Self-Locking Allen Head Pin Bow Shackle - 6mm Diameter - 1/4"Features: Self-locking twisted shackle with allen head pin forged in grade 316L stainless steel The pin is locked into one of the indentations The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) Applications: Ideal to link chains and anchor On the halyard, avoids damaging the sails To be used when the clutter is reduced To be used when ample room is required Specifications: Materials: 316 stainless steel grade Working load: (lb) 1320 / (kg) 600  WLL: (lb) 660 / (kg) 300  Breaking load: (lb) 3300 / (kg) 1500  Weight: (lb) 0.064 / (g) 29  Dimensions: A: (inch) 1 1/16" / (mm) 27  B: (inch) 15/32" / (mm) 12  C: (inch) 15/64" / (mm) 6  D: (inch) 15/32" / (mm) 12  D diameter: (inch) 15/64" / (mm) 6  E: (inch) 13/64" / (mm) 5  F: (inch) 3/64" / (mm) 1  M: (inch) 1 17/64" / (mm) 32  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Allen Head Pin Bow Shackle - 8mm Diameter - 5/16"Features: Self-locking twisted shackle with allen head pin forged in grade 316L stainless steel The pin is locked into one of the indentations The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications: Ideal for linking chains and anchor On the halyard, avoids damaging the sails To be used when the clutter is reduced To be used when ample room is required Specifications: Materials: 316 stainless steel grade Working load: (lb) 2110 / (kg) 960  WLL: (lb) 1190 / (kg) 540  Breaking load: (lb) 5950 / (kg) 2700  Weight: (lb) 0.148 / (g) 67  Dimensions: A: (inch) 1 29/64" / (mm) 37  B: (inch) 5/8" / (mm) 16  C: (inch) 5/16" / (mm) 8  D: (inch) 5/8" / (mm) 16  D diameter: (inch) 5/16" / (mm) 8  E: (inch) 9/32" / (mm) 7  F: (inch) 63/64" / (mm) 25  M: (inch) 1 37/64" / (mm) 40  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Allen Head Pin D Shackle - 10mm Diameter - 13/32"Features: Self-locking shackle with allen head pin D forged in grade 316L stainless steel The pin is locked into one of the indentations The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications: Ideal for linking chains and anchor On the halyard, avoids damaging the sails To be used when the clutter is reduced Specifications: Materials: 316 stainless steel grade Working load: (lb) 3170 / (kg) 1440  WLL: (lb) 1890 / (kg) 860  Breaking load: (lb) 9470 / (kg) 4300  Weight: (lb) 0.218 / (g) 99  Dimensions: A: (inch) 1 19/64" / (mm) 33  B: (inch) 25/32" / (mm) 20  C: (inch) 25/64" / (mm) 10  D: (inch) 3/4" / (mm) 19  D diameter: (inch) 25/64" / (mm) 10  E: (inch) 23/64" / (mm) 9  F: (inch) 2 1/4" / (mm) 57  G: (inch) 1 39/64" / (mm) 41  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Allen Head Pin D Shackle - 12mm Diameter - 15/32"Features: Self-locking shackle with allen head pin D forged in grade 316L stainless steel The pin is locked into one of the indentations The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications: Ideal to link chains and anchor On the halyard, avoids damaging the sails To be used when the clutter is reduced Specifications: Materials: 316 stainless steel grade Working load: (lb) 4580 / (kg) 2080  WLL: (lb) 2640 / (kg) 1200  Breaking load: (lb) 13220 / (kg) 6000  Weight: (lb) 0.412 / (g) 187  Dimensions: A: (inch) 1-21/32" / (mm) 42 B: (inch) 1-1/16" / (mm) 27 C: (inch) 15/32" / (mm) 12  D: (inch) 15/16" / (mm) 24  D diameter: (inch) 15/32" / (mm) 12  E: (inch) 25/64" / (mm) 10  F: (inch) 2-7/8" / (mm) 73  G: (inch) 1-59/64" / (mm) 49  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Allen Head Pin D Shackle - 6mm Diameter - 1/4"Features: Self-locking shackle with allen head pin D forged in grade 316L stainless steel The pin is locked into one of the indentations The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications: Ideal to link chains and anchor On the halyard, avoids damaging the sails To be used when the clutter is reduced  Specifications: Materials: 316 stainless steel grade  Working load: (lb) 1320 / (kg) 600  WLL: (lb) 700 / (kg) 320  Breaking load: (lb) 3520 / (kg) 1600  Weight: (lb) 0.049 / (g) 22  Dimensions: A: (inch) 3/4" / (mm) 19  B: (inch) 15/32" / (mm) 12  C: (inch) 15/64" / (mm) 6  D: (inch) 15/32" / (mm) 12  D diameter: (inch) 15/64" / (mm) 6  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Allen Head Pin D Shackle - 8mm Diameter - 5/16"Features: Self-locking shackle with allen head pin D forged in grade 316L stainless steel The pin is locked into one of the indentations The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications: Ideal to link chain and anchor On the halyard, avoids to damage the sails To be used when the clutter is reduced Specifications: Materials: 316 stainless steel grade Working load: (lb) 2110 / (kg) 960  WLL: (lb) 1190 / (kg) 540  Breaking load: (lb) 5950 / (kg) 2700  Weight: (lb) 0.117 / (g) 53  Dimensions: A: (inch) 1 1/32" / (mm) 26  B: (inch)5/8" / (mm) 16  C: (inch) 5/16" / (mm) 8  D: (inch) 5/8" / (mm) 16  D diameter: (inch) 5/16" / (mm) 8  E: (inch) 9/32" / (mm) 7  F: (inch) 1 13/16" / (mm) 46  G: (inch) 1 19/64" / (mm) 33  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Bow Shackle - Diameter 10mm - 13/32"Features: Self-locking bow shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications: To be used when ample room is required Possibility to attach several lines or cables Specifications: Materials 316 stainless steel grade Working load (lb) 3350 WLL (lb) 1890 Breaking load (lb) 9470 Weight (lb) 0.302 Dimensions: A (inch) 1-27/32" B (inch) 25/32" C (inch) 25/64" D (inch) 25/32" D diameter (inch) 25/64" E (inch) 23/64" M (inch) 2-3/64"

