for increased accuracy Fuel flow senders automatically detect reverse flow due to fluctuating pressure difference from injection pumps Fuel flow senders pass particle sizes up to 70 micrometers (diesel fuel filters normally filter down to 2 micrometers to prevent clogging injectors) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Fluid Pressure MonitorMaretron's Fluid Pressure Monitor is used to adapt up to six pressure transducers to the NMEA 2000® network (pressure transducers sold separately). This allows you to observe fluid pressures and tank levels anywhere on the vessel where there are NMEA 2000® compatible displays. With the appropriate transducer, the FPM100 reports either pressure or vacuum for a variety of applications including water pressures, oil pressures, hydraulic pressures, or system vacuum for detecting clogged filters.The FPM100 also has a tank level mode, so that fluid levels in a tank can be monitored via a pressure transducer mounted at the bottom of the tank and transmitted over the NMEA 2000® network. This allows you to monitor the fluid levels in tanks that are extremely deep, have internal structures, or are otherwise not suited for other tank level sensing technologies. In this mode, the FPM100 can be calibrated for irregular tank shapes so that you know the true level of the tanks.The FPM100 is NMEA 2000® certified so you can view any and all information anywhere on the vessel using a compatible NMEA 2000® display. The FPM100 is a key component of Maretron's N2KView® vessel monitoring and control system. Features: Adapts up to six pressure transducers to the NMEA 2000® network Each channel independently programmed to match pressure transducer characteristics Each channel independently programmed in pressure/vacuum mode or tank level mode In Tank Level Mode, measures levels of extremely deep or irregularly shaped tanks Applications Water Pressure Atmospheric Pressure Compressed Air Pressure Hydraulic Pressure Steam Pressure User Defined Pressure Sources Fuel Tank Level/Volume Remaining Fresh Water Tank Level/Volume Remaining Waste Water Tank Level/Volume Remaining WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Attaches to Maretron SIM100 for NMEA 2000 network monitoring Real Test technology allows for functional testing in the field Trouble relay for circuit trouble or detector end of life notification Provides wiring supervision 4-wire detector; mounts to wall or ceiling WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

ACM100 Alternating Current MonitorMaretron's ACM100 is a device which monitors AC power sources and outputs information about these sources onto the industry standard NMEA 2000® marine data network. The ACM100 can monitor power busses, generators, or utility power. ACM100 output information is then displayed with networked NMEA 2000® equipment such as the Maretron DSM250 dedicated display or with NMEA 2000® compatible software such as Maretron N2KView. Best of all, the ACM100 is NMEA 2000® certified so you can view any and all AC information anywhere on the vessel using a compatible NMEA 2000® display. The ACM100 is a key component of Maretron's N2KViewr vessel monitoring and control system. Features: Voltage Current Frequency Real Power Reactive Power Apparent Power Power Factor Total Energy Imported Total Energy Exported WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)