Read more less

Self-Locking Bow Shackle - Diameter 12mm - 15/32"Features: Self-locking bow shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications: To be used when ample room is required Possibility to attach several lines or cables Specifications: Materials 316 stainless steel grade Working load (lb) 4580 WLL (lb) 2640 Breaking load (lb) 13220 Weight (lb) 0.514 Dimensions (see 2nd image): A (inch) 2-11/64" B (inch) 15/16" C (inch) 15/32" D (inch) 15/16" D diameter (inch) 15/32" E (inch) 25/64" M (inch) 2-31/64"

Read more less

Self-Locking Bow Shackle - Diameter 5mm - 3/16"Features: Self-locking bow shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications: To be used when ample room is required Possibility to attach several lines or cables Specifications: Materials 316 stainless steel grade Working load (lb) 880 WLL (lb) 440 Breaking load (lb) 2200 Weight (lb) 0.037 Dimensions (see 2nd image): A (inch) 29/32" B (inch) 25/64" C (inch) 13/64" D (inch) 25/64" D diameter (inch) 13/64" E (inch) 5/32" M (inch) 63/64"

Read more less

Self-Locking Bow Shackle - Diameter 6mm - 1/4"Features: Self-locking bow shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications: To be used when ample room is required Possibility to attach several lines or cables Specifications: Materials 316 stainless steel grade Working load (lb) 1320 WLL (lb) 660 Breaking load (lb) 3300 Weight (lb) 0.066 Dimensions (see 2nd image): A (inch) 1-7/64" B (inch) 15/32" C (inch) 15/64" D (inch) 15/32" D diameter (inch) 15/64" E (inch) 13/64" M (inch) 1-17/64"

Read more less

Self-Locking Bow Shackle - Diameter 8mm - 5/16"Features: Self-locking bow shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications: To be used when ample room is required Possibility to attach several lines or cables Specifications: Materials 316 stainless steel grade Working load (lb) 2200 WLL (lb) 1190 Breaking load (lb) 5950 Weight (lb) 0.15 Dimensions (see 2nd image): A (inch) 1-29/64" B (inch) 5/8" C (inch) 5/16" D (inch) 5/8" D diameter (inch) 5/16" E (inch) 9/32" M (inch) 1-17/32"

Read more less
